Accurpress Accell CNC Press Brake
Key Specifications
capacity
bending length
ram drive
crowning
backgauge
open height
How much does the Accurpress Accell CNC Press Brake cost?
Estimated price range
Our best estimate for a cnc press brake in this class — not a quote from Accurpress. Configuration moves it a long way.
Overview
The Accurpress Accell CNC Press Brake is a hydraulic, dual-cylinder press brake family listed in 10 standard sizes from 55 to 1,100 ton, with bending lengths from 6 to 22 ft (1829 to 6706 mm). This page covers the range as a whole, so every figure here is a span, and the numbers for one size have to come from the quotation for that size.
CNC hydraulic crowning is listed as standard. That matters most at the long end of the range: on a 22 ft (6706 mm) bed, deflection of the ram and bed under load would otherwise open the angle in the middle of the bend, and crowning is what holds it constant along the part.
Ram speeds are listed as 200 mm/s on approach and 10 mm/s typical in the bend. The fast approach shortens the non-working part of each stroke, while the bending speed is slow enough for an operator to follow the sheet as it swings up. Open height is given as 500 – 800 mm depending on model, and daylight as 400 – 650 mm. The listed figures do not say which size has which.
The backgauge is listed as 5-axis, naming X, R, Z1 and Z2, with a 6th axis optional. The control is either Hurco Autobend or Delem DA-66T, so two machines of the same size can differ in how they are programmed. Settle the control choice before comparing quotations.
Full Specifications
| Parameter | Value |
|---|---|
| Capacity | 55 to 1,100 ton (10 standard sizes) |
| Bending Length | 6 to 22 ft (1829 to 6706 mm) |
| Ram Drive | Hydraulic, dual cylinder |
| Crowning | CNC hydraulic crowning standard |
| Backgauge | 5-axis (X, R, Z1, Z2, optional 6th axis) |
| Open Height | 500 – 800 mm (model dependent) |
| Daylight | 400 – 650 mm |
| CNC Control | Hurco Autobend or Delem DA-66T |
| Approach Speed | 200 mm/s |
| Bending Speed | 10 mm/s typical |
Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.
Strengths & Limitations
Strengths
- 10 standard sizes from 55 to 1,100 ton, in bending lengths from 6 to 22 ft (1829 to 6706 mm)
- CNC hydraulic crowning is listed as standard
- Hydraulic ram drive with dual cylinders
- 200 mm/s approach speed shortens the idle part of each stroke
- Backgauge with X, R, Z1 and Z2 axes, and a 6th axis optional
Limitations
- Open height (500 – 800 mm) and daylight (400 – 650 mm) are model dependent, and the listed figures do not tie them to a size
- No stroke, throat depth or machine weight is listed for any size
- The 6th backgauge axis is an option, not part of the standard machine
- The control is either Hurco Autobend or Delem DA-66T, and the choice changes programming and training
Best For
Frequently Asked Questions
01
The listed figures show 10 standard sizes with capacities from 55 to 1,100 ton and bending lengths from 6 to 22 ft (1829 to 6706 mm). The table does not pair each tonnage with a length, so that comes from the quotation for a specific size.
02
Yes. CNC hydraulic crowning is listed as standard across the range. The ram drive is hydraulic with dual cylinders, and crowning compensates for deflection along the bed so the bend angle stays the same from the ends to the middle.
03
Approach speed is listed as 200 mm/s and bending speed as 10 mm/s typical. No return speed is listed. Open height is 500 – 800 mm depending on model, so the time lost on each stroke also depends on how far the ram has to travel.
04
The control row lists Hurco Autobend or Delem DA-66T. The backgauge is listed as 5-axis with X, R, Z1 and Z2 named, and a 6th axis as an option. Confirm both the control and the axis count on the quotation for the machine you are considering.
