KMT Waterjet Streamline SL-V 100
This model was not found in KMT Waterjet's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.
Key Specifications
Weight
pump power
max operating pressure
flow rate at max pressure
intensification ratio
pressure fluctuation
How much does the KMT Waterjet Streamline SL-V 100 cost?
Estimated price range
Our best estimate for a cnc waterjet cutting in this class — not a quote from KMT Waterjet. Configuration moves it a long way.
Overview
The KMT Waterjet Streamline SL-V 100 is a 100 hp (75 kW) hydraulic intensifier pump listed at a maximum operating pressure of 60,000 psi (4,137 bar), with 7.6 L/min of flow at that pressure. It does not appear in KMT Waterjet's current lineup and may be an older model. The listed figures could not be checked against a maker page, so read them alongside the nameplate and manual of any unit on offer.
The hydraulic side explains most of the table. The intensification ratio is 20:1, meaning the water end runs at twenty times the pressure of the oil that drives it. That oil sits in a 208 L reservoir and gives up its heat through a water-cooled heat exchanger, so the installation needs a cooling water supply as well as the cutting water feed. Pressure fluctuation is listed as < 0.5%. A steady supply matters because pressure ripple shows up as marks on the cut edge.
Flow decides what the pump can feed. All the orifices in use draw from the same 7.6 L/min, and the table lists neither a head count nor an orifice size, so that sum has to be done from the orifice chart for the heads on the table.
For site planning, the supply is 460V or 380V, 3-phase, 50–60 Hz. The unit measures 2,200 x 900 x 1,600 mm and weighs approximately 1,800 kg. The control interface is a PLC with alarm outputs and hour metering, and on a used pump the hour meter is the first reading to ask for. Certifications are listed as CE, UL and ISO 9001.
Full Specifications
| Parameter | Value |
|---|---|
| Pump Power | 100 hp (75 kW) |
| Max Operating Pressure | 60,000 psi (4,137 bar) |
| Flow Rate at Max Pressure | 7.6 L/min |
| Intensification Ratio | 20:1 |
| Pressure Fluctuation | < 0.5% |
| Electrical Supply | 460V or 380V / 3-phase / 50–60 Hz |
| Cooling Method | Water-cooled heat exchanger |
| Hydraulic Fluid Volume | 208 L reservoir |
| Dimensions L X W X H | 2,200 x 900 x 1,600 mm |
| Machine Weight | approximately 1,800 kg |
| Control Interface | PLC with alarm outputs and hour metering |
| Certifications | CE, UL, ISO 9001 |
Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.
Strengths & Limitations
Strengths
- 100 hp (75 kW) intensifier delivering 7.6 L/min at 60,000 psi (4,137 bar)
- Pressure fluctuation is listed as < 0.5%
- Runs on a 460V or 380V three-phase supply at 50–60 Hz
- PLC control with alarm outputs and hour metering, which gives a used unit a readable running-hours record
- Listed certifications are CE, UL and ISO 9001
Limitations
- The listed figures are unverified, so the nameplate of the actual unit has the final word
- Needs cooling water for the heat exchanger and carries a 208 L hydraulic reservoir to maintain
- Maximum operating pressure is 60,000 psi (4,137 bar), with no higher rating in the table
- At approximately 1,800 kg and 2,200 x 900 x 1,600 mm it needs a planned floor position and lifting gear
- No seal life or service interval is listed
Best For
Frequently Asked Questions
01
The listed figures are 7.6 L/min at a maximum operating pressure of 60,000 psi (4,137 bar), from a 100 hp (75 kW) drive. That flow is the total for every cutting head connected to the pump. The table does not say how many heads it is intended for.
02
It is the ratio between the water pressure the pump produces and the hydraulic oil pressure that drives the intensifier. At 20:1 the water end reaches twenty times the oil pressure. The oil circuit on this pump holds 208 L in its reservoir and is cooled by a water-cooled heat exchanger.
03
Electrical supply is listed as 460V or 380V, 3-phase, 50–60 Hz. Cooling is by a water-cooled heat exchanger, so a cooling water connection is required in addition to the cutting water. No cooling water flow or air supply figure is listed.
04
Dimensions are listed as 2,200 x 900 x 1,600 mm (length x width x height) and weight as approximately 1,800 kg. Plan the route into the building and the lifting equipment around those figures, and confirm the weight on the unit's own plate.
