INDEX G160

Specs verified 2026-10-03 · index-group.com Updated 2026-10-03

Image: index-group.com, INDEX-Traub

Key Specifications

Tool Capacity

up to 120 tools (magazine and turrets)

Rapid Traverse

up to 60 m/min

Max Turn Length

760 mm (29.9 in)

spindle bore

42 / 65 mm (1.7 / 2.6 in) spindle clearance

chuck size

up to 130 / 175 mm (5.1 / 6.9 in)

work spindles

2 identical (main and counter spindle)

How much does the INDEX G160 cost?

Price estimate

Uncertain

We do not have a price for the INDEX G160 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The INDEX G160 is a compact turn-mill center with 2 identical work spindles, 3 tool carriers and a motor milling spindle offered at 18,000 rpm or 32,000 rpm. Spindle clearance is 42 / 65 mm (1.7 / 2.6 in) depending on version, chucks go up to 130 / 175 mm (5.1 / 6.9 in), and turning length is 760 mm (29.9 in). The control is a Siemens Sinumerik ONE.

The two milling spindle versions are a real choice. The 18,000 rpm spindle gives 29 Nm (21.4 lb-ft), the 32,000 rpm version 17 Nm (12.5 lb-ft). The first covers general milling and drilling; the second is for very small tools, micro-drilling and fine finishing, where only high rpm brings the cutter to its proper surface speed. Tools in the milling spindle can be up to 250 mm (9.8 in) long.

Tooling capacity is large for the size. Each lower turret has 15 VDI 25 stations with W serration, all live-tool capable, and total capacity reaches up to 120 tools across magazine and turrets. Up to 3 tools can be in cut at once, and the machine has up to 16 productive axes, so cycle time on complex parts comes from overlapping operations rather than from any single spindle.

Because main and counter spindle are identical, both ends of the part get the same capability. Rapid traverse is up to 60 m/min. The bar loader interface is UNIMAG 5 for the INDEX MBL76 loader, with 3 m or 4 m bars.

Against the G200, which is listed with 660 mm (26 in) of turning length and a 165 mm (6.5 in) chuck, the G160 offers more length and much faster milling in a machine aimed at smaller diameters.

Full Specifications

Parameter	Value
Spindle Bore	42 / 65 mm (1.7 / 2.6 in) spindle clearance
Chuck Size	up to 130 / 175 mm (5.1 / 6.9 in)
Max Turning Length	760 mm (29.9 in)
Work Spindles	2 identical (main and counter spindle)
Tool Carriers	3
Tool Capacity	up to 120 tools (magazine and turrets)
Turret Stations	15 VDI 25 stations per lower turret (W serration), all live-tool capable
Milling Spindle Speed	18,000 rpm / 29 Nm (21.4 lb-ft) or 32,000 rpm / 17 Nm (12.5 lb-ft)
Max Tool Length	250 mm (9.8 in) in the motor milling spindle
Rapid Traverse Rate	up to 60 m/min
Productive Axes	up to 16
Simultaneous Tools	up to 3 tools in cut
CNC Control	Siemens Sinumerik ONE
Bar Loader Interface	UNIMAG 5 (INDEX MBL76 loader, 3 m or 4 m bars)

Specifications sourced from index-group.com — verified 2026-10-03

Strengths & Limitations

Strengths

Motor milling spindle at 18,000 rpm / 29 Nm or 32,000 rpm / 17 Nm
2 identical work spindles, so both ends of the part get the same capability
Up to 120 tools across magazine and turrets, with 15 live VDI 25 stations per lower turret
Up to 3 tools in cut and up to 16 productive axes
760 mm (29.9 in) turning length and rapids up to 60 m/min

Limitations

Spindle clearance is 42 / 65 mm (1.7 / 2.6 in), so bar work is limited to small and medium diameters
Chucks go up to 130 / 175 mm (5.1 / 6.9 in), small for flange-type parts
The 32,000 rpm milling spindle gives only 17 Nm (12.5 lb-ft)
The table lists no main spindle speed, power or torque

Best For

Complex small and medium bar parts finished in one cycle Micro-drilling and fine milling at up to 32,000 rpm Shafts up to 760 mm (29.9 in) long Parts with many operations where 3 tools can cut at once

Frequently Asked Questions

01 Which milling spindle should I choose on the G160?

The 18,000 rpm version gives 29 Nm (21.4 lb-ft) and suits general milling and drilling. The 32,000 rpm version gives 17 Nm (12.5 lb-ft) and suits very small tools and fine finishing. Tools up to 250 mm (9.8 in) long fit the motor milling spindle.

02 How many tools does the G160 carry?

Up to 120 tools across the magazine and turrets. Each lower turret has 15 VDI 25 stations with W serration, all live-tool capable. Up to 3 tools can be in cut at the same time.

03 What bar and chuck sizes does the G160 take?

Spindle clearance is 42 / 65 mm (1.7 / 2.6 in) and chucks go up to 130 / 175 mm (5.1 / 6.9 in), each pair depending on the spindle version. The bar loader interface is UNIMAG 5 for the INDEX MBL76 loader with 3 m or 4 m bars.

04 Which control does the G160 use?

A Siemens Sinumerik ONE. The machine has up to 16 productive axes and 3 tool carriers, so a control able to coordinate several channels at once is part of how it reaches short cycle times.
