Okuma LB3000 EX II MY

Est. $180,000 – $240,000 Updated 2026-10-03

Key Specifications

Max Turn Length

750 mm (29.5 in)

max swing over bed

680 mm (26.8 in)

max turning diameter

366 mm (14.4 in)

chuck size

254 mm (10 in)

spindle speed main

35 – 3,500 rpm

spindle motor main

18.5 / 22 kW (25 / 30 HP)

How much does the Okuma LB3000 EX II MY cost?

Estimated price range

Est.$180,000 – $240,000

Our best estimate for a cnc lathes / turning center in this class — not a quote from Okuma. Configuration moves it a long way.

Overview

The Okuma LB3000 EX II MY is listed as an LB3000 with a Y axis and driven tools on the turret. Y-axis travel is ±52.5 mm, the live tools run 50 – 6,000 rpm on a 3.7 / 5.5 kW (5 / 7.5 HP) motor, and the turret has 12 stations, given as VDI-40 or BMT-65. With that equipment a turned part can be cross-drilled, slotted and milled off-centre without leaving the chuck.

On the work side, the listed figures are a 254 mm (10 in) chuck, an 80 mm (3.15 in) bar capacity and a JIS A2-6 spindle nose. Rapid traverse is 20 / 24 / 12 m/min in X, Z and Y. The Y axis is the slowest of the three, which seldom matters because Y moves are short.

The rest of the table needs caution. The listed rows give more than one value for main spindle speed, main spindle power, swing, turning diameter and turning length, and they name two different controls. That pattern points to more than one configuration behind the figures. Take those values from the nameplate and build sheet of the specific machine, not from a summary.

For installation, the listed weight is approx. 6,500 kg (14,330 lb) and the floor space is 3,025 x 2,008 mm, width by depth.

Full Specifications

Parameter	Value
Max Swing Over Bed	680 mm (26.8 in)
Max Turning Diameter	366 mm (14.4 in)
Chuck Size	254 mm (10 in)
Spindle Speed Main	35 – 3,500 rpm
Spindle Motor Main	18.5 / 22 kW (25 / 30 HP)
Y Axis Travel	±52.5 mm
Live Tool Speed	50 – 6,000 rpm
Live Tool Motor	3.7 / 5.5 kW (5 / 7.5 HP)
Number of Tool Stations	12
Bar Capacity	80 mm (3.15 in)
Machine Weight	Approx. 6,500 kg (14,330 lb)
Floor Space W X D	3,025 x 2,008 mm
Speed Range	45~5,000
Standard Power	22/15
Max Machining Diameter	410
Max Machining Length	500 [1,000; 1,300]
Spindle Nose Type	JIS A2-6
Max Swing	580 mm (22.8 in)
Max Turning Length	750 mm (29.5 in)
Main Spindle Speed	4,200 RPM
Main Spindle Motor	15 kW (20 HP)
Spindle Nose	A2-6 (Camlock)
Turret Stations	12-station (VDI-40 or BMT-65)
Rapid Traverse X Z Y	20 / 24 / 12 m/min
CNC Control	Okuma OSP-P300L

Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.

Strengths & Limitations

Strengths

Y-axis travel of ±52.5 mm for off-centre milling and drilling
Live tools listed at 50 – 6,000 rpm with a 3.7 / 5.5 kW (5 / 7.5 HP) motor
12-station turret, listed as VDI-40 or BMT-65
Listed bar capacity of 80 mm (3.15 in) with a 254 mm (10 in) chuck

Limitations

Y travel of ±52.5 mm limits how far off centre a feature can be milled
Live tool power of 3.7 / 5.5 kW (5 / 7.5 HP) suits drilling and light milling, not heavy stock removal
Y-axis rapid is 12 m/min, against 20 and 24 m/min in X and Z
The listed rows disagree on main spindle speed, power and turning capacity, so those must be confirmed on the machine

Best For

Turned parts that also need cross holes, flats or keyways Off-centre milling within ±52.5 mm of Y travel Bar work up to the listed 80 mm (3.15 in) capacity Drilling and light milling with live tools at up to 6,000 rpm

Frequently Asked Questions

01 How much Y-axis travel does the LB3000 EX II MY have?

The listed Y-axis travel is ±52.5 mm. That is the distance either side of the spindle centreline over which a driven tool can mill or drill, and Y-axis rapid traverse is listed at 12 m/min.

02 What are the live tooling figures for the LB3000 EX II MY?

Live tool speed is listed as 50 – 6,000 rpm and the live tool motor as 3.7 / 5.5 kW (5 / 7.5 HP). Those figures fit drilling, tapping and light milling on turned parts.

03 What turret does the LB3000 EX II MY use?

A 12-station turret. The table gives the tooling interface as VDI-40 or BMT-65, so find out which one a particular machine has before buying holders, because the two are not interchangeable.

04 What main spindle speed and power does the LB3000 EX II MY have?

The listed rows do not agree. Main spindle speed and motor power each appear with more than one value, which suggests different spindle configurations. Read both from the nameplate of the machine in question; the spindle nose is listed as JIS A2-6.

05 How much floor space and weight should I plan for?

The listed floor space is 3,025 x 2,008 mm, width by depth, and the listed weight is approx. 6,500 kg (14,330 lb). Allow extra room around that footprint for door and service access.
