Flow Dynamic Waterjet XL
Key Specifications
Cutting Head
Head Tilt Range
Table Size Options
Operating Pressure
Positional Accuracy
Repeatability
Overview
The Flow Dynamic Waterjet XL is Flow International's large-format 5-axis waterjet platform, combining the Dynamic Waterjet cutting head technology with an extended table envelope to serve aerospace, shipbuilding, and heavy industrial fabricators that process large plate and sheet stock. The system is purpose-built for shops that need both the scale of a large-format machine and the geometric complexity enabled by 5-axis tilting head capability.
At the heart of the Dynamic Waterjet XL is Flow's Active Tolerance Control (ATC) technology. Traditional waterjet cutting introduces taper error — a slight angle on the cut wall — that increases with material thickness and cutting speed. Flow's ATC system dynamically adjusts the head angle in real time as the machine interpolates the toolpath, compensating for taper and producing near-perpendicular cut walls without slowing the machine down. This eliminates a major source of secondary machining rework on precision parts.
The Dynamic head tilts up to 60 degrees from vertical, enabling bevel cuts, chamfers, countersink geometry, and compound angles all in a single waterjet setup. For aerospace structural components, marine hull sections, and architectural metalwork, this eliminates the need for separate milling or grinding operations to achieve complex edge geometry. The XL configuration provides table sizes up to 4,000 x 8,000 mm, accommodating full sheet or plate without repositioning.
Flow's FlowXpert CAD/CAM software integrates taper compensation models, bevel programming, and nesting into a unified environment. SmartStream motion control optimizes the relationship between cutting speed and head angle in real time, maintaining cut quality as geometry changes. The Dynamic Waterjet XL is available with HyperPressure pump options up to 94,000 psi for maximum cutting speed on thick exotic alloys.
Full Specifications
| Parameter | Value |
|---|---|
| Cutting Head | Flow Dynamic Waterjet with Active Tolerance Control (ATC) |
| Head Tilt Range | Up to 60 degrees from vertical |
| Table Size Options | Up to 4,000 x 8,000 mm (157 x 315 in) |
| Operating Pressure | 60,000 psi (4,137 bar) standard; 87,000–94,000 psi HyperPressure option |
| Positional Accuracy | ±0.025 mm (±0.001 in) |
| Repeatability | ±0.013 mm (±0.0005 in) |
| 5-Axis Bevel Capability | Yes — compound angle geometry in single setup |
| Taper Compensation | Active Tolerance Control (ATC) — real-time dynamic |
| Control Software | FlowXpert CAD/CAM + SmartStream motion control |
| Multi-Head Option | Up to 4 cutting heads |
| Drive System | Proprietary linear drives, steel gantry |
| Power Requirements | 480V, 3-phase, 60 Hz |
Strengths & Limitations
Strengths
- Active Tolerance Control eliminates taper error in real time without sacrificing cutting speed
- 60-degree tilt range enables bevel cuts, chamfers, and compound angles in a single waterjet setup
- Large table options up to 4,000 x 8,000 mm accommodate aerospace and shipbuilding plate without repositioning
- HyperPressure pump option pushes to 94,000 psi for maximum speed on thick exotic alloys
- FlowXpert + SmartStream provide integrated CAD/CAM and motion optimization in one environment
Limitations
- High capital cost limits accessibility for all but the largest job shops and tier-1 suppliers
- 5-axis programming complexity requires skilled CAM programmers familiar with waterjet bevel geometry
- Large format table and HyperPressure pump demand significant floor space and facility infrastructure
Best For
Frequently Asked Questions
01
ATC is Flow's real-time taper compensation system. As the cutting head moves through the toolpath, ATC continuously adjusts the head angle to counteract the natural taper that abrasive waterjet produces, delivering near-perpendicular cut walls without reducing cutting speed.
02
Yes. The cutting head tilts up to 60 degrees from vertical, enabling full bevel, chamfer, countersink, and compound-angle cuts in a single setup. FlowXpert CAM software programs these complex geometries directly.
03
The XL configuration offers table sizes ranging from standard Mach-series envelopes up to 4,000 x 8,000 mm. Custom table configurations are available for applications requiring non-standard dimensions.
04
Both use Flow's high-pressure pump technology, but the Dynamic Waterjet XL emphasizes the 5-axis Dynamic cutting head with Active Tolerance Control as the primary feature. The Mach 700 is Flow's premium production waterjet platform; the Dynamic XL is specifically configured for large-format 5-axis work.
05
The standard configuration runs at 60,000 psi. Optional HyperPressure pump upgrades bring operating pressure to 87,000 or 94,000 psi for maximum cutting speed on thick titanium, Inconel, and other hard alloys.
