Breton Matrix 800

Est. $650,000 - $1,100,000 Possible older model Updated 2026-10-03

This model was not found in Breton's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.

Key Specifications

X Travel

2,000 mm (78.7 in)

Y Travel

1,600 / 2,500 mm (63 / 98.4 in)

Z Travel

800 mm (31.5 in)

machine variants

MATRIX 800 16/25 (3 interpolated axes) and MATRIX 800/2T 16/25 (5 interpolated axes)

table length

2,000 / 3,000 mm (78.7 / 118 in)

table width

2,000 mm (78.7 in)

How much does the Breton Matrix 800 cost?

Estimated price range

Est.$650,000 - $1,100,000

Our best estimate for a 5-axis machining center in this class — not a quote from Breton. Configuration moves it a long way.

Overview

The Breton Matrix 800 is a large-table machining center listed in two variants: the MATRIX 800 16/25 with 3 interpolated axes and the MATRIX 800/2T 16/25 with 5 interpolated axes. Both have 2,000 mm (78.7 in) of X travel and 800 mm (31.5 in) of Z, with Y listed at 1,600 / 2,500 mm (63 / 98.4 in). The model is not in the maker's current lineup, so this page is written for buyers of used machines.

The table is 2,000 mm (78.7 in) wide and 2,000 / 3,000 mm (78.7 / 118 in) long, rated at 10,000 kg/m² (2,048 lb/sq ft), with T-slots 22 mm wide on a 250 mm pitch. On a used machine the first thing to establish is which Y travel and table length it was built with.

Choosing 5 axes costs height and spindle choice. Spindle-nose-to-table clearance is 1,360 mm (53.5 in) on the 3-axis machine and 1,000 mm (39.4 in) on the 5-axis one. The M100/18 spindle, listed at 137 / 100 Nm and up to 18,000 rpm on HSK-63A, is for the 3-axis variant only. The other three options are the M38/28 at 55 / 38 Nm and up to 28,000 rpm on HSK-63A, and the M16/40 and M11/40, both reaching 40,000 rpm on HSK-40E with 22 / 16 Nm and 15 / 11 Nm.

On the 5-axis variant A is listed at ±105° with a 12 rpm rapid and C is continuous at 19 rpm. Linear rapids are 40 / 40 / 20 m/min (1,575 / 1,575 / 787 ipm) on X, Y and Z. Linear positioning accuracy is listed as ±0.007 mm/m and repeatability as ±0.005 mm/m.

For installation the listed figures are a minimum weight of 26,000 – 30,000 kg (57,200 – 66,000 lb), overall dimensions of 5,150 x 3,100 / 4,100 x 3,950 mm, and total installed power of 45 kW (60 hp) for 3 axes or 55 kW (74 hp) for 5.

Full Specifications

Parameter	Value
Machine Variants	MATRIX 800 16/25 (3 interpolated axes) and MATRIX 800/2T 16/25 (5 interpolated axes)
Table Length	2,000 / 3,000 mm (78.7 / 118 in)
Table Width	2,000 mm (78.7 in)
Table Loading Capacity	10,000 kg/m² (2,048 lb/sq ft)
T-Slots	22 mm width / 250 mm pitch
X-Axis Travel	2,000 mm (78.7 in)
Y-Axis Travel	1,600 / 2,500 mm (63 / 98.4 in)
Z-Axis Travel	800 mm (31.5 in)
Spindle Nose to Table Clearance	1,360 mm (53.5 in) 3-axis; 1,000 mm (39.4 in) 5-axis
Rapid Feedrate Xyz	40 / 40 / 20 m/min (1,575 / 1,575 / 787 ipm)
A Axis Rotation	±105°, rapid 12 rpm (5-axis)
C Axis Rotation	continuous, rapid 19 rpm (5-axis)
Linear Axis Positioning Accuracy	±0.007 mm/m (±0.00028 in / 40 in), at 20 °C ±1°
Linear Axis Repeatability	±0.005 mm/m (±0.0002 in / 40 in)
Rotary Axis Accuracy	positioning ±0.0035°, repeatability ±0.0025°
Automatic Tool Store	30 (60) (100) (150) tools, optional; max. tool diameter 90 mm (140 / 60 mm with alternate pockets); max. length 300 mm; max. weight 10 kg
Milling Spindle Options	M100/18: 40 / 40 kW S6/S1, 137 / 100 Nm, 1 – 18,000 rpm, HSK-63A (3-axis only); M38/28: 28 / 20 kW, 55 / 38 Nm, 1 – 28,000 rpm, HSK-63A; M16/40: 55 / 40 kW, 22 / 16 Nm, 1 – 40,000 rpm, HSK-40E; M11/40: 50 / 40 kW, 15 / 11 Nm, 1 – 40,000 rpm, HSK-40E
Total Installed Power	45 kW (60 hp) 3-axis; 55 kW (74 hp) 5-axis
Compressed Air	6 bar (87 psi)
Sound Pressure Level	< 80 dBA
Machine Weight	min. 26,000 – 30,000 kg (57,200 – 66,000 lb)
Overall Dimensions Wxlxh	5,150 x 3,100 / 4,100 x 3,950 mm (202.7 x 122 / 161.4 x 155.5 in)

Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.

Strengths & Limitations

Strengths

Listed as a 3-axis machine or, as the MATRIX 800/2T, with 5 interpolated axes: A at ±105° and a continuous C
Four listed spindle options, from the M100/18 at 137 / 100 Nm to two 40,000 rpm units on HSK-40E
Table load of 10,000 kg/m² (2,048 lb/sq ft) on a table 2,000 mm (78.7 in) wide
Linear positioning accuracy listed at ±0.007 mm/m (±0.00028 in / 40 in), repeatability at ±0.005 mm/m (±0.0002 in / 40 in)
Rapid feed of 40 m/min (1,575 ipm) on X and Y
Rotary axis positioning listed at ±0.0035°, with repeatability of ±0.0025°

Limitations

The M100/18, the highest-torque spindle in the list, is for the 3-axis variant only
The automatic tool store is optional, in sizes of 30, 60, 100 or 150 tools
Z rapid is 20 m/min (787 ipm), half the 40 m/min (1,575 ipm) of X and Y
Tools are limited to 90 mm in diameter, 300 mm in length and 10 kg
The 5-axis variant has 1,000 mm (39.4 in) of spindle-nose-to-table clearance against 1,360 mm (53.5 in) on the 3-axis machine

Best For

Large moulds, models and patterns on a 2,000 mm (78.7 in) wide table High-speed finishing with the 40,000 rpm HSK-40E spindles 5-axis contouring on the MATRIX 800/2T variant 3-axis work that needs the 137 / 100 Nm of the M100/18 spindle

Frequently Asked Questions

01 What is the difference between the two Matrix 800 variants?

The MATRIX 800 16/25 has 3 interpolated axes and the MATRIX 800/2T 16/25 has 5. The 5-axis variant adds A at ±105° and a continuous C, has 1,000 mm (39.4 in) of spindle-nose-to-table clearance where the 3-axis machine has 1,360 mm (53.5 in), and is listed at 55 kW (74 hp) total installed power against 45 kW (60 hp).

02 Which spindles are listed for the Matrix 800?

Four. The M100/18 gives 137 / 100 Nm up to 18,000 rpm on HSK-63A and is for the 3-axis variant only. The M38/28 gives 55 / 38 Nm up to 28,000 rpm on HSK-63A. The M16/40 gives 22 / 16 Nm and the M11/40 gives 15 / 11 Nm, both up to 40,000 rpm on HSK-40E.

03 How large is the Matrix 800 table and what load does it take?

The table is 2,000 mm (78.7 in) wide and either 2,000 or 3,000 mm (78.7 / 118 in) long. Loading capacity is listed as 10,000 kg/m² (2,048 lb/sq ft), and the T-slots are 22 mm wide on a 250 mm pitch.

04 How many tools does the Matrix 800 hold?

The automatic tool store is listed as optional, with 30, 60, 100 or 150 tools. Maximum tool diameter is 90 mm, maximum length 300 mm and maximum weight 10 kg. A used machine may have been delivered without a tool store, so check.

05 What services and space does the Matrix 800 need?

Total installed power is 45 kW (60 hp) on the 3-axis variant and 55 kW (74 hp) on the 5-axis one, with compressed air at 6 bar (87 psi). Overall dimensions are listed as 5,150 x 3,100 / 4,100 x 3,950 mm (202.7 x 122 / 161.4 x 155.5 in), and the weight as a minimum of 26,000 – 30,000 kg (57,200 – 66,000 lb).
