Prima Power Syncrono

Est. $500,000 - $900,000 Possible older model Specs verified 2026-03-28 · machinetools.com Updated 2026-10-03

This model was not found in Prima Power's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.

Key Specifications

Accuracy

±0.05 mm

Repeatability

±0.03 mm

working area

3000 x 1500 mm (standard); 4020 and 6020 mm formats available

laser type

Fiber

laser power

2 kW, 4 kW, or 6 kW

max sheet thickness mild steel

15 mm (6 kW)

How much does the Prima Power Syncrono cost?

Estimated price range

Est.$500,000 - $900,000

Our best estimate for a cnc laser cutting machine in this class — not a quote from Prima Power. Configuration moves it a long way.

Overview

The Prima Power Syncrono is a fiber laser cutting machine built around an unusual motion scheme: the table describes it as 2D dynamic, with the head moving in X and Y at the same time as the bridge that carries it. The model is absent from Prima Power's current lineup, so take the listed figures as a guide to an older machine and confirm them unit by unit.

The point of moving head and bridge together is acceleration. A small head axis can change direction far faster than a full bridge, so the short moves between holes and corners fall to the head while the bridge covers the sheet. The listed results are up to 170 m/min combined dynamic speed and up to 5 g combined dynamic acceleration. Those numbers pay off on thin sheet full of small features. On long straight cuts in plate they matter much less.

Laser power is listed as 2 kW, 4 kW, or 6 kW. With 6 kW the listed limits are 15 mm in mild steel and 10 mm in stainless, and copper and brass are each listed to 4 mm. That is thin-to-medium territory, in keeping with a machine laid out for speed in light gauges.

The standard working area is 3000 x 1500 mm, with 4020 and 6020 mm formats listed as available, and the maximum sheet weight is 920 kg (3015 format). Positioning accuracy is listed as ±0.05 mm and repeatability as ±0.03 mm.

Full Specifications

Parameter	Value
Working Area	3000 x 1500 mm (standard); 4020 and 6020 mm formats available
Laser Type	Fiber
Laser Power	2 kW, 4 kW, or 6 kW
Max Sheet Thickness Mild Steel	15 mm (6 kW)
Max Sheet Thickness Stainless	10 mm (6 kW)
Max Sheet Thickness Copper	4 mm
Max Sheet Thickness Brass	4 mm
Head Kinematics	2D dynamic — simultaneous X+Y head and bridge motion
Max Axis Speed	up to 170 m/min combined dynamic
Max Acceleration	up to 5 g (combined dynamic)
Positioning Accuracy	±0.05 mm
Repeatability	±0.03 mm
Max Sheet Weight	920 kg (3015 format)

Specifications sourced from machinetools.com — verified 2026-03-28

Strengths & Limitations

Strengths

Head and bridge move together in X and Y, a layout the table calls 2D dynamic
Listed at up to 170 m/min combined dynamic speed and up to 5 g combined dynamic acceleration
Fiber source listed as 2 kW, 4 kW, or 6 kW
3000 x 1500 mm standard working area, with 4020 and 6020 mm formats listed as available
Listed repeatability of ±0.03 mm and positioning accuracy of ±0.05 mm

Limitations

Listed thickness limits are modest even at 6 kW: 15 mm in mild steel and 10 mm in stainless
Copper and brass are listed only to 4 mm
Sheet weight is limited to 920 kg (3015 format)
The 170 m/min and 5 g figures are combined-dynamic maximums, not what a single axis delivers

Best For

Thin sheet with many holes and small features, where up to 5 g acceleration counts Mild steel up to 15 mm and stainless up to 10 mm at 6 kW Sheets of 3000 x 1500 mm weighing up to 920 kg (3015 format) Copper and brass sheet up to 4 mm

Frequently Asked Questions

01 What makes the Syncrono different from a conventional laser cutter?

Its head kinematics. The table lists them as 2D dynamic, with simultaneous X+Y head and bridge motion, and gives up to 170 m/min combined dynamic speed and up to 5 g combined dynamic acceleration. The gain is on parts with many short moves, where acceleration decides the cycle time.

02 How thick can the Syncrono cut?

The listed limits are 15 mm in mild steel (6 kW) and 10 mm in stainless (6 kW), with copper and brass each at 4 mm. Laser power is listed as 2 kW, 4 kW, or 6 kW, and no limits are given for the two lower powers.

03 What sheet sizes does the Syncrono take?

The standard working area is listed as 3000 x 1500 mm, and 4020 and 6020 mm formats are listed as available. Maximum sheet weight is 920 kg (3015 format); no sheet weight is given for the larger formats.

04 How accurate is the Syncrono?

Positioning accuracy is listed as ±0.05 mm and repeatability as ±0.03 mm. Those are axis figures for the machine; the tolerance held on a cut part also depends on material, thickness and cutting parameters.
