Chiron FZ 15W Baseline

$250,000 - $375,000 Updated 2025-03-15

Key Specifications

X Travel

430 mm (16.9 in)

Y Travel

400 mm (15.7 in)

Z Travel

400 mm (15.7 in)

Max Spindle

20,000 RPM (high-speed options available)

Spindle Taper

HSK-A63

Tool Capacity

36 standard (basket or chain-type changer)

Overview

The Chiron FZ 15W Baseline is Chiron's entry-level 5-axis machining center, designed to bring the German manufacturer's performance DNA to shops that need production-grade 5-axis capability at a more accessible price point. The Baseline series strips away some of the premium features of the standard 15 Series — notably replacing linear direct drives with high-performance ball screws — while retaining the core platform architecture, mineral-cast bed, and integrated workpiece changer.

The FZ 15W Baseline shares the 15 Series work envelope with X/Y/Z travels of 430 x 400 x 400 mm (16.9 x 15.7 x 15.7 in) and maintains the vertical moving column principle that defines Chiron machines. The workpiece changer is integrated, providing the same loading/unloading-during-machining advantage as the standard FZ 15W. Tool changer options include basket or chain-type configurations. The machine handles workpieces up to 350 mm diameter and 150 kg.

The key difference from the standard FZ 15W is the drive system. Where the standard machine uses linear direct drives for maximum dynamics, the Baseline uses dynamic direct drives (high-performance ball screws) that deliver strong performance at a lower cost. This trade-off reduces acceleration rates and top positioning speed but keeps the machine well above conventional ball-screw performance. The mineral-cast bed and thermally stable design are retained, maintaining Chiron's precision standards.

The HSK-A63 spindle runs at up to 20,000 RPM with optional high-speed configurations. The control is Siemens SINUMERIK 840D sl. New FZ 15W Baseline machines price between $250,000 and $375,000 — roughly $50,000-$100,000 less than the standard FZ 15W. This positions the Baseline as a direct competitor to machines like the DMG Mori DMU 50, Hermle C 250, and even higher-end configurations of the Fanuc Robodrill with 5-axis table. Used Baseline units from 2019-2023 trade between $125,000 and $250,000.

The FZ 15W Baseline is Chiron's answer to shops that want the brand's engineering quality and workpiece changer productivity without paying the premium for linear direct drives. For shops machining parts where the additional dynamics of linear drives don't translate to meaningful cycle time savings, the Baseline delivers 80-90% of the performance at 70-80% of the price.

Full Specifications

Parameter	Value
X-Axis Travel	430 mm (16.9 in)
Y-Axis Travel	400 mm (15.7 in)
Z-Axis Travel	400 mm (15.7 in)
Max Spindle Speed	20,000 RPM (high-speed options available)
Spindle Taper	HSK-A63
Spindle Torque	Up to 200 Nm (148 ft-lb)
A Axis Range	Direct drive tilt axis
C Axis Range	360° continuous
Max Workpiece Diameter	350 mm (13.8 in)
Max Workpiece Weight	150 kg (330 lb)
Tool Capacity	36 standard (basket or chain-type changer)
Workpiece Changer	Integrated 2-position pallet changer
Axis Drives	Dynamic direct drives (high-performance ball screws) on X, Y, Z
Machine Bed	Mineral cast
Machine Design	Vertical moving column principle
CNC Control	Siemens SINUMERIK 840D sl
Thermal Management	Thermally stable design

Specifications sourced from chiron-group.com — verified 2026-03-28

Strengths & Limitations

Strengths

Most affordable entry to Chiron's engineering quality and German precision, priced $50,000-$100,000 below the standard FZ 15W
Integrated workpiece changer delivers 90%+ spindle utilization — the same productivity advantage as the standard FZ 15W
Mineral-cast machine bed provides superior vibration damping and thermal stability compared to cast-iron competitors at this price
Vertical moving column design minimizes thermal drift and maintains accuracy across production runs
Compact footprint suitable for dense production cell layouts where floor space is premium
Basket or chain-type tool changer options provide flexibility for different production requirements

Limitations

Ball-screw drives instead of linear direct drives result in lower acceleration and positioning speed than the standard FZ 15W
430 mm X-travel limits the Baseline to small parts, same as the standard 15 Series
Tool capacity is more limited than competitors like the DMG Mori DMU 50 with larger magazine options
Chiron's service network in North America is smaller than competitors at this price point (DMG Mori, Mazak, Haas)
150 kg workpiece capacity is restrictive for heavier steel and titanium blanks

Best For

Shops seeking their first Chiron machine at a more accessible price point without sacrificing the workpiece changer advantage Production environments where ball-screw dynamics are sufficient and linear direct drive premiums don't justify the cycle time savings Medical device and dental manufacturers machining small implants and components where Chiron's precision matters but ultra-high dynamics are not critical Job shops adding 5-axis capability with built-in automation that want German engineering quality at a mid-range price Contract manufacturers needing compact, automated 5-axis capacity for recurring small-part programs Shops comparing DMG Mori DMU 50 or Hermle C 250 that want an integrated workpiece changer as standard

Frequently Asked Questions

01 What does a new Chiron FZ 15W Baseline cost?

New FZ 15W Baseline machines start around $250,000 and can reach $375,000 with high-speed spindle, expanded tool magazine, probing, and coolant upgrades. This is roughly $50,000-$100,000 less than the standard FZ 15W with linear direct drives. Used units from 2019-2023 trade between $125,000 and $250,000.

02 What is the difference between Baseline and standard FZ 15W?

The primary difference is the drive system. The standard FZ 15W uses linear direct drives for maximum acceleration and zero backlash. The Baseline uses high-performance ball screws (dynamic direct drives) that are slower but more affordable. Both share the same work envelope, mineral-cast bed, workpiece changer, spindle options, and Siemens control. The Baseline delivers approximately 80-90% of the standard's dynamic performance.

03 How does the Baseline compare to the DMG Mori DMU 50?

Both are compact 5-axis machines at similar price points. The Chiron FZ 15W Baseline includes an integrated workpiece changer as standard, which the DMU 50 does not. The DMU 50 offers a larger work envelope (500 x 450 x 400 mm). The Chiron has a mineral-cast bed versus DMG Mori's cast iron. Choose the Baseline when built-in pallet automation and vibration damping are priorities; the DMU 50 when you need the larger envelope.

04 Should I buy the Baseline or save up for the standard FZ 15W?

It depends on your parts. If your cycle times are dominated by cutting time rather than rapid positioning, the Baseline's ball-screw dynamics are sufficient and the savings are better spent elsewhere. If you machine many small features with frequent rapid moves, the standard FZ 15W's linear direct drives provide meaningful cycle time reductions. Run a cycle time comparison with your specific parts to decide.

05 Is the Baseline upgradeable to linear direct drives?

No. The drive system is integral to the machine platform. You cannot retrofit linear direct drives onto a Baseline machine. If you anticipate needing linear direct drive dynamics in the future, purchase the standard FZ 15W from the start.
