Amada AC 2510 NT
This model was not found in Amada's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.
Key Specifications
punching force
sheet thickness max
sheet size max
number of tools
hits per minute max
positioning speed
How much does the Amada AC 2510 NT cost?
Estimated price range
Our best estimate for a cnc punch presse in this class — not a quote from Amada. Configuration moves it a long way.
Overview
The Amada AC 2510 NT is a CNC turret punch press for sheets up to 2,500 x 1,250 mm, with a listed punching force of 300 kN (33 US ton). Amada's current lineup does not include it, so the listed figures here serve mainly as a reference for a used machine and should be checked against the machine's own documentation.
The turret is listed with up to 58 stations in a mixed configuration. Maximum sheet thickness is 6.4 mm in mild steel, 4 mm in stainless and 6 mm in aluminum. Speed figures are 600 hpm in single hit mode and a positioning speed of 100 m/min with X and Y combined, so the hit rate on real nests, with longer moves between holes, will be lower than the headline number.
The control is listed as the Amada AMNC 3i, and the machine weight as approximately 9,000 kg.
Full Specifications
| Parameter | Value |
|---|---|
| Punching Force | 300 kN (33 US ton) |
| Sheet Thickness Max | 6.4 mm mild steel, 4 mm stainless, 6 mm aluminum |
| Sheet Size Max | 2,500 x 1,250 mm |
| Number of Tools | Up to 58 stations (turret, mixed configuration) |
| Hits per Minute Max | 600 hpm (single hit mode) |
| Positioning Speed | 100 m/min (X and Y combined) |
| CNC Control | Amada AMNC 3i |
| Machine Weight | Approx. 9,000 kg |
Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.
Strengths & Limitations
Strengths
- Up to 58 turret stations in a mixed configuration
- Handles sheets up to 2,500 x 1,250 mm
- 600 hpm in single hit mode with 100 m/min combined positioning speed
- 300 kN (33 US ton) punching force for mild steel up to 6.4 mm
Limitations
- Stainless is limited to 4 mm, against 6.4 mm in mild steel
- The 600 hpm figure applies to single hit mode only
- Weighs approximately 9,000 kg, which needs a suitable floor and rigging
Best For
Frequently Asked Questions
01
The listed maximums are 6.4 mm in mild steel, 4 mm in stainless and 6 mm in aluminum, with a punching force of 300 kN (33 US ton). The force needed also depends on the punch perimeter, so a large shape in thick material can reach the limit before the thickness does.
02
Up to 58 stations are listed, in a mixed turret configuration. The split between station sizes is not given, so on a used machine check the actual turret layout and station sizes before planning tooling.
03
600 hpm in single hit mode, with a positioning speed of 100 m/min for X and Y combined. Both are peak figures. Throughput on a real part depends on hole spacing, tool changes at the turret and sheet repositioning.
