Republic Lagun UTC-2280
Key Specifications
Spindle Taper
Spindle Power
Max Turn Length
Accuracy
Repeatability
swing over bed
How much does the Republic Lagun UTC-2280 cost?
Price estimate
We do not have a price for the Republic Lagun UTC-2280 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Planning the floor comes first with the Republic Lagun UTC-2280. This Universal Turning Center has 73.62 in (1,870 mm) between centers, packs to 165.4 in x 90.6 in x 87.8 in (4,200 mm x 2,300 mm x 2,230 mm) and weighs 4,800 kg (10,582 lb) net, 5,400 kg (11,905 lb) gross.
For that footprint the buyer gets a working length of 66.14 in (1,680 mm) at up to Ø 12.8 in (325 mm) in diameter, under a Ø 22 in (550 mm) swing. Z travel is 70.1 in (1,780 mm) and X travel 11.8 in (300 mm). Rapid traverse in Z is 394 ipm (10 m/min), so the carriage needs several seconds to run the length of the bed; cycle planning for long parts should allow for it.
Holding accuracy over a long Z stroke is the harder problem. The maker's answer is a precision-ground 2 in (50 mm) diameter Z axis ball screw and a Meehanite frame with heavy ribbing, and it states positioning accuracy of ±0.0005 in (0.01 mm) over full X and Z travel, laser verified before shipping. Table repeatability is ± 0.0002 in (0.005 mm). The headstock is enclosed and ribbed to shed heat, which the maker links to avoiding thermal distortion on long turning jobs.
The spindle runs 35-3,500 rpm on an AC 12 HP (9 kW) Fanuc AC motor through an ASA A2-8 nose. Fluids are sized to match the bed: a 47.5 gal (180 liters) coolant tank, and a hydraulic tank of 6.6 gal (25 liters) as standard or 10.5 gal (40 liters) as an option. A manual 4-way tool post is standard.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | Ø 22 in (550 mm) |
| Distance Between Centers | 73.62 in (1,870 mm) |
| Max Turning Length | 66.14 in (1,680 mm) |
| Max Turning Diameter | Ø 12.8 in (325 mm) |
| Bed Width | 13.58 in (345 mm) |
| Bed Ways | 2 V, 2 flat |
| X Axis Travel | 11.8 in (300 mm) |
| Z Axis Travel | 70.1 in (1,780 mm) |
| Spindle Nose | ASA A2-8, Ø 3.8 in (97 mm) |
| Spindle Taper | Taper 1/20 |
| Spindle Speeds | Infinitely variable |
| Spindle Speed Range | 35-3,500 rpm |
| Spindle Motor Power | AC 12 HP (9 kW) wide range heavy duty Fanuc AC spindle motor |
| Tool Post | Manual 4-way tool post (STD) |
| Turning Tool Size | 1 in (25 mm) |
| Tailstock Quill Diameter | Ø 3.35 in (85 mm) |
| Tailstock Quill Taper | #5 MT |
| Tailstock Quill Travel | 7 in (178 mm) |
| Ball Screw Diameter X Z | Ø 0.98 in (25 mm) P5 C5 / Ø 1.97 in (50 mm) P10 C5 |
| Rapid Traverse X Z | X = 295 ipm (7.5 m/min) / Z = 394 ipm (10 m/min) |
| Positioning Accuracy | ± 0.0005 in (0.01 mm) |
| Repeatability | ± 0.0002 in (0.005 mm) |
| Resolution | ± 0.0001 in (0.002 mm) |
| Hydraulic Tank | 6.6 gal (25 liters) standard, 10.5 gal (40 liters) optional |
| Coolant Tank | 47.5 gal (180 liters) |
| Machine Weight | 4,800 kg (10,582 lb) / 5,400 kg (11,905 lb) (net / gross, approx.) |
| Packing Dimensions | 165.4 in x 90.6 in x 87.8 in (4,200 mm x 2,300 mm x 2,230 mm) |
Specifications sourced from lagun.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 66.14 in (1,680 mm) working length with 70.1 in (1,780 mm) of Z travel
- Precision-ground 2 in (50 mm) Z axis ball screw, per the maker's feature list
- Stated positioning accuracy of ±0.0005 in (0.01 mm) over full X and Z travel
- 47.5 gal (180 liters) coolant tank
- Enclosed, well-ribbed headstock intended to limit thermal distortion
Limitations
- Packs to 165.4 in (4,200 mm) long and weighs 5,400 kg (11,905 lb) gross
- Z rapid of 394 ipm (10 m/min) is slow relative to the stroke
- AC 12 HP (9 kW) is the only spindle motor listed
- Standard tool station is a manual 4-way tool post
Best For
Frequently Asked Questions
01
The packing size is 165.4 in x 90.6 in x 87.8 in (4,200 mm x 2,300 mm x 2,230 mm), length by width by height. Net weight is 4,800 kg (10,582 lb) and gross weight 5,400 kg (11,905 lb). The maker gives packing dimensions only, so ask for an installation drawing with door and tailstock clearances.
02
Positioning accuracy of ± 0.0005 in (0.01 mm), repeatability of ± 0.0002 in (0.005 mm) and resolution of ± 0.0001 in (0.002 mm). The maker says each UTC is laser verified for the positioning figure before shipment.
03
Maximum working length is 66.14 in (1,680 mm) and maximum working diameter Ø 12.8 in (325 mm). Swing over the bed is Ø 22 in (550 mm), and distance between centers is 73.62 in (1,870 mm).
04
Mainly in length. The UTC-22120 has 113 in (2,870 mm) between centers and 109.4 in (2,780 mm) of Z travel, and its Z ball screw is Ø 2.48 in (63 mm) instead of the Ø 1.97 in (50 mm) on the UTC-2280. Net weight is 5,300 kg (11,684 lb) for the UTC-22120.
