Haas ST-10

List US$64,995 Specs verified 2026-10-02 · haascnc.com Updated 2026-10-02

Image: haascnc.com, Haas Automation

Key Specifications

X Travel

7.88 in (200 mm)

Z Travel

16 in (406 mm)

Max Spindle

6,000 rpm

Rapid Traverse

1,200 ipm (30.5 m/min)

Spindle Power

15 hp (11.2 kW)

Max Turn Length

16 in (406 mm)

How much does the Haas ST-10 cost?

Manufacturer list price

US$64,995

As published by Haas Automation, verified 2026-10-02. Options, tooling, freight and installation are extra.

Overview

The Haas ST-10 is a compact two-axis turning center: a 6.5 in (165 mm) chuck, 1.75 in (44 mm) of bar capacity, 16 in (406 mm) of Z travel and a 15 hp (11.2 kW) spindle that reaches 6,000 rpm. It is the high-speed, small-bore machine of this frame size, and that combination points it at small parts from bar.

The ST-15 shows the trade Haas offers on the same travels. The ST-15 has an 8.3 in (210 mm) chuck, 2.5 in (64 mm) of bar capacity and twice the torque, 150 ft-lbf (203 N·m) at 500 rpm, but its speed stops at 4,000 rpm. The ST-10 delivers 75 ft-lbf (102 N·m) at 1,300 rpm on an A2-5 nose with a 2.31 in (58.7 mm) bore. On small bar a top speed 50% above the ST-15's is worth more than the torque, because small diameters need spindle speed to reach a proper surface speed.

How large a part it turns depends on the turret. The table gives 12 in (305 mm) as the maximum turning diameter, 11 in (279 mm) with a BMT45 turret and 6.8 in (173 mm) with a VDI turret, under a 16.5 in (419 mm) swing. The turret row reads 12-station BOT, and OD and ID tools can go in any combination. Rear clearance for boring bars is 0.75 in (19.1 mm), so plan long bars around what sits behind the turret.

Both axes rapid at 1,200 ipm (30.5 m/min) and are rated for 3,300 lbf (14,679 N) of thrust. The table also holds tailstock figures (MT3 taper, 3.8 in (95 mm) of hydraulic quill travel, 140 to 1,130 lbf (623 to 5,026 N) of quill thrust) and a block of sub-spindle figures: a 5.3 in (135 mm) chuck on an A2-5 nose, 6,000 rpm, synchronised with the main spindle up to 4,800 rpm. Ask Haas which of these the quoted machine includes.

The ST-10 runs on 40 A at 220 VAC or 20 A at 440 VAC three-phase and carries 30 gal (114 L) of coolant. It ships at 7,900 lb (3,585 kg) on a 126 × 70 × 81 in (320 × 178 × 206 cm) pallet. Haas lists a starting price of US$64,995.

Full Specifications

Parameter	Value
Chuck Size	6.5 in (165 mm)
Max Swing	16.5 in (419 mm)
Max Turning Diameter	12 in (305 mm)
Max Turning Diameter with Bmt45 Turret	11 in (279 mm)
Max Turning Diameter with VDI Turret	6.8 in (173 mm)
Max Turning Length	16 in (406 mm)
Bar Capacity	1.75 in (44 mm)
X-Axis Travel	7.88 in (200 mm)
Z-Axis Travel	16 in (406 mm)
Rapid Traverse Rate	1,200 ipm (30.5 m/min)
Max Thrust X	3,300 lbf (14,679 N)
Max Thrust Z	3,300 lbf (14,679 N)
Spindle Nose	A2-5
Spindle Motor Power	15 hp (11.2 kW)
Max Spindle Speed	6,000 rpm
Spindle Torque	75 ft-lbf @ 1,300 rpm (102 N·m @ 1,300 rpm)
Spindle Bore	2.31 in (58.7 mm)
Sub Spindle Chuck Size	5.3 in (135 mm)
Sub Spindle Nose	A2-5
Sub Spindle Speed	6,000 rpm
Sub Spindle Max Sync Speed with Main Spindle	4,800 rpm
Sub Spindle Chuck Throat	Ø 1.3 in × 1.37 in DEEP (Ø 33 mm × 34.8 mm DEEP)
Sub Spindle Drawbar Bore	Ø 1 in × 4.5 in DEEP (Ø 25.4 mm × 114.3 mm DEEP)
Sub Spindle Spindle Bore	1.5 in (38.1 mm)
Sub Spindle Integrated Brake Torque	17 ft-lbf (23 N·m)
Sub Spindle Spindle Orientation Accuracy	± 0.02 °
Sub Spindle Rapids	400 ipm (10 m/min)
Tailstock Taper	MT3
Tailstock Hydraulic Quill Travel	3.8 in (95 mm)
Tailstock Manual Body Positioning	20 in (508 mm)
Tailstock Max Thrust Hyd Quill Only	1,130 lbf (5,026 N)
Tailstock Min Thrust Hyd Quill Only	140 lbf (623 N)
Turret Stations	12-Station BOT
Turret OD Vs ID Tools	Any Combination (will vary with turret)
Turret Boring Bar Rear Clearance	0.75 in (19.1 mm)
Coolant Capacity	30 gal (114 L)
Air Required	4 scfm @ 100 psi (113 L/min @ 6.9 bar)
Inline Air Hose	3/8 in
Air Coupler	3/8 in
Air Pressure Min	80 psi (5.5 bar)
Electrical Service (low voltage)	220 VAC 3-phase, 40 A
Electrical Service (high voltage)	440 VAC 3-phase, 20 A
Shipping Domestic Pallet	126 × 70 × 81 in (320 × 178 × 206 cm)
Shipping Export Pallet	126 × 70 × 81 in (320 × 178 × 206 cm)
Machine Weight	7,900 lb (3,585 kg)

