Techni Waterjet i-510 CNC Waterjet System
Key Specifications
machine size l x w x h
cutting area
machine type
accuracy of motion
max material thickness
How much does the Techni Waterjet i-510 CNC Waterjet System cost?
Estimated price range
Our best estimate for a cnc waterjet cutting in this class — not a quote from Techni Waterjet. Configuration moves it a long way.
Overview
The Techni Waterjet i-510 CNC Waterjet System is a cantilever waterjet with a 1525 x 3050 mm (60" x 120") cutting area and a maximum material thickness of 200 mm (8"). Techni Waterjet lists its accuracy of motion at ±0.12 mm (0.005").
Cantilever is the machine type given, which means the beam carrying the cutting head is supported from one side instead of bridging the tank on two rails. In general that leaves the opposite long side and the ends open, which makes loading sheet by crane or forklift easier. The cutting area takes one 1525 x 3050 mm (60" x 120") sheet with no room to spare, so larger stock has to be cut down first.
The machine itself measures 4200 x 2350 x 2050 mm (165" x 92" x 80.7") in length, width and height. Allow for the pump, the control and loading access around that when laying out the floor, none of which the table describes. Pump pressure, pump power, traverse speed and weight are not among the figures Techni Waterjet gives for this model on the cited page, so ask for them with the quotation.
Full Specifications
| Parameter | Value |
|---|---|
| Machine Size L X W X H | 4200 x 2350 x 2050 mm (165” x 92” x 80.7”) |
| Cutting Area | 1525 x 3050 mm (60" x 120") |
| Machine Type | Cantilever |
| Accuracy of Motion | ±0.12 mm (0.005") |
| Max Material Thickness | 200 mm (8") |
Specifications sourced from techniwaterjet.com — verified 2026-10-03
Strengths & Limitations
Strengths
- 1525 x 3050 mm (60" x 120") cutting area on a cantilever frame
- Maximum material thickness of 200 mm (8")
- Machine size of 4200 x 2350 x 2050 mm (165" x 92" x 80.7") is stated, so floor planning can start from a real figure
Limitations
- Accuracy of motion is ±0.12 mm (0.005"), a motion figure and not a finished-part tolerance
- The 1525 x 3050 mm (60" x 120") cutting area leaves no margin around a sheet of that size
- No pump, speed or weight figures are given for this model on the maker's page
Best For
Frequently Asked Questions
01
1525 x 3050 mm (60" x 120"), with a maximum material thickness of 200 mm (8"). The machine frame is larger than the cutting area: Techni Waterjet gives its size as 4200 x 2350 x 2050 mm (165" x 92" x 80.7") in length, width and height.
02
Techni Waterjet lists accuracy of motion as ±0.12 mm (0.005"). That describes how closely the cutting head follows the programmed path. The edge of a cut part also depends on the jet itself, so thick material and fast cutting will show more deviation than the motion figure alone suggests.
03
It is the machine type Techni Waterjet gives for the i-510. On a cantilever waterjet the beam that carries the cutting head is supported from one side of the tank, not from both. That generally leaves the other side clear for loading and unloading material.
