Makino MAG A5
This model was not found in Makino's current lineup when we checked on 2026-09-24 (lineup page). It may be a superseded or older model; the specifications below are as we last recorded them.
Key Specifications
X Travel
Y Travel
Z Travel
Max Spindle
Spindle Taper
Tool Capacity
How much does the Makino MAG A5 cost?
Estimated price range
Our best estimate for a 5-axis machining center in this class — not a quote from Makino. Configuration moves it a long way.
Overview
Makino does not show the MAG A5 in its current lineup; it may be an older model, and the figures on this page are unverified listed values. According to them, the MAG A5 is a gantry-type 5-axis machine with a fixed table, about 5,000 mm (196.9 in) of X, 2,500 mm (98.4 in) of Y and 1,000 mm (39.4 in) of Z, carrying a 33,000 RPM spindle with an HSK-A63 taper.
No current Makino machine sits at that length. The MAG3.EX and MAG4 stop at 4,000 mm (157.5 in) of X, and the MAG.A6 starts at 6,200 mm (244.1 in) with a 6,000 x 2,000 mm (236.0 in x 78.7 in) pallet. That alone is a reason to check the identity of any machine offered under this name: its plate, its parameter list and its original documentation should agree before the listed figures are relied on.
The remaining listed rows describe a direct-drive A axis of +30° to -120° (150° total, direct drive), a continuous 360° C axis, about 80 kW (107 hp) of spindle power and 120 tools standard. X and Y rapid at 60 m/min (2,362 ipm) and Z at 50 m/min (1,969 ipm). Chips leave through a full-length through-table chip conveyor system, and the control is given as Makino Professional 6 (Pro 6). Every travel figure is marked approximate.
Full Specifications
| Parameter | Value |
|---|---|
| X-Axis Travel | ~5,000 mm (196.9 in) |
| Y-Axis Travel | ~2,500 mm (98.4 in) |
| Z-Axis Travel | ~1,000 mm (39.4 in) |
| A Axis Range | +30° to -120° (150° total, direct drive) |
| C Axis Range | 360° (continuous, direct drive) |
| Max Spindle Speed | 33,000 RPM |
| Spindle Taper | HSK-A63 |
| Spindle Motor Power | ~80 kW (107 hp) |
| Tool Capacity | 120 tools standard |
| Table Configuration | Fixed table, moving gantry column |
| Rapid Traverse Xy | 60 m/min (2,362 ipm) |
| Rapid Traverse Z | 50 m/min (1,969 ipm) |
| Chip Evacuation | Full-length through-table chip conveyor system |
| CNC Control | Makino Professional 6 (Pro 6) |
Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.
Strengths & Limitations
Strengths
- Listed X travel of about 5,000 mm (196.9 in) on a fixed table
- 33,000 RPM HSK-A63 spindle in the listed table
- Full-length through-table chip conveyor system listed
- Listed rapids of 60 m/min (2,362 ipm) on X and Y
Limitations
- Not in Makino's current lineup; the listed figures have not been verified
- All three travels are marked approximate
- No current Makino model matches its listed length, which makes identification harder
Best For
Frequently Asked Questions
01
No. It is not in Makino's current lineup and may be an older model. The listed figures could not be checked against a Makino specification, so verify them from the machine and its documentation.
02
About 5,000 mm (196.9 in) in X, 2,500 mm (98.4 in) in Y and 1,000 mm (39.4 in) in Z, all marked approximate, on a fixed table with a moving gantry column.
03
The MAG4 has 4,000 mm (157.5 in) of X and 2,200 mm (86.6 in) of Y on a 3,500 x 2,000 mm (137.8 in x 78.7 in) pallet. The MAG.A6 has 6,200 mm (244.1 in) of X and 2,200 mm (86.6 in) of Y on a 6,000 x 2,000 mm (236.0 in x 78.7 in) pallet. Both run 33,000 rpm spindles.
04
A 33,000 RPM spindle with an HSK-A63 taper and about 80 kW (107 hp), and 120 tools standard. The listed control is Makino Professional 6 (Pro 6).
