Haas ST-30

List US$88,995 Specs verified 2026-10-02 · haascnc.com Updated 2026-10-02

Image: haascnc.com, Haas Automation

Key Specifications

X Travel

9.4 in (239 mm)

Z Travel

32.5 in (826 mm)

Max Spindle

3,400 rpm

Rapid Traverse

945 ipm (24 m/min)

Spindle Power

30 hp (22.4 kW)

Max Turn Length

32.5 in (826 mm)

How much does the Haas ST-30 cost?

Manufacturer list price

US$88,995

As published by Haas Automation, verified 2026-10-02. Options, tooling, freight and installation are extra.

Overview

The Haas ST-30 is a two-axis turning center for larger-diameter work: 15 in (381 mm) maximum turning diameter, 32.5 in (826 mm) between centers, a 10 in (254 mm) chuck and a 30 hp (22.4 kW) spindle rated 300 ft-lbf (407 N·m) at 500 rpm.

The option that changes the machine most is the gearbox. Haas quotes 1,000 ft-lbf (1,356 N·m) at 150 rpm with it, more than three times the standard torque, delivered at under a third of the speed. A part near the full turning diameter needs few rpm to reach cutting speed, so the gearbox is what makes that diameter usable for roughing in steel. It is an extra, not the base machine. The standard spindle reaches 3,400 rpm; the table gives no top speed for the geared configuration.

X travel is 9.4 in (239 mm). Bar capacity is 3 in (76 mm) through a 3.5 in (88.9 mm) bore on an A2-6 nose. Buyers who need a bigger bore more than a bigger diameter should look at the ST-28L, which passes 4 in (102 mm) bar but turns 13 in (330 mm). For length, the ST-30L extends the turning length to 62.5 in (1,588 mm).

A sub-spindle is optional: 6.5 in (165 mm) chuck, A2-5 nose, 4,100 rpm, a 2.31 in (58.7 mm) bore, and synchronised running up to the main spindle's full 3,400 rpm. Its integrated brake holds 17 ft-lbf (23 N·m). The two-stage parts catcher and the automatic door are options as well.

Standard on the feature list are WiFi, HaasDrop wireless file transfer, Safe Run and HaasConnect remote monitoring. Haas also cites new castings with more rigidity and damping, and improved chip evacuation. The machine weighs 10,900 lb (4,944 kg), and Haas lists a starting price of US$88,995.

Full Specifications

Parameter	Value
Chuck Size	10 in (254 mm)
Max Swing	21 in (533 mm)
Max Turning Diameter	15 in (381 mm)
Max Turning Diameter with Bmt65 Turret	13.75 in (349 mm)
Max Turning Length	32.5 in (826 mm)
Bar Capacity	3 in (76 mm)
Distance Between Centers	32.5 in (826 mm)
X-Axis Travel	9.4 in (239 mm)
Z-Axis Travel	32.5 in (826 mm)
Rapid Traverse Rate	945 ipm (24 m/min)
Max Thrust X	4,100 lbf (18,238 N)
Max Thrust Z	5,100 lbf (22,686 N)
Spindle Nose	A2-6
Spindle Motor Power	30 hp (22.4 kW)
Max Spindle Speed	3,400 rpm
Spindle Torque	300 ft-lbf @ 500 rpm (407 N·m @ 500 rpm)
Spindle Torque (optional gearbox)	1,000 ft-lbf @ 150 rpm (1,356 N·m @ 150 rpm)
Spindle Bore	3.5 in (88.9 mm)
Sub Spindle Chuck Size	6.5 in (165 mm)
Sub Spindle Nose	A2-5
Sub Spindle Speed	4,100 rpm
Sub Spindle Max Sync Speed with Main Spindle	3,400 rpm
Sub Spindle Chuck Throat	Ø 1.81 in × 1.6 in DEEP (Ø 46 mm × 40.6 mm DEEP)
Sub Spindle Drawbar Adapter Bore	Ø 1.81 in × 3.09 in DEEP (Ø 46 mm × 78.5 mm DEEP)
Sub Spindle Drawbar Bore	Ø 1.03 in × 4.91 in DEEP (Ø 26.2 mm × 124.7 mm DEEP)
Sub Spindle Spindle Bore	2.31 in (58.7 mm)
Sub Spindle Integrated Brake Torque	17 ft-lbf (23 N·m)
Sub Spindle Spindle Orientation Accuracy	± 0.02 °
Sub Spindle Rapids	400 ipm (10 m/min)
Turret Stations	12-Station BOT
Turret OD Vs ID Tools	Any Combination (will vary with turret)
Turret Boring Bar Rear Clearance	4 in (102 mm)
Coolant Capacity	55 gal (208 L)
Air Required	4 scfm @ 100 psi (113 L/min @ 6.9 bar)
Inline Air Hose	3/8 in
Air Coupler	3/8 in
Air Pressure Min	80 psi (5.5 bar)
Electrical Service (low voltage)	220 VAC 3-phase, 70 A
Electrical Service (high voltage)	440 VAC 3-phase, 35 A
Shipping Domestic Pallet	171 × 90 × 98 in (435 × 229 × 249 cm)
Shipping Export Pallet	171 × 90 × 98 in (435 × 229 × 249 cm)
Machine Weight	10,900 lb (4,944 kg)

