Finn-Power A5 Punch Press

Est. $40,000 - $120,000 Possible older model Updated 2026-10-03

This model was not found in Prima Power's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.

Key Specifications

punching force

200 kN (20 tons)

punch drive

Servo-electric

turret stations

36 stations (with auto-index options)

max tool diameter

88.9 mm in large station

sheet capacity

1,250 x 2,500 mm (49 x 98 in)

sheet thickness mild steel

0.5-6.0 mm (0.02-0.236 in)

How much does the Finn-Power A5 Punch Press cost?

Estimated price range

Est.$40,000 - $120,000

Our best estimate for a cnc punch presse in this class — not a quote from Prima Power. Configuration moves it a long way.

Overview

The Finn-Power A5 Punch Press is a servo-electric turret punch for 1,250 x 2,500 mm (49 x 98 in) sheet, with 200 kN (20 tons) of punching force and 36 turret stations. It carries the Finn-Power name and is not in Prima Power's current lineup. What follows is drawn from the listed figures for an older machine and should be confirmed on the machine itself.

The turret is the figure to look at first. It has 36 stations with auto-index options, and the large station accepts tools up to 88.9 mm in diameter. A turret of that size lets the tooling for several jobs stay loaded together, which means fewer turret changes between jobs, provided the station sizes on the machine match the tooling a shop owns.

Material range is 0.5-6.0 mm (0.02-0.236 in) in mild steel and in aluminum, and 0.5-4.0 mm (0.02-0.157 in) in stainless. The lower stainless limit follows from the 200 kN force. X positioning is listed at 85 m/min and the punch rate at 700 hits/min on a short step, so the rate falls as hole spacing grows.

Tapping is an optional threading unit and may not be fitted. The electrical supply is 400/460 VAC 3-phase 50/60 Hz, which covers both common mains standards. Machine weight is 8,800 kg (19,400 lb), the figure to plan lifting and the floor around.

Full Specifications

Parameter	Value
Punching Force	200 kN (20 tons)
Punch Drive	Servo-electric
Turret Stations	36 stations (with auto-index options)
Max Tool Diameter (full magazine)	88.9 mm in large station
Sheet Capacity	1,250 x 2,500 mm (49 x 98 in)
Sheet Thickness Mild Steel	0.5-6.0 mm (0.02-0.236 in)
Sheet Thickness Stainless	0.5-4.0 mm (0.02-0.157 in)
Sheet Thickness Aluminum	0.5-6.0 mm (0.02-0.236 in)
Positioning Speed X	85 m/min
Max Punch Rate	700 hits/min (short step)
Tapping	Optional threading unit
CNC Control	FANUC or Siemens CNC with Finn-Power NC programming
Machine Weight	8,800 kg (19,400 lb)
Electrical	400/460 VAC 3-phase 50/60 Hz

Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.

Strengths & Limitations

Strengths

36 turret stations with auto-index options, so a wide tool mix can stay loaded between jobs
The large station takes tools up to 88.9 mm in diameter
Electrical supply is listed as 400/460 VAC 3-phase 50/60 Hz, so either mains standard is covered
Servo-electric punch drive, with X positioning listed at 85 m/min

Limitations

Sheet capacity is 1,250 x 2,500 mm (49 x 98 in), so larger stock has to be cut down first
Stainless is limited to 0.5-4.0 mm (0.02-0.157 in) at 200 kN (20 tons)
Tapping is an optional threading unit and may not be on a given machine
The 700 hits/min figure applies to a short step only

Best For

Mild steel and aluminum parts from 0.5-6.0 mm (0.02-0.236 in) Jobs with a wide tool mix that benefit from 36 stations Shops running 1,250 x 2,500 mm (49 x 98 in) sheet Parts needing punched shapes up to 88.9 mm in one hit

Frequently Asked Questions

01 What sheet size and thickness does the Finn-Power A5 handle?

Sheet capacity is listed as 1,250 x 2,500 mm (49 x 98 in). Thickness is 0.5-6.0 mm (0.02-0.236 in) in mild steel, 0.5-4.0 mm (0.02-0.157 in) in stainless and 0.5-6.0 mm (0.02-0.236 in) in aluminum. Punching force is 200 kN (20 tons).

02 How many stations does the Finn-Power A5 turret have?

36 stations, with auto-index options. The maximum tool diameter is 88.9 mm in the large station. The table does not break the 36 down by station size or say how many are auto-index, so that has to be read from the turret on the machine.

03 Does the Finn-Power A5 have tapping?

Tapping is listed as an optional threading unit. It was an extra, so a used machine may or may not have it. If threaded holes are part of the work, confirm the unit is fitted and working before relying on it.

04 What electrical supply and floor loading does the Finn-Power A5 need?

The electrical row reads 400/460 VAC 3-phase 50/60 Hz. Machine weight is 8,800 kg (19,400 lb). Check the voltage a particular machine is wired for against the supply in your building, since the row gives two voltages.
