Yawei PBH(A)-1000/6200
Key Specifications
bending force
table length
distance between columns
throat depth
ram stroke
max opening height
How much does the Yawei PBH(A)-1000/6200 cost?
Price estimate
We do not have a price for the Yawei PBH(A)-1000/6200 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
At 10,000 kN, the Yawei PBH(A)-1000/6200 is the first five-figure force rating in the PBH(A) series. The table length is 6,200 mm (244.1 in).
Geometry is carried over from the PBH(A)-800/6200: 5,100 mm (200.8 in) between columns, a 610 mm (24.0 in) throat, 410 mm (16.1 in) of stroke and 720 mm (28.3 in) of opening height. Even the slider speeds are the same, 100 mm/s; 9 mm/s; 80 mm/s. What the buyer pays for is force, delivered by a 90 kW (120.7 hp) motor.
One detail in Yawei's table is unexpected. The overall dimensions, 6,500 x 2,760 x 4,800 mm (255.9 x 108.7 x 189.0 in), are narrower and lower than those printed for the PBH(A)-800/6200, although the weight is higher at 108,000 / 92,000 kg (238,095 / 202,822 lb). The figures are reproduced as the maker gives them; a site plan should rest on a drawing, not on the brochure table.
The oil tank holds 1,500 L.
A six-metre bed with this much force is a specialist tool for thick and hard plate. Armour and wear grades, heavy crane and excavator parts, and thick-walled half shells are the obvious candidates. For such work the maker's notes on the cylinder mounting are worth reading: a spherical floating support with a specially guided piston rod, described as giving strong resistance to off-centre load.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Force | 10,000 kN |
| Table Length | 6,200 mm (244.1 in) |
| Distance Between Columns | 5,100 mm (200.8 in) |
| Throat Depth | 610 mm (24.0 in) |
| Ram Stroke | 410 mm (16.1 in) |
| Max Opening Height | 720 mm (28.3 in) |
| Ram Speed | 100 mm/s; 9 mm/s; 80 mm/s |
| Main Motor Power | 90 kW (120.7 hp) |
| Oil Tank Volume | 1,500 L |
| Machine Dimensions | 6,500 x 2,760 x 4,800 mm (255.9 x 108.7 x 189.0 in) |
| Machine Weight | 108,000 / 92,000 kg (238,095 / 202,822 lb) |
Specifications sourced from en.yawei.cc — verified 2026-10-05
Strengths & Limitations
Strengths
- 10,000 kN on a 6,200 mm (244.1 in) table
- Geometry and slider speeds of the PBH(A)-800/6200 with more force
- 90 kW (120.7 hp) main motor
- 410 mm (16.1 in) slider stroke
- Oil tank of 1,500 L, no larger than on the PBH(A)-800/6200
Limitations
- Weight above one hundred tonnes
- Printed dimensions are smaller than the lighter sibling's and need confirming
- Slider return speed of 80 mm/s
- Electrical supply for a 90 kW (120.7 hp) motor
Best For
Frequently Asked Questions
01
Nominal force is 10,000 kN and the table length is 6,200 mm (244.1 in). Column spacing is 5,100 mm (200.8 in), throat opening 610 mm (24.0 in) and slider stroke 410 mm (16.1 in).
02
Not according to the table. The PBH(A)-800/6200 is printed at 6,500 x 2,990 x 5,000 mm (255.9 x 117.7 x 196.9 in), this model at 6,500 x 2,760 x 4,800 mm (255.9 x 108.7 x 189.0 in). The weight here is higher, 108,000 / 92,000 kg (238,095 / 202,822 lb), so the dimensions deserve a check.
03
A 90 kW (120.7 hp) main motor with a 1,500 L oil tank. Slider speeds are given as 100 mm/s; 9 mm/s; 80 mm/s; the three values are not labelled on the page.
04
Yes. The PBH(A)-1000/8200 has a table of 8,200 mm (322.8 in) and 6,500 mm (255.9 in) between the columns, with motor and working space unchanged from this model.
