Handtmann PBZ 750 CNC

$750,000 – $1,800,000 Updated 2026-03-17

Key Specifications

Working Area (X×Y×Z)

7,500 × 1,500 × 750 mm

Spindle Power

30 kW

Max Spindle Speed

24,000 RPM

Feed Rate

Up to 50,000 mm/min

Positioning Accuracy

±0.04 mm

Control System

Heidenhain TNC 640

Overview

The Handtmann PBZ 750 CNC is a flexible, high-performance portal machining center designed for precision aluminum and lightweight material machining in aerospace, automotive, and transportation industries. Where the PFZ 850 targets long structural profiles, the PBZ 750 addresses a broader spectrum of aluminum component sizes with enhanced flexibility for mixed production environments.

The PBZ 750's bridge-type portal construction combines a stable fixed table with high-speed linear axis drives to deliver rapid traverse and cutting feeds that maximize spindle utilization. The machine is engineered to handle the interrupted cuts, deep pockets, and complex bore patterns typical of aerospace bulkheads, automotive subframes, and rail vehicle structural elements.

Handtmann integrates its proprietary clamping technology with the PBZ 750, enabling rapid workpiece changeover and secure fixturing of profiles, plates, and cast components. The 5-axis option extends the machine's reach to compound-angle features and undercuts without requiring repositioning, reducing setup time and part handling risk for complex components.

The PBZ 750 runs on a Heidenhain TNC control and is typically integrated into automated production cells with pallet systems or robotic loading. Handtmann's process engineers work with customers to develop complete machining solutions — from cutting strategy development through fixture design and tooling qualification — making the PBZ 750 a turnkey investment rather than a standalone machine purchase.

Full Specifications

Parameter	Value
Working Area (X×Y×Z)	7,500 × 1,500 × 750 mm
Spindle Power	30 kW
Max Spindle Speed	24,000 RPM
Feed Rate	Up to 50,000 mm/min
Positioning Accuracy	±0.04 mm
Control System	Heidenhain TNC 640
Table Type	Fixed T-slot table with integrated clamping
Machine Weight	Approx. 28,000 kg
Maximum Storage Duration 1 Day	Type: HTTP Cookie
Maximum Storage Duration 1 Year	Type: HTTP Cookie
Maximum Storage Duration Persistent	Type: HTML Local Storage
Maximum Storage Duration Session	Type: HTTP Cookie
Maximum Storage Duration 2 Years	Type: HTTP Cookie
Maximum Storage Duration 3 Months	Type: HTTP Cookie
Maximum Storage Duration 400 Days	Type: HTTP Cookie
Maximum Storage Duration 180 Days	Type: HTTP Cookie
Maximum Storage Duration 25 Years	Type: HTTP Cookie
Maximum Storage Duration 30 Days	Type: HTTP Cookie

Specifications sourced from handtmann.us — verified 2026-03-28

Strengths & Limitations

Strengths

Versatile portal design handles a wide range of aluminum component types
Handtmann proprietary clamping system enables fast, secure workholding
5-axis option for complex features without repositioning
Strong integration with automated cell configurations and pallet systems

Limitations

Primarily optimized for aluminum — limited capability in hard metals
High initial investment for smaller production operations
Service and support infrastructure concentrated in Europe

Best For

Aerospace bulkheads and structural plates in aluminum alloy Automotive subframe and suspension component machining Rail and transportation structural aluminum profile machining

Frequently Asked Questions

01 What is the difference between the Handtmann PBZ 750 and PFZ 850?

The PFZ 850 offers a longer X-axis travel (8,500 mm vs 7,500 mm) and higher spindle speed (30,000 vs 24,000 RPM), making it better suited for extended aerospace structural profiles. The PBZ 750 is slightly more flexible for mixed-part production environments.

02 Can the PBZ 750 be equipped with 5-axis capability?

Yes. Handtmann offers a 5-axis tilting/rotating spindle head for the PBZ 750, enabling simultaneous 5-axis machining of complex compound-angle features without workpiece repositioning.

03 Does Handtmann offer automation integration for the PBZ 750?

Yes. The PBZ 750 is designed for integration with pallet handling systems, conveyor lines, and robotic loading. Handtmann works with customers to design complete automated cells around the machine.
