LVD Strippit PX-30/1500 CNC Punch Press

$180,000 – $280,000 Updated 2026-03-17

Key Specifications

Punching Force

300 kN (33 tons)

Sheet Size Capacity

1,270 x 3,810 mm (50 x 150 in) typical

Number of Tool Stations

32 stations (A/B/C/D Strippit Thin Turret)

Repositioning Speed

Up to 76 m/min

Punching Speed

Up to 400 strokes/min

Control System

LVD CNC with CADMAN-P software integration

Overview

The LVD Strippit PX-30/1500 is a hydraulic CNC turret punch press delivering 300 kN (33 tons) of punching force for sheet metal workpieces up to 1,500 mm in the Y-axis. Part of LVD's established PX series, the PX-30/1500 is built for fabricators who require the high and consistent clamping force of hydraulic actuation for demanding punching operations — heavy-gauge steel, high-strength alloys, and frequent large-diameter tool use where servo-electric drive systems can be at a disadvantage.

The PX-30/1500 features a fixed hydraulic punch head combined with a coordinate table drive system that positions the sheet under the punch with precision linear encoder feedback, achieving positional accuracies of ±0.1 mm across the full working envelope. The turret carries 32 tool stations accommodating standard Strippit Thin Turret tooling in A, B, C, and D station sizes, providing broad tool variety for punching, nibbling, forming, and marking operations within a single setup.

LVD's CADMAN-P programming software handles offline job preparation for the PX-30/1500, importing DXF and IGES geometry, applying automatic tool selection from the machine's configured turret, and optimizing punch sequence for minimum sheet travel time. The resulting NC program is transferred to the machine's CNC controller via Ethernet, USB, or direct DNC link, and the operator can review and edit the program at the conversational control panel before committing to production.

The PX-30/1500 is a proven workhorse platform with a large installed base in North American and European fabrication shops. Its conventional hydraulic architecture translates to straightforward maintenance procedures, a wide network of qualified service technicians, and long-term parts availability — practical advantages for operations that prioritize machine uptime and minimize dependency on specialized service contracts. For shops running diverse material types including heavy-gauge carbon steel and thick stainless, the hydraulic PX-30/1500 remains a reliable, cost-effective punching solution.

Full Specifications

Parameter	Value
Punching Force	300 kN (33 tons)
Sheet Size Capacity	1,270 x 3,810 mm (50 x 150 in) typical
Number Of Tool Stations	32 stations (A/B/C/D Strippit Thin Turret)
Repositioning Speed	Up to 76 m/min
Punching Speed	Up to 400 strokes/min
Control System	LVD CNC with CADMAN-P software integration
Throat Depth	1,270 mm
Machine Weight	Approx. 6,800 kg (14,990 lb)

Specifications sourced from static.machinetools.com — verified 2026-03-28

Strengths & Limitations

Strengths

Hydraulic drive provides consistent high-clamping force for heavy-gauge and high-strength materials
32-station turret with full A/B/C/D Strippit tooling compatibility maximizes tool variety
Proven hydraulic architecture simplifies maintenance with a wide service technician network
CADMAN-P offline programming minimizes machine downtime for job changeover

Limitations

Hydraulic actuation consumes more energy than servo-electric equivalents at similar output
Hydraulic system requires regular oil maintenance, filtration, and temperature management
Punching speed (400 spm) is lower than servo-electric competitors at equivalent force rating

Best For

Fabricators regularly punching heavy-gauge mild steel (4–6 mm) and stainless steel Shops with an existing Strippit tooling inventory looking to upgrade their punch press Operations prioritizing machine reliability, maintainability, and long service life

Frequently Asked Questions

01 How does the PX-30/1500 compare to the Strippit VX series?

The PX-30/1500 uses a proven hydraulic drive, while the VX series uses a servo-electric drive. The VX is faster and more energy-efficient for light-to-medium gauge work, while the PX-30/1500's hydraulic system delivers consistent force for heavy-gauge and high-strength material applications where peak force demands are frequent.

02 Can the PX-30/1500 handle stainless steel?

Yes. The PX-30/1500 is rated for stainless steel up to approximately 4 mm at full 300 kN force with standard tooling. Proper tool clearances and coated punches are recommended for stainless to minimize galling and maximize tool life.

03 What forming operations can be done on the PX-30/1500?

With appropriate tooling in the turret, the PX-30/1500 can perform louvers, lances, bridges, embosses, countersinks, tapping extrusions, and part marking in the same CNC program as standard punching and nibbling operations.
