MultiCam 1000 Series

Est. $30,000 - $55,000 Possible older model Specs verified 2026-03-28 · machinio.com Updated 2026-10-03

This model was not found in MultiCam's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.

Key Specifications

Max Spindle

18,000 RPM

Table Size

1524 x 3048 mm

Spindle Power

5–10 hp (3.7–7.5 kW)

work area x

49 in (1,245 mm) standard; larger options available

work area y

97 in (2,464 mm) standard

work area z

6 in (152 mm)

How much does the MultiCam 1000 Series cost?

Estimated price range

Est.$30,000 - $55,000

Our best estimate for a cnc router in this class — not a quote from MultiCam. Configuration moves it a long way.

Overview

The MultiCam 1000 Series is a light gantry CNC router listed with a standard work area of 49 in (1,245 mm) by 97 in (2,464 mm), 6 in (152 mm) of Z and a 5–10 hp (3.7–7.5 kW) spindle. MultiCam no longer shows it in its current lineup. The listed figures come from an unconfirmed table, which makes them a guide for inspecting a used machine and nothing firmer.

The standard work area takes a four-by-eight sheet with a small margin. Larger options are noted, and the table also lists a 1524 x 3048 mm table size with travels of 3,048 mm and 1,524 mm, the five-by-ten format. Which of the two a particular machine has is easy to settle with a tape measure and worth settling early.

At approx. 1,800 lb (816 kg) this is a light machine, and the other rows are consistent with that. Spindle speed tops out at 18,000 RPM and feed rate at 1,200 in/min (30.5 m/min). Z is 6 in (152 mm), enough for sheet and thin slab but not for deep work. The control is the MultiCam e-Panel with a touchscreen.

By the listed figures it sits well below the 8000 Series, which is listed with 20–30 hp (14.9–22.4 kW), 24,000 RPM and approx. 8,000–12,000 lb (3,629–5,443 kg). The 1000 Series has a fraction of that mass and spindle power, and a lower top speed.

Full Specifications

Parameter	Value
Work Area X	49 in (1,245 mm) standard; larger options available
Work Area Y	97 in (2,464 mm) standard
Work Area Z	6 in (152 mm)
Spindle Motor Power	5–10 hp (3.7–7.5 kW)
Max Spindle Speed	18,000 RPM
Feed Rate Max	1,200 in/min (30.5 m/min)
CNC Control	MultiCam e-Panel (touchscreen)
Machine Weight	Approx. 1,800 lb (816 kg)
Table Size	1524 x 3048 mm
X Axis Travel	3,048 mm
Y Axis Travel	1,524 mm
Z Axis Travel	152 mm

Specifications sourced from machinio.com — verified 2026-03-28

Strengths & Limitations

Strengths

5–10 hp (3.7–7.5 kW) spindle range at up to 18,000 RPM
Feed rate listed at up to 1,200 in/min (30.5 m/min)
Approx. 1,800 lb (816 kg) machine weight eases placing and moving it
Standard work area of 49 in (1,245 mm) by 97 in (2,464 mm), with a 1524 x 3048 mm table size also listed

Limitations

Not in MultiCam's current lineup; the listed figures are unconfirmed
Z travel is 6 in (152 mm)
Spindle speed is capped at 18,000 RPM, against 24,000 RPM listed for the 8000 Series
No tool changer or accuracy figure is listed

Best For

Sheet routing within 49 in (1,245 mm) by 97 in (2,464 mm) Light-duty cutting with a 5–10 hp (3.7–7.5 kW) spindle Shallow work inside 6 in (152 mm) of Z Buyers after a used router of around 1,800 lb (816 kg)

Frequently Asked Questions

01 Is the MultiCam 1000 Series still made?

MultiCam no longer shows the 1000 Series in its current lineup, so it appears to be an older model. The listed figures are unconfirmed, and a used machine should be checked for its actual bed size, spindle and control.

02 What is the working area of the 1000 Series?

The standard work area is listed as 49 in (1,245 mm) by 97 in (2,464 mm) with 6 in (152 mm) of Z. Larger options are noted, and a 1524 x 3048 mm table size is also listed with travels of 3,048 mm and 1,524 mm and a Z travel of 152 mm.

03 What spindle does it have?

The spindle is listed at 5–10 hp (3.7–7.5 kW) with a maximum speed of 18,000 RPM. That is a range, so the power of the unit fitted to a given machine has to be read from its nameplate.

04 How does the 1000 Series compare with the 8000 Series?

The 8000 Series is listed with 20–30 hp (14.9–22.4 kW), 24,000 RPM and approx. 8,000–12,000 lb (3,629–5,443 kg). The 1000 Series is listed with 5–10 hp (3.7–7.5 kW), 18,000 RPM and approx. 1,800 lb (816 kg), so it is the lighter machine with the smaller spindle.