Specifications sourced from haascnc.com — verified 2026-10-02

Strengths & Limitations

Strengths

15 in (381 mm) maximum turning diameter with 9.4 in (239 mm) of X travel
Optional gearbox raises torque to 1,000 ft-lbf (1,356 N·m) at 150 rpm
32.5 in (826 mm) between centers
Optional sub-spindle with a 6.5 in (165 mm) chuck and a 2.31 in (58.7 mm) bore
WiFi, HaasDrop, Safe Run and HaasConnect remote monitoring are standard
12-station BOT turret takes OD and ID tools in any combination

Limitations

Standard torque is 300 ft-lbf (407 N·m); the 1,000 ft-lbf (1,356 N·m) figure requires the optional gearbox
Bar capacity is 3 in (76 mm), against 4 in (102 mm) on the ST-28L
With a BMT65 turret the turning diameter drops to 13.75 in (349 mm)
Sub-spindle, parts catcher and automatic door are options
No live-tooling, C-axis or Y-axis rows are in the table for this model

Best For

Chucked parts up to 15 in (381 mm) in diameter Heavy steel roughing with the optional 1,000 ft-lbf (1,356 N·m) gearbox Shaft work up to 32.5 in (826 mm) between centers 3 in (76 mm) bar work, with the optional sub-spindle for the second side

Frequently Asked Questions

01 What does the optional gearbox do on the ST-30?

It raises spindle torque from the standard 300 ft-lbf (407 N·m) at 500 rpm to 1,000 ft-lbf (1,356 N·m) at 150 rpm. That is the torque needed to take heavy cuts on large diameters, where the spindle turns slowly. The gearbox is an option; the base machine has the standard 30 hp (22.4 kW), 3,400 rpm spindle.

02 How big a part can the ST-30 turn?

Up to 15 in (381 mm) in diameter and 32.5 in (826 mm) long, with 21 in (533 mm) of swing. If a BMT65 turret is fitted the maximum turning diameter is 13.75 in (349 mm). Bar up to 3 in (76 mm) feeds through the spindle, and the chuck is 10 in (254 mm).

03 What is the difference between the ST-30 and the ST-30L?

Length. The ST-30 has 32.5 in (826 mm) of Z travel and weighs 10,900 lb (4,944 kg). The ST-30L has 62.5 in (1,588 mm) of Z travel and weighs 13,300 lb (6,033 kg). Turning diameter, chuck, bar capacity and the 30 hp (22.4 kW) spindle are the same on both.

04 Is the sub-spindle standard on the ST-30?

No, it is listed as an option. It has a 6.5 in (165 mm) chuck on an A2-5 nose, a 4,100 rpm top speed, a 2.31 in (58.7 mm) bore and rapids of 400 ipm (10 m/min), and it runs synchronised with the main spindle up to 3,400 rpm. The chuck throat is 1.81 in in diameter by 1.6 in deep (46 mm by 40.6 mm).

05 Which software and connectivity features are standard?

Haas lists WiFi, HaasDrop wireless file transfer, Safe Run and HaasConnect remote monitoring as standard on the ST-30. The two-stage automatic parts catcher, the sub-spindle and the automatic door are listed as options, so check which of them are on your quote.

06 What services does the ST-30 require?

220 VAC three-phase at 70 A or 440 VAC three-phase at 35 A, plus 4 scfm of air at 100 psi (113 L/min at 6.9 bar) with no less than 80 psi (5.5 bar) at the inlet. Coolant capacity is 55 gal (208 L). It ships on a 171 × 90 × 98 in (435 × 229 × 249 cm) pallet.
