Euromac FX Punch 6-1250 CNC Punch Press
Key Specifications
Punch Force
Drive Type
Table Size
Turret Stations
Max Tool Diameter
Sheet Thickness Range
Overview
The Euromac FX Punch 6-1250 is a compact servo-electric CNC punch press designed for job shops and light fabricators processing thin-gauge sheet metal for enclosures, HVAC components, and electrical panels. The FX series uses Euromac's servo-electric drive delivering 6 tons of punch force — ideal for light-gauge stainless steel and aluminum sheet from 0.5mm to 3mm. The 1250x4000mm table handles 4-foot sheets with full repositioning capability. A 24-station turret provides common punching tools including round, square, oblong, and special forms. Euromac's Artube software handles DXF import and nesting to maximize sheet yield. The compact footprint (under 4m x 3m) and single-phase power option make the FX Punch accessible for small shops without three-phase infrastructure. Euromac is an Italian manufacturer with distribution through metalworking dealers across Europe and North America.
Full Specifications
| Parameter | Value |
|---|---|
| Punch Force | 6 ton (53 kN) |
| Drive Type | Servo-electric |
| Table Size | 1250 x 4000 mm |
| Turret Stations | 24 |
| Max Tool Diameter | 76 mm |
| Sheet Thickness Range | 0.5 - 3.0 mm (mild steel) |
| Punch Rate | Up to 400 hits/min |
| Control | Euromac Artube |
| Power | Single or three-phase option |
Strengths & Limitations
Strengths
- Compact footprint for small shop environments
- Single-phase power option reduces electrical infrastructure requirements
- Servo-electric for low maintenance and consistent force control
- Artube software with DXF import for simple programming
- Low entry cost for CNC punch press capability
Limitations
- 6-ton capacity limits to thin gauge only (max 3mm steel)
- Smaller turret (24 stations) vs larger TRUMPF or Amada presses
- Euromac service network thinner in North America
Best For
Frequently Asked Questions
01
The FX Punch 6-1250 handles mild steel from 0.5mm to 3.0mm (approximately 26 gauge to 11 gauge), stainless steel to 2.5mm, and aluminum to 3.5mm. For heavier gauge or higher forming forces, a larger machine like the Euromac XT Punch or TRUMPF TruPunch is required.
02
The FX Punch is available with a single-phase 230V option in addition to the standard three-phase configuration. This makes it accessible for smaller shops and facilities that lack three-phase power infrastructure.
