Hanwha XE16 II
Key Specifications
max bar capacity
max machining diameter
max machining length
number of axes
main spindle speed
main spindle power
How much does the Hanwha XE16 II cost?
Estimated price range
Our best estimate for a swiss-type lathe in this class — not a quote from Hanwha. Configuration moves it a long way.
Overview
The Hanwha XE16 II is a compact Swiss-type lathe for bar up to 16 mm (0.630 in), listed with a main spindle that runs up to 15,000 rpm, a back spindle up to 10,000 rpm and up to 18 tool positions. Maximum machining length is 150 mm (5.91 in).
Spindle speed is the figure that defines it. Small-diameter stock needs high rpm to reach a sensible surface speed, and 15,000 rpm on a 16 mm (0.630 in) machine addresses that directly. For comparison the XE20 II, a 20 mm (0.79 in) machine, is listed at 10,000 rpm. Power on the XE16 II is in proportion to the bar: 2.2 kW (3.0 hp) on the main spindle and 1.5 kW (2.0 hp) on the back spindle.
The listed figures describe 7-axis simultaneous control, a precision Swiss-type guide bushing, and driven tools on both the front and back sides running up to 6,000 rpm. With a back spindle and back driven tools, the cut-off end can be drilled or milled before the part drops. The control is a Fanuc 32i.
Size is approximate in the table: about 1,700 x 1,100 x 1,650 mm and about 1,700 kg (3,748 lbs). The table does not split the 18 tool positions into turning, front, cross and back groups, and gives no stroke or driven-tool power figures. Confirm those, along with the figures above, against the documentation for the specific machine.
Full Specifications
| Parameter | Value |
|---|---|
| Max Bar Capacity | 16 mm (0.630 in) |
| Max Machining Diameter | 16 mm (0.630 in) |
| Max Machining Length | 150 mm (5.91 in) |
| Number of Axes | 7-axis simultaneous |
| Main Spindle Speed | Up to 15,000 RPM |
| Main Spindle Power | 2.2 kW (3.0 HP) |
| Back Spindle Speed | Up to 10,000 RPM |
| Back Spindle Power | 1.5 kW (2.0 HP) |
| Guide Bushing | Yes, precision Swiss-type |
| Driven Tools | Yes, front and back |
| Driven Tool Speed | Up to 6,000 RPM |
| Tool Positions | Up to 18 |
| CNC Control | Fanuc 32i |
| Machine Dimensions | Approx. 1,700 x 1,100 x 1,650 mm |
| Machine Weight | Approx. 1,700 kg (3,748 lbs) |
Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.
Strengths & Limitations
Strengths
- Main spindle listed at up to 15,000 rpm for small-diameter stock
- Back spindle at up to 10,000 rpm with 1.5 kW (2.0 hp)
- Driven tools on both front and back sides, up to 6,000 rpm
- Up to 18 tool positions with 7-axis simultaneous control
- Small and light: approx. 1,700 x 1,100 x 1,650 mm and approx. 1,700 kg (3,748 lbs)
Limitations
- Bar capacity is 16 mm (0.630 in) and machining length 150 mm (5.91 in)
- Main spindle power is 2.2 kW (3.0 hp), which suits free-cutting materials and light cuts, not heavy stock removal
- The 18 tool positions are not broken down and no stroke or driven-tool power is listed, so tooling for a given part cannot be judged from the table alone
Best For
Frequently Asked Questions
01
The listed maximum bar capacity and maximum machining diameter are both 16 mm (0.630 in). Maximum machining length is 150 mm (5.91 in). A precision Swiss-type guide bushing is listed.
02
The main spindle is listed at up to 15,000 rpm with 2.2 kW (3.0 hp). The back spindle is listed at up to 10,000 rpm with 1.5 kW (2.0 hp). Driven tools run up to 6,000 rpm.
03
Yes. The listed figures show driven tools on both the front and the back, running up to 6,000 rpm, within a total of up to 18 tool positions. The table does not say how many of those positions are driven, or their power.
04
The table gives approximate figures: machine dimensions of about 1,700 x 1,100 x 1,650 mm and a weight of about 1,700 kg (3,748 lbs). Allow extra length for a bar feeder.
