Quintax 5-Axis CNC Composite Router
This model was not found in Quintax's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.
Key Specifications
X Travel
Y Travel
Z Travel
Table Size
Spindle Power
Accuracy
How much does the Quintax 5-Axis CNC Composite Router cost?
Estimated price range
Our best estimate for a cnc router in this class — not a quote from Quintax. Configuration moves it a long way.
Overview
The Quintax 5-Axis CNC Composite Router is a large-format trimming machine with an A/C head, listed with 4400 mm (173.2 in) of X travel, 3800 mm (149.6 in) of Y and 1500 mm of Z. No model of this name is in Quintax's current lineup, and the table comes from a third-party listing, so the listed figures are a starting point to confirm against the build sheet of any machine on offer.
Much of the table is written as ranges. The spindle is a 22 – 37 kW direct-drive electrospindle running up to 30,000 RPM on an HSK-63A interface, the drives are linear motors or ballscrew/servo depending on the table, and table size runs from 5x10 ft to 30x15 ft in custom configurations. Each machine is therefore one build inside those ranges, and the single set of travels quoted above cannot describe all of them.
What sets the layout apart from a flat-sheet router is the Z stroke. With 1500 mm of vertical travel and a head listed for full contouring on double-curvature surfaces, it is arranged for trimming and drilling deep moulded shells. The listed materials are CFRP, fiberglass, honeycomb sandwich, Kevlar and aluminum.
Positioning accuracy is listed as ±0.05 mm (±0.002 in) across the full table, and the control as Siemens 840D sl with RTCP. A compliance row names a quality standard and an export registration; those describe a company rather than a machine and say nothing about the calibration of an individual router.
Full Specifications
| Parameter | Value |
|---|---|
| Table Size | 5x10 ft to 30x15 ft (custom configurations) |
| Spindle Motor Power | 22 – 37 kW direct-drive electrospindle |
| Spindle Speed | Up to 30,000 RPM |
| 5 Axis Head | A/C axis, full contouring on double-curvature surfaces |
| Tooling Interface | HSK-63A |
| Positioning Accuracy | ±0.05 mm (±0.002 in) across full table |
| Drive System | Linear motors or ballscrew/servo (table dependent) |
| CNC Control | Siemens 840D sl with RTCP |
| Materials | CFRP, fiberglass, honeycomb sandwich, Kevlar, aluminum |
| Compliance | AS9100, ITAR-registered |
| X-Axis Travel | 4400 mm (173.2 in) |
| Y-Axis Travel | 3800 mm (149.6 in) |
| Z-Axis Travel | 1500 mm |
Specifications sourced from machinio.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Listed Z travel of 1500 mm gives the vertical stroke that deep moulded parts and tall trim fixtures need
- A/C-axis head listed for full contouring on double-curvature surfaces
- Direct-drive electrospindle listed at 22 – 37 kW and up to 30,000 RPM on an HSK-63A interface
- Listed positioning accuracy of ±0.05 mm (±0.002 in) across the full table
- Control listed as Siemens 840D sl with RTCP, so tool-centre-point programming is part of the listed build
Limitations
- Not in Quintax's current lineup, and the figures come from a third-party listing that has not been confirmed
- Spindle power, drive system and table size are listed as ranges or alternatives, so every machine has to be checked individually
- One set of travels sits beside table sizes from 5x10 ft to 30x15 ft, so the travels cannot apply to every size
- The table gives no rapid traverse, feed rate, tool changer capacity or machine weight
Best For
Frequently Asked Questions
01
The listed figures are 4400 mm (173.2 in) in X, 3800 mm (149.6 in) in Y and 1500 mm in Z. Table size is listed separately as 5x10 ft to 30x15 ft in custom configurations, so the travels describe one configuration only. Measure the actual strokes of any machine you are considering.
02
The table lists a direct-drive electrospindle of 22 – 37 kW running up to 30,000 RPM, with an HSK-63A tooling interface. Because power is given as a range, the rating of an individual machine has to be read from its spindle plate or build sheet.
03
No. A model under this name is not in Quintax's current lineup, and the specification shown here comes from a third-party listing. Treat the listed figures as unconfirmed and ask the seller for the original build documentation, since table size, spindle power and drive system were all configured per machine.
04
The materials row names CFRP, fiberglass, honeycomb sandwich, Kevlar and aluminum. The A/C head is described as giving full contouring on double-curvature surfaces, which matches trimming and drilling of moulded composite parts rather than flat nesting work.
05
Positioning accuracy is listed as ±0.05 mm (±0.002 in) across the full table. The control is listed as Siemens 840D sl with RTCP. Axis drives are given as linear motors or ballscrew/servo depending on the table, so the drive type of a specific machine should be confirmed.
