WaterJet Sweden I-Cut 2040

$240,000 - $340,000 Updated 2026-03-17

Key Specifications

Table Size

2,100 x 4,100 mm (nominal)

Accuracy

±0.05 mm

cutting area

2,000 x 4,000 mm (78.7" x 157.5")

pump pressure

Up to 4,000 bar (58,000 psi)

pump power

45 kW or 55 kW (direct-drive)

cutting speed

Up to 10,000 mm/min (rapid); material-dependent cutting feed

Overview

The WaterJet Sweden I-Cut 2040 is a large-format CNC abrasive waterjet cutting system offering a 2,000 mm x 4,000 mm cutting envelope — one of the most commonly requested table sizes in industrial waterjet applications worldwide. This expanded worktable allows fabricators and manufacturers to process full standard sheets of steel, aluminum, and stainless steel in a single setup, eliminating the need for repositioning and improving throughput on high-volume production work.

Built on the same proven I-Cut platform as the 1530, the I-Cut 2040 features WaterJet Sweden's robust all-welded steel frame construction with precision-machined mounting surfaces for the gantry rails. The extended X-axis travel of 4,000 mm is supported by dual-drive servo motors on both sides of the bridge to ensure synchronized motion across the full travel length, preventing the yaw error that can affect single-sided drive systems on longer travel machines. Linear guides and precision ball screws or rack-and-pinion drives deliver positioning accuracy consistent with the I-Cut line's reputation.

The I-Cut 2040 is designed to accept WaterJet Sweden's ultra-high-pressure pump systems operating at up to 4,000 bar (58,000 psi), typically in the 45 kW to 55 kW range for production-intensity use. Higher pump power is particularly beneficial on the larger format machine, where operators are more likely to run multiple simultaneous cutting heads to maximize table utilization — a configuration that the I-Cut 2040's electrical and hydraulic infrastructure is engineered to support. Dual-head configurations can significantly reduce per-part cycle time on nested sheet runs.

The CNC controller provided with the I-Cut 2040 is the same WaterJet Sweden proprietary platform used across the I-Cut series, offering a consistent operator experience for shops running multiple machines. The software includes advanced nesting algorithms particularly valuable on the 2040's larger sheet area, where sheet utilization optimization directly impacts material costs. Taper correction, lead-in/lead-out optimization, and automatic pierce sequencing are all handled in the controller without requiring a separate CAM post-processor.

The I-Cut 2040 targets medium-to-large fabrication operations, steel service centers, architectural metalwork shops, and manufacturers in aerospace, defense, and energy sectors where large plate processing is routine. Its ability to handle full 2 m x 4 m sheets of steel plate, stainless, aluminum, and specialty alloys in a single operation, combined with WaterJet Sweden's emphasis on machine rigidity and long-term geometric stability, makes it a productive and reliable asset for facilities with high throughput demands.

Full Specifications

Parameter	Value
Cutting Area	2,000 x 4,000 mm (78.7" x 157.5")
Pump Pressure	Up to 4,000 bar (58,000 psi)
Pump Power	45 kW or 55 kW (direct-drive)
Cutting Speed	Up to 10,000 mm/min (rapid); material-dependent cutting feed
Positioning Accuracy	±0.05 mm
Max Material Thickness	Up to 200 mm (material-dependent)
Table Size	2,100 x 4,100 mm (nominal)
Water Flow Rate	~4.5 L/min at max pressure
CNC Control	WaterJet Sweden proprietary CNC with touchscreen, nesting software, DXF/DWG import
Machine Weight	~9,500 kg
10 0 X 5 2	3.04 m x 1.57 m
13 4 X 6 8	4.06 m x 2.03 m
2 1 X 2 1	0.63 m x 0.63 m
2 2 X 2 2	0.66 m x 0.66 m
4 4 X 2 2	1.32 m x 0,66 m
4 7 X 4 7	1.39 m x 1.39 m
8 4 X 4 7	2.54 m x 1.39 m
20 0 X 10 0	6.09 m x 3.04 m
26 8 X 13 4	8.12 m x 4.06 m
5 2 X 5 2	1.57 m x 1.57 m
10 0 X 6 7	3.04 m x 2.00 m
13 10 X 6 7	4.21 m x 2.00 m
20 6 X 6 7	6.24 m x 2.00 m
27 2 X 6 7	8.28 m x 2.00 m
20 6 X 10 2	6.24 m x 3.09 m
2 7 X 5 0	.78 m x 1.52 m
10 0 X 5 0	3.04 m x 1.52 m
13 3 X 6 8	4.03 m x 2.03 m

Specifications sourced from omax.com — verified 2026-03-28

Strengths & Limitations

Strengths

Full 2x4 m sheet capacity eliminates repositioning for standard plate sizes
Dual-drive synchronized gantry ensures accuracy across extended 4,000 mm X travel
Supports dual-head configuration for increased throughput on nested sheet runs
Advanced nesting software maximizes material utilization on large sheets
Same operator interface as I-Cut 1530 for consistent multi-machine shop environments

Limitations

Large footprint requires significant floor space and facility planning
Higher capital and installation cost compared to smaller-format waterjet systems
Dual-head setup adds complexity to pump capacity planning and abrasive supply

Best For

Steel service centers and large fabrication shops processing full standard sheets Aerospace and defense manufacturers cutting large aluminum and titanium plate Architectural metalwork and cladding fabricators with large-format design requirements High-volume job shops seeking maximum throughput with dual-head waterjet configurations

Frequently Asked Questions

01 Can the I-Cut 2040 run two cutting heads simultaneously?

Yes, the I-Cut 2040 is designed to support dual-head cutting configurations. Running two heads simultaneously on the same gantry allows shops to produce two identical parts in parallel or nest complementary parts on the same sheet, significantly reducing cycle time per part on production runs.

02 What sheet sizes does the I-Cut 2040 accommodate?

The 2,000 x 4,000 mm cutting area accommodates full standard mill sheets, including 2 m x 4 m steel and aluminum plate. Sheets up to these dimensions can be processed in a single setup without repositioning, which is a key productivity advantage over smaller-format machines.

03 How is accuracy maintained over the 4,000 mm X-axis travel?

The I-Cut 2040 uses dual synchronized servo drives on both sides of the gantry bridge for the X-axis. This dual-drive approach prevents yaw error — the tendency of a long bridge to skew when driven from only one side — and maintains positioning accuracy of ±0.05 mm across the full 4,000 mm travel length.

04 What pump options are available for the I-Cut 2040?

The I-Cut 2040 is typically configured with a 45 kW or 55 kW direct-drive ultra-high-pressure pump operating at up to 4,000 bar. For dual-head operation, pump capacity must be matched to support two simultaneous cutting heads, which may require a higher-power pump or dual pump configuration depending on orifice sizes used.

05 What industries commonly use the I-Cut 2040?

The I-Cut 2040 is widely used in steel service centers, heavy fabrication, aerospace and defense manufacturing, shipbuilding, energy sector component production, and architectural metalwork. Any industry that regularly processes large format plate in steel, aluminum, stainless, or specialty alloys benefits from the 2 m x 4 m work envelope.
