Prima Power Punch Genius 1530

$400,000 - $650,000+ (new, depending on automation and magazine size) Updated 2026-03-16

Key Specifications

Tool Capacity

Up to 384 tools (extended magazine)

Weight

Approx. 22,000 kg (48,500 lbs)

Accuracy

±0.05 mm

working area

3,048 x 1,524 mm (120 x 60 in)

max punching force

300 kN (33.7 tons)

max stroke rate

1,000 strokes/min (at 1 mm pitch)

Overview

The Prima Power Punch Genius 1530 is a servo-electric CNC punch press that breaks from the traditional turret punch concept entirely. Instead of a rotating turret, the Punch Genius uses a linear tool magazine with direct servo-electric ram, selecting and loading tools from a magazine into a single punching head. This eliminates the turret altogether and provides virtually unlimited tool capacity from the magazine -- up to 384 tools in the extended configuration.

The working area is 3,048 x 1,524 mm (120 x 60 in), handling full-size 5 x 10 ft sheets without repositioning. Maximum punching force is 300 kN (33.7 tons) -- substantially higher than most turret punch presses. The servo-electric ram achieves up to 1,000 strokes per minute on 1 mm pitch, and the machine handles mild steel up to 8 mm (0.315 in) thick. Positioning speed is 150 m/min with ±0.05 mm accuracy.

The tool-changing approach is the Punch Genius's defining feature. Because tools load from a linear magazine into a single ram position, there is no turret to index and no limit on how many different tools a program can use. The machine can also rotate any tool to any angle continuously, eliminating the need for dedicated angular tool stations. Prima Power's Tulus HMI control provides programming, monitoring, and OEE tracking. New Punch Genius 1530 machines start around $400,000 and reach $650,000+ with full automation, extended tool magazine, and part sorting systems.

Full Specifications

Parameter	Value
Working Area	3,048 x 1,524 mm (120 x 60 in)
Max Punching Force	300 kN (33.7 tons)
Max Stroke Rate	1,000 strokes/min (at 1 mm pitch)
Max Sheet Thickness	8 mm (0.315 in) mild steel
Tool Capacity	Up to 384 tools (extended magazine)
Tool Type	Linear magazine with single ram (no turret)
Tool Rotation	Continuous 360° rotation, any angle
Positioning Accuracy	±0.05 mm
Traverse Speed	150 m/min
Drive Type	Servo-electric
CNC Control	Prima Power Tulus HMI
Machine Weight	Approx. 22,000 kg (48,500 lbs)
Model	COMBI GENIUS CG1530Discontinued Model
Brand	PRIMA
Type	Turret Punches
Convert Specs To Metrictonnage33 T Turret Stations20controlcnc	12 ModelsView more about Prima Industrie S.p.A.
Tonnage33 T Turret Stations20	ControlCNC (Siemens CNC Control)
Tonnage33 T	# Turret Stations20
Tonnage	33 T
Turret Stations	20
Cnc Control	CNC (Siemens CNC Control)

Specifications sourced from machinetools.com — verified 2026-03-28

Strengths & Limitations

Strengths

300 kN punching force is among the highest in the servo-electric punch press class -- handles 8 mm steel
Up to 384 tools eliminates tool capacity as a production constraint entirely
1,000 strokes/min at 1 mm pitch delivers high throughput on thin sheet applications
No turret means continuous 360° tool rotation -- any tool at any angle without dedicated angular stations
Full 5 x 10 ft working area (3,048 x 1,524 mm) handles standard large-format sheets without repositioning
Servo-electric drive eliminates hydraulic oil maintenance and delivers consistent punch quality

Limitations

Tool change time from magazine to ram is slower than a turret's indexing for sequential tool usage
Higher price point than conventional turret punches -- $400,000-$650,000 is significant capital
22,000 kg machine weight and large footprint requires substantial floor space and foundation
Prima Power's dealer network in North America is smaller than Amada or Trumpf
Proprietary tool magazine system means less aftermarket tooling flexibility than thick turret machines

Best For

High-mix fabrication shops where unlimited tool capacity eliminates the bottleneck of tool changes between jobs Large-format sheet processing (5 x 10 ft) in industries like transportation, construction, and industrial enclosures Operations requiring heavy punching force (up to 300 kN) for thicker sheet metal and large tools Shops running complex parts with many different tool shapes and angles that would overwhelm a turret punch Fabricators looking to replace turret punches with next-generation servo-electric technology

Frequently Asked Questions

01 What does a Prima Power Punch Genius 1530 cost?

New Punch Genius 1530 machines start around $400,000 for base configuration and reach $650,000+ with extended tool magazine (384 tools), load/unload automation, and part sorting. Full FMS (Flexible Manufacturing System) integration with sheet storage and automated material flow can push total system cost above $1 million.

02 How does the linear magazine compare to a turret?

A turret holds 20-58 tools and indexes between them in 0.3-0.5 seconds. The linear magazine holds up to 384 tools but each tool change (magazine to ram) takes slightly longer than a turret index. The advantage is unlimited tool variety per program -- you never run out of stations. For parts requiring many tools, the magazine approach wins on total cycle time by eliminating tool swaps between jobs.

03 Can the Punch Genius 1530 perform forming operations?

Yes. The servo-electric ram provides precise depth control for forming operations including louvers, countersinks, embossments, lances, and ribs. The machine can also tap threads and mark parts. The high 300 kN force allows deeper forms and larger forming tools than most turret punch presses can accommodate.

04 What automation options are available?

Prima Power offers integrated automation including automatic load/unload systems, sheet storage towers, part picking and sorting, and connection to their Night Train FMS (Flexible Manufacturing System) for unmanned production. The Night Train system stores raw sheets and finished parts in a multi-level storage tower with automated material delivery to the machine.
