Bystronic BySmart Fiber 3015
Key Specifications
Working Area (X × Y)
Laser Type
Laser Power Options
Maximum Sheet Thickness (Mild Steel, 10 kW)
Maximum Sheet Thickness (Stainless Steel, 10 kW)
Maximum Sheet Thickness (Aluminum, 10 kW)
Overview
The Bystronic BySmart Fiber 3015 is Bystronic's mid-range fiber laser cutting machine, positioned between the entry-level ByStar Fiber and the high-end BySprint Pro platforms. It delivers a compelling combination of cutting performance, automation readiness, and competitive pricing for job shops and contract fabricators running standard 3,000 × 1,500 mm sheet formats in mild steel, stainless steel, aluminum, and non-ferrous metals.
Equipped with a fiber laser source ranging from 3 kW to 10 kW, the BySmart Fiber 3015 covers a wide range of material thicknesses while maintaining fast cycle times on thin-gauge sheet. Bystronic's ByMotion axis drive system delivers precise, dynamic cutting motion, while the ByCut intelligent cutting process automatically selects optimal cutting parameters based on material type and thickness — reducing setup time and operator dependence on manual parameter tuning.
The BySmart Fiber 3015 supports Bystronic's automation modules including the ByLoader sheet loading system and integration with ByTower storage towers for extended unattended operation. Bystronic's BySoft 7 CAM software provides nesting, part programming, and machine communication from a single environment, with cloud connectivity for remote monitoring and diagnostics through the Bystronic Customer Center platform.
For fabricators seeking a balance of capability and cost in a proven Swiss-engineered platform, the BySmart Fiber 3015 offers a clear upgrade path from entry-level machines while remaining more accessible than Bystronic's flagship BySpeed Pro or BySprint Pro systems. It suits shops processing mixed material orders with regular throughput demands that benefit from Bystronic's strong after-sales support network.
Full Specifications
| Parameter | Value |
|---|---|
| Working Area (X × Y) | 3,000 × 1,500 mm |
| Laser Type | Fiber laser (IPG or equivalent) |
| Laser Power Options | 3 kW / 6 kW / 8 kW / 10 kW |
| Maximum Sheet Thickness (Mild Steel, 10 KW) | 25 mm |
| Maximum Sheet Thickness (Stainless Steel, 10 KW) | 25 mm |
| Maximum Sheet Thickness (Aluminum, 10 KW) | 20 mm |
| Maximum Cutting Speed | 40 m/min |
| Maximum Traverse Speed | 120 m/min |
| Positioning Accuracy | ±0.05 mm |
| Maximum Sheet Weight | 900 kg |
| Control | Bystronic ByVision Cutting |
| CAM Software | Bystronic BySoft 7 |
Specifications sourced from bystronic.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Mid-range pricing delivers Bystronic build quality and BySoft 7 integration at a cost accessible to growing job shops
- ByCut intelligent process control automatically selects cutting parameters, reducing operator skill dependency
- Wide laser power range (3–10 kW) covers thin decorative sheet to 25 mm structural plate in a single platform
- Automation-ready design supports ByLoader and ByTower integration for extended unattended production
- Bystronic's global service network and Customer Center cloud platform provide strong remote support and diagnostics
Limitations
- Maximum traverse speed of 120 m/min is lower than Bystronic's flagship BySpeed Pro, impacting cycle time on high-volume thin sheet
- 10 kW maximum power does not match the 15+ kW options available on premium laser platforms for ultra-thick cutting
- Automation ecosystem is less developed than TRUMPF's offering, with fewer turnkey storage and sorting solutions
Best For
Frequently Asked Questions
01
The ByStar Fiber is Bystronic's entry-level fiber laser platform. The BySmart Fiber 3015 sits above it with higher available laser power (up to 10 kW vs. 6 kW typical for entry models), more automation integration options, and the ByCut intelligent cutting process. The BySmart is better suited for shops with higher throughput needs and thicker material requirements.
02
Yes. The fiber laser source on the BySmart Fiber handles reflective metals including copper and brass. Typical capacity with a 6 kW or higher laser is 6–8 mm copper and 8–10 mm brass, though exact values depend on laser power level and assist gas pressure.
03
The BySmart Fiber 3015 is compatible with Bystronic's ByLoader for automated sheet feeding, and can be integrated with ByTower storage towers for lights-out operation. BySoft 7 manages production scheduling and machine communication across the automation cell.
04
Yes. ByCut is included on the BySmart Fiber 3015 and automatically selects cutting parameters including speed, power, focus, and assist gas pressure based on the detected material type and thickness. This reduces the need for manual parameter optimization and helps maintain consistent cut quality.
05
BySoft 7 is Bystronic's all-in-one CAM platform that handles nesting, part programming, cutting parameter management, and direct machine communication for the BySmart Fiber. It also connects to Bystronic's Customer Center cloud for remote monitoring, job tracking, and diagnostics.
