Thermal Dynamics Pak Master 150XL
This model was not found in Thermal Dynamics's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.
Key Specifications
Weight
output current
cutting capacity mild steel
max pierce thickness
duty cycle
input voltage
How much does the Thermal Dynamics Pak Master 150XL cost?
Estimated price range
Our best estimate for a cnc plasma cutting in this class — not a quote from Thermal Dynamics. Configuration moves it a long way.
Overview
The Thermal Dynamics Pak Master 150XL is a 150 A plasma power supply listed for both mechanized and manual cutting, with a 100% duty cycle at 150 A and an output range of 30–150 A. It is not in the maker's current lineup, so it is of interest mainly as a used purchase.
The dual process listing is what sets it apart. One supply is listed for hand work and for a table, which suits a shop that cannot justify a separate machine for each. Because the listed figures give 100% duty at the full 150 A, neither use has to be derated for long arc-on times.
In mild steel the recommended cut is up to 38 mm (1.5 in), maximum severance is 50 mm (2 in) and the pierce limit is 25 mm (1 in). Plate between 25 mm (1 in) and 38 mm (1.5 in) therefore cuts at the recommended quality but must be entered from an edge.
Input is listed as 200–600V three-phase, 50/60 Hz, multi-voltage, and weight as approximately 130 kg (285 lb). Torch, gas and cut-speed details are not in the table; they have to come from the documents of the unit being offered.
Full Specifications
| Parameter | Value |
|---|---|
| Output Current | 30–150 A |
| Cutting Capacity Mild Steel | Up to 38 mm (1.5 in) recommended; 50 mm (2 in) maximum severance |
| Max Pierce Thickness | Up to 25 mm (1 in) mild steel |
| Duty Cycle | 100% at 150 A |
| Input Voltage | 200–600V, 3-phase, 50/60 Hz (multi-voltage) |
| Process | Mechanized and manual plasma cutting |
| Machine Weight | Approx. 130 kg (285 lb) |
Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.
Strengths & Limitations
Strengths
- Listed for both mechanized and manual plasma cutting
- 100% duty cycle at the full 150 A
- Multi-voltage input, listed as 200–600V three-phase at 50/60 Hz
Limitations
- Pierce limit of 25 mm (1 in) in mild steel, below the 38 mm (1.5 in) recommended cut
- Approximately 130 kg (285 lb), heavy for a supply that is also listed for manual cutting
- Only three-phase input appears in the listed figures
Best For
Frequently Asked Questions
01
Both. The process row lists mechanized and manual plasma cutting, and the duty cycle is listed as 100% at 150 A, so the full output is available whichever way the supply is used.
02
Up to 25 mm (1 in) in the listed figures. The recommended cut is up to 38 mm (1.5 in) and maximum severance is 50 mm (2 in); above 25 mm (1 in) the cut has to begin at a plate edge.
03
The input row reads 200–600V, 3-phase, 50/60 Hz, and describes the unit as multi-voltage. No single-phase input is listed. The weight is given as approximately 130 kg (285 lb).
