Fooke Endura 605L

$600,000 – $1,500,000 Updated 2026-03-17

Key Specifications

Working Area (X×Y×Z)

6,000 mm × 5,000 mm × 1,500 mm (other configurations available)

Spindle Power

22–52 kW (30–70 hp)

Max Spindle Speed

18,000 RPM (electrospindle option: 24,000 RPM)

Feed Rate

Up to 60,000 mm/min (2,362 IPM) rapid (linear drives optional)

Positioning Accuracy

±0.01 mm (volumetric, HEIDENHAIN KGM measurement)

Repeatability

±0.005 mm

Overview

The Fooke Endura 605L is a high-precision gantry-type CNC machining center designed for milling, routing, and machining of large aluminum structures, composites, and complex molds and patterns. Built by Fooke GmbH in Borken, Germany, the Endura 605L belongs to the company's long-established Endura series of portal milling machines, which have been widely adopted in aerospace, automotive tooling, and mold-making industries across Europe and globally.

The Endura 605L features a moving gantry architecture with a longitudinal table travel (X-axis) of up to 6,000 mm and transverse gantry travel (Y-axis) up to 5,000 mm, providing a large machining envelope suited to full-size automotive body dies, aerospace structural molds, and architectural aluminum panels. The vertical headstock (Z-axis) travel of 1,500 mm accommodates deep-pocket mold cavities and tall aerospace structural components. The machine's welded steel gantry is FEA-optimized for rigidity and thermal stability, reducing geometric drift during long production cycles.

Fooke offers the Endura 605L with a choice of 5-axis universal milling heads, including a fork-type head for unobstructed angular access and a swivel-type head for applications requiring high stiffness at horizontal spindle angles. Spindle power ranges from 22 kW to 52 kW with speeds up to 18,000 RPM, making the 605L capable of both aggressive roughing of large aluminum billets and high-speed finishing of mold surfaces. The HEIDENHAIN TNC 640 control with 5-axis RTCP (Rotary Tool Center Point) delivers the volumetric accuracy required for precision mold and die work.

The 605L is a strong choice for automotive press tool manufacturers producing large stamping dies, aerospace tooling builders creating composite lay-up molds and forming tools, and heavy equipment OEMs machining large structural weldments and gearbox housings. Fooke's reputation for thermally stable gantry construction and precise 5-axis heads has made the Endura series a benchmark in European mold and aerospace tooling shops.

Full Specifications

Parameter	Value
Working Area (X×Y×Z)	6,000 mm × 5,000 mm × 1,500 mm (other configurations available)
Spindle Power	22–52 kW (30–70 hp)
Max Spindle Speed	18,000 RPM (electrospindle option: 24,000 RPM)
Feed Rate	Up to 60,000 mm/min (2,362 IPM) rapid (linear drives optional)
Positioning Accuracy	±0.01 mm (volumetric, HEIDENHAIN KGM measurement)
Repeatability	±0.005 mm
Control System	HEIDENHAIN TNC 640 (5-axis RTCP standard)
Axes	5-axis simultaneous; fork or swivel milling head options
Table Type	Fixed T-slot table with vacuum clamping option
ATC	Up to 60 positions (chain magazine)
Machine Weight	Approx. 30,000–60,000 kg (configuration-dependent)

Strengths & Limitations

Strengths

Large machining envelope up to 6,000 × 5,000 mm handles full-size automotive dies and large aerospace molds
HEIDENHAIN TNC 640 with RTCP delivers high volumetric accuracy essential for precision mold and die work
High spindle power range (up to 52 kW) enables aggressive roughing and high-speed finishing on the same machine
German engineering pedigree with strong customer references in European aerospace and automotive tooling

Limitations

Premium pricing reflects high German manufacturing quality — not competitive with Asian alternatives on pure cost basis
Large installation footprint requires substantial facility space and foundation engineering
Delivery and lead times from Germany can be lengthy for North American or Asian buyers

Best For

Automotive press tool and stamping die manufacturers producing large body panel stamping dies Aerospace tooling builders creating composite lay-up molds, autoclave tools, and forming fixtures Mold and die shops machining large injection molds, blow molds, and architectural aluminum and composite panels

Frequently Asked Questions

01 What is the difference between the Fooke Endura 605L and other Endura models?

The Endura series spans multiple frame sizes. The '605L' designation reflects a 6,000 mm X-axis travel in a long-table configuration. Other Endura models offer different X/Y travel combinations. All share the same moving gantry architecture, HEIDENHAIN TNC 640 control, and 5-axis milling head philosophy — the choice between models is driven primarily by the size of the largest workpiece in the customer's program.

02 Can the Endura 605L machine steel as well as aluminum and composites?

Yes. While the 605L is optimized for aluminum and composite machining — particularly aerospace structural components and molds — its high-torque spindle options (up to 52 kW) and rigid gantry structure allow milling of hardened tool steel mold cavities and structural steel weldments. The choice of spindle and tooling configuration at order time should reflect the customer's primary material mix.

03 Does the Endura 605L support automation and pallet systems?

Fooke offers the Endura series with optional pallet change systems for high-volume production applications. For aerospace and tooling applications, most Endura 605L installations use manual workpiece loading with crane assistance, given the size and weight of the parts being machined. Custom automation integration is available through Fooke's project engineering team.
