Yamazaki Mazak Vertical Machining Centers

Mazak VTC-530C

$250,000 - $350,000 Updated 2026-03-19

Key Specifications

X Travel

2,500 mm (98.4 in)

Y Travel

760 mm (29.9 in)

Z Travel

660 mm (26.0 in)

Max Spindle

10,000 RPM

Spindle Taper

BT 50

Tool Capacity

30 (arm-type ATC); 48 optional

Overview

The Mazak VTC-530C is a large-format vertical traveling column machining center that provides 2,500 mm (98.4 in) of X-axis travel for shops machining long parts that exceed the capacity of standard VMCs. The traveling column design keeps the workpiece stationary on a fixed table while the spindle head traverses the full X-stroke, eliminating dynamic workpiece loads and maintaining consistent floor space usage.

The BT 50 spindle turns at 10,000 RPM with 30 kW (40 hp), providing the torque and tool clamping force for aggressive material removal in steel, cast iron, and alloy work. The 50-taper is well-matched to the machine's intended role: heavy-duty cutting on large parts where tool rigidity and cutting force matter more than spindle speed. A 30-tool arm-type ATC handles the BT 50 tooling, with expanded magazine options available.

The fixed table measures 3,000 x 760 mm (118.1 x 29.9 in) with a load capacity of 3,500 kg (7,716 lb). This table accommodates workpieces approaching 100 inches long, or multiple shorter parts fixtured side by side. The 760 mm Y-travel and 660 mm Z-travel provide generous clearance for tall parts and deep-cavity work.

Built on a cast iron base with roller guides, the VTC-530C delivers consistent accuracy across the full travel range. The MAZATROL SmoothG CNC provides conversational and G-code programming. Rapid traverse reaches 36 m/min across all axes.

New VTC-530C machines run $250,000-$350,000. The machine competes with the Okuma MCR-A5CII, DMG Mori DMF 360, and larger Johnford double-column machines. For shops that need nearly 100 inches of X-travel with the convenience of a traveling column and BT 50 power, the VTC-530C is a proven production platform.

Full Specifications

Parameter	Value
X-Axis Travel	2,500 mm (98.4 in)
Y-Axis Travel	760 mm (29.9 in)
Z-Axis Travel	660 mm (26.0 in)
Max Spindle Speed	10,000 RPM
Spindle Taper	BT 50
Spindle Motor Power	30 kW (40 hp)
Tool Capacity	30 (arm-type ATC); 48 optional
Table Size	82.68" × 25"
Max Table Load	3,500 kg (7,716 lb)
Rapid Traverse Rate	36 m/min (1,417 ipm)
Machine Weight	14,000 kg (30,865 lb)
CNC Control	MAZATROL SmoothG
Machine Type	Vertical traveling column
Guide Type	Linear roller guides (all axes)
Tool Shank	CAT No.50
Max Spindle Speed	6000 min-1(rpm)

Specifications sourced from mazak.com — verified 2026-03-28

Strengths & Limitations

Strengths

2,500 mm (98.4 in) X-travel handles workpieces nearly 100 inches long on a single setup without repositioning
BT 50 spindle with 30 kW provides heavy cutting power for large-volume material removal in steel and cast iron
3,500 kg fixed table load supports the heaviest workpieces without dynamic load concerns
3,000 x 760 mm table enables multi-part fixturing that reduces per-part setup time on production runs
Traveling column maintains constant footprint and eliminates workpiece motion for better accuracy on heavy parts
MAZATROL SmoothG with conversational programming simplifies shop-floor programming for long-part work

Limitations

14,000 kg machine weight requires substantial foundation preparation and limits placement flexibility
10,000 RPM BT 50 spindle is slow for high-speed aluminum work; not the right machine for high-RPM applications
Starting at $250K, the VTC-530C represents a major capital investment
Large footprint with nearly 100 inches of X-travel demands significant linear floor space

Best For

Aerospace manufacturers machining long wing ribs, structural members, and fuselage components Rail and transportation shops machining long structural rails, brackets, and chassis components Mold and die manufacturers working on extra-long die shoes and press bolster plates Energy sector shops machining large turbine components, valve assemblies, and generator housings Job shops specializing in long, heavy workpieces that do not fit on standard VMCs

Frequently Asked Questions

01 What does a Mazak VTC-530C cost new?

New VTC-530C machines run $250,000-$350,000 depending on configuration. Used units from 2008-2018 sell for $100,000-$200,000 depending on hours and condition.

02 How does the VTC-530C differ from the VTC-300C?

The VTC-530C provides 500 mm more X-travel (2,500 vs 2,000 mm), a larger table (3,000 vs 2,500 mm), and higher table load capacity (3,500 vs 3,000 kg). Both share the traveling column architecture and BT 50 spindle. The 530C is the larger, heavier machine for shops needing maximum long-part capability.

03 What is the maximum part length?

The 2,500 mm X-stroke supports parts up to approximately 3,000 mm (118 in) on the table. Actual maximum part length depends on fixturing and tool clearance requirements.

04 Is the VTC-530C suitable for 5-axis work?

The standard VTC-530C is a 3-axis machine. For 5-axis traveling column capability, Mazak offers the VTC-800/30SR and VTC-800/30HD with B-axis tilting heads. The VTC-530C can be equipped with a 4th-axis rotary table for indexing work.