Specifications sourced from haascnc.com — verified 2026-10-02

Strengths & Limitations

Strengths

6,000 rpm spindle, 50% faster than the 4,000 rpm of the ST-15 on the same travels
1,200 ipm (30.5 m/min) rapids on both X and Z
12 in (305 mm) maximum turning diameter and 16.5 in (419 mm) swing from a machine that ships at 7,900 lb (3,585 kg)
Runs from a 40 A supply at 220 VAC three-phase, or 20 A at 440 VAC
1.75 in (44 mm) bar capacity through a 2.31 in (58.7 mm) spindle bore

Limitations

75 ft-lbf (102 N·m) of torque at 1,300 rpm, half the 150 ft-lbf (203 N·m) of the ST-15
Bar capacity stops at 1.75 in (44 mm); the ST-15 takes 2.5 in (64 mm)
A VDI turret cuts the maximum turning diameter to 6.8 in (173 mm), and a BMT45 turret to 11 in (279 mm)
Only 0.75 in (19.1 mm) of rear clearance behind the turret for boring bars
No live tooling, C axis or Y axis in the table; the ST-10Y adds ± 2 in (± 51 mm) of Y and 4,000 rpm live tools

Best For

Small bar parts up to 1.75 in (44 mm) at spindle speeds to 6,000 rpm Short chuck work within 16 in (406 mm) of turning length Brass, aluminium and plastic parts that need high surface speed on small diameters Shops with a limited three-phase supply: 40 A at 220 VAC

Frequently Asked Questions

01 What is the difference between the ST-10 and the ST-15?

The spindle. Both have 7.88 in (200 mm) of X travel, 16 in (406 mm) of Z and a 16.5 in (419 mm) swing. The ST-10 has a 6.5 in (165 mm) chuck, an A2-5 nose, 1.75 in (44 mm) of bar capacity and 15 hp (11.2 kW) at up to 6,000 rpm. The ST-15 has an 8.3 in (210 mm) chuck, an A2-6 nose, 2.5 in (64 mm) of bar capacity and 20 hp (14.9 kW) at up to 4,000 rpm.

02 How does the turret choice affect the ST-10's turning diameter?

The table gives three figures: 12 in (305 mm) maximum turning diameter, 11 in (279 mm) with a BMT45 turret and 6.8 in (173 mm) with a VDI turret. If the work is near the top of that range, settle the turret type before ordering.

03 How long a part can the ST-10 turn?

16 in (406 mm), which is also the Z travel. For longer parts the ST-10L has 32.5 in (826 mm) of turning length with the same chuck, bar capacity and 6,000 rpm spindle, and it ships at 10,000 lb (4,536 kg) where the ST-10 ships at 7,900 lb (3,585 kg).

04 What are the sub-spindle figures in the ST-10 table?

A 5.3 in (135 mm) chuck on an A2-5 nose with a 1.5 in (38.1 mm) spindle bore, 6,000 rpm maximum, 4,800 rpm maximum when synchronised with the main spindle, and 400 ipm (10 m/min) rapids. The brake holds 17 ft-lbf (23 N·m) and orientation accuracy is ± 0.02°. Confirm with Haas whether the machine you are quoted carries it.

05 What power and air supply does the ST-10 need?

220 VAC three-phase at 40 A, or 440 VAC three-phase at 20 A. Air consumption is 4 scfm at 100 psi (113 L/min at 6.9 bar) and supply pressure must not fall below 80 psi (5.5 bar). The air hose and coupler are 3/8 in.
