Flow Flow Mach 200c
Key Specifications
Rapid Traverse
Accuracy
Repeatability
cutting method
max pressure
pump options
Overview
The Flow Mach 200c is a mid-range cantilever-style waterjet cutting system from Flow International, designed for shops that need reliable waterjet capability with the ergonomic advantages of a cantilever frame. The cantilever design provides unobstructed front and side access for easy material loading and unloading, making it particularly well-suited for shops processing sheet materials and flat stock where efficient material handling directly impacts throughput.
Operating at up to 60,000 PSI (4,150 bar), the Mach 200c supports three pump technologies: HyPlex Prime for intermittent duty, MotoJet for high-production environments, and MotoJet X for maximum uptime. Three table sizes are available — 1313 (1.3 x 1.3 m), 3020 (3.05 x 2 m), and 4020 (4 x 2 m) — covering compact prototyping through full-sheet production cutting. Positioning accuracy is +/- 0.025 mm (+/- 0.001 in) with matching repeatability of +/- 0.025 mm (+/- 0.001 in).
The machine features 203 mm (8 in) Z-axis travel and rapid traverse speeds of 12.7 m/min (500 in/min). Flow offers both FlowMaster and FlowXpert software suites for 2D and 3D cutting programming with built-in material databases that calculate optimal feed rates and pierce parameters. The cantilever construction provides inherent advantages for loading from the front and sides without gantry interference.
The Mach 200c cuts virtually any material including metals, stone, glass, composites, rubber, and plastics without heat-affected zones. It competes with the OMAX 2652, WardJet A-Series, and Techni Waterjet i-Series. New systems price between $100,000 and $175,000. Operating costs run approximately $20-$30/hour. The cantilever design makes it an excellent choice for shops where operator access and material handling efficiency are key considerations.
Full Specifications
| Parameter | Value |
|---|---|
| Cutting Method | Abrasive waterjet |
| Max Pressure | 60,000 PSI (4,150 bar) |
| Pump Options | HyPlex Prime, MotoJet, MotoJet X |
| Table Sizes | 1313 (1.3x1.3m), 3020 (3.05x2m), 4020 (4x2m) |
| Positioning Accuracy | +/- 0.025 mm (+/- 0.001 in) |
| Repeatability | ± 0.001 in |
| Z Axis Travel | 8 in |
| Rapid Traverse Rate | 12.7 m/min (500 in/min) |
| Frame Type | Cantilever |
| Cutting Head | Single abrasive waterjet head |
| Control Software | FlowMaster or FlowXpert |
| Drive System | AC servo motors with linear guides |
| Rapid Traverse Maximum | 500 in/min |
| Linear Positional Accuracy | ± 0.001 in |
| Work Envelope | Mach 200c 1313: 4'-3" x 4'-3"Mach 200c 3020: 10' x 6'-6"Mach 200c 4020: 13'-1" x 6'-6" |
| Ballbar Circularity | ± 0.003 in |
Specifications sourced from flowwaterjet.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Cantilever frame design provides unobstructed front and side access for efficient material loading and unloading
- Positioning accuracy and repeatability of +/- 0.025 mm deliver tight-tolerance cutting for precision applications
- 500 in/min rapid traverse keeps non-cutting time to a minimum on multi-part nested layouts
- Three pump technology options match the system to specific duty cycles from intermittent to continuous production
- FlowXpert software with material databases enables quick setup and optimized cutting parameters for any material
- Flow's global service network provides the largest support infrastructure in the waterjet industry
Limitations
- 60,000 PSI maximum pressure limits cutting speed compared to 87,000 or 94,000 PSI systems
- Cantilever design has inherent rigidity limitations compared to bridge-type gantry structures on larger machines
- Single-head configuration limits productivity for high-volume production compared to multi-head options
- 8-inch Z-axis travel restricts maximum material thickness compared to 12-inch options on performance models
Best For
Frequently Asked Questions
01
New Mach 200c systems price between $100,000 and $175,000 depending on table size and pump selection. The compact 1313 starts around $100,000. Larger 4020 tables with MotoJet X pump and Dynamic Waterjet head reach $175,000. Operating costs run $20-$30/hour.
02
The Mach 200c uses a cantilever frame while the Mach 200s uses a shuttle table design optimized for soft material cutting with up to 4 cutting heads. The 200c is better for precision cutting of metals and hard materials. The 200s excels at high-volume cutting of gaskets, insulation, rubber, and foam.
03
Virtually anything: metals (steel, aluminum, titanium, copper, brass), composites (carbon fiber, fiberglass), stone, glass, ceramics, rubber, foam, and plastics. Maximum thickness depends on material — typically up to 150 mm (6 in) on metals. Only tempered glass and diamonds cannot be cut.
04
The cantilever frame eliminates the overhead gantry beam on the front side of the machine, providing unobstructed access for loading materials with a forklift, crane, or manually. Operators can see the entire cutting area clearly and reach the workpiece from three sides for setup, fixturing, and part removal.
