Makino V99L (40 Taper)

$320,000 - $420,000 Updated 2026-03-13

Key Specifications

X Travel

1,300 mm (51.2 in)

Y Travel

1,000 mm (39.4 in)

Z Travel

500 mm (19.7 in)

Max Spindle

14,000 RPM

Spindle Taper

CAT40 (HSK-A63 opt)

Tool Capacity

30 (40, 80)

Overview

The Makino V99L (40 Taper) is the extended-travel version of the V99, designed for die and mold shops that need to machine oversized workpieces — large bumper molds, instrument panel tools, and multi-cavity mold plates — on a single setup. The 'L' designation means long-stroke, and the V99L delivers it with significantly increased Y-axis travel compared to the standard V99.

Axis travel measures 1,300 x 1,000 x 500 mm (51.2 x 39.4 x 19.7 in) on X/Y/Z, a substantial upgrade from the standard V99's 1,000 x 800 mm envelope. The worktable expands to 1,500 x 1,000 mm (59.1 x 39.4 in) with a 3,000 kg (6,614 lb) load capacity, accommodating the heavy mold plates and die blocks that this class of machine is built to handle. This travel range covers workpieces that would otherwise require a double-column or gantry machine.

The 40-taper spindle configuration matches the standard V99 at 14,000 RPM with 22 kW (30 hp) and Makino's core-cooled technology. Rapid traverse rates run 36 m/min (1,417 ipm) on X/Y and 30 m/min (1,181 ipm) on Z. The standard 30-tool ATC (60-tool optional) keeps non-cutting time short during complex multi-tool finishing sequences.

The machine sits on the same rigid cast-iron construction as the V99, with roller-type linear guides and hand-scraped mating surfaces for long-term geometric accuracy. The Pro 6 control with SGI.5 contouring handles the high-speed finish passes on 3D mold surfaces that define die/mold VMC capability. At approximately 16,000 kg (35,274 lb), the V99L carries substantial thermal mass that contributes to dimensional stability during extended machining cycles.

The V99L competes with double-column machines like the Makino F-series and Okuma MCR-A5CII in the large-workpiece segment. New pricing typically runs $320,000 to $420,000 depending on configuration, with the extended travel commanding a premium over the standard V99.

Full Specifications

Parameter	Value
X-Axis Travel	1,300 mm (51.2 in)
Y-Axis Travel	1,000 mm (39.4 in)
Z-Axis Travel	500 mm (19.7 in)
Max Spindle Speed	14,000 RPM
Spindle Taper	CAT40 (HSK-A63 opt)
Spindle Motor Power	22 kW (30 hp)
Tool Capacity	30 (40, 80)
Table Size	1,500 x 1,000 mm (59.1 x 39.4 in)
Table Load Capacity	3,000 kg (6,614 lb)
Rapid Traverse Xy	36 m/min (1,417 ipm)
Rapid Traverse Z	30 m/min (1,181 ipm)
Guideway Type	Roller-type linear guides
Machine Weight	~16,000 kg (35,274 lb)
CNC Control	Makino Professional 6 (Pro 6)
Coolant System	Through-spindle coolant (standard)
Eventscontent Librarywebinar Archiveownersmakino Expertisesafety Data Sheetsnewsroomfinancing	Financing OptionsMakino makes it easy to upgrade with flexible financing optionsLearn More
Metric	English
Spindle Rpm	20,000
Rapid Traverse Rate	787 in/min
Cutting Feedrate	787 in/min
Maximum Workpiece	90.55" x 39.37" x 25.59"
Maximum Payload	8,816 lbs
Tool To Tool	8 secs
Maximum Tool Diameter	4.7"
Maximum Tool Weight	17.6"
Optional Atc Capacity	Yes
Makinooptionalatccapacity	Yes

Specifications sourced from makino.com — verified 2026-03-28

Strengths & Limitations

Strengths

1,300 x 1,000 mm X/Y travel handles oversized mold halves and multi-cavity die plates that exceed the standard V99's envelope
3,000 kg table load capacity supports heavy mold plates and complex fixture setups without compromising rigidity
Core-cooled 14,000 RPM spindle provides excellent thermal stability for long finishing cycles on large mold surfaces
SGI.5 contouring delivers smooth 3D surfaces across the extended travel range without sacrificing feed rates at direction changes
C-frame design maintains operator accessibility for large workpieces compared to equivalent double-column machines
Extended travel eliminates workpiece repositioning on large parts, reducing setup time and improving geometric consistency

Limitations

At approximately 16,000 kg, the V99L requires substantial floor preparation, rigging capacity, and potentially foundation reinforcement
14,000 RPM spindle speed limits high-speed finishing options for aluminum and graphite compared to 20K+ RPM machines
Premium pricing ($320K-$420K) approaches double-column machine territory where some shops may prefer the additional rigidity
Larger footprint than the standard V99 consumes valuable floor space in shops where layout is constrained
Extended travel may reduce dynamic rigidity at full Y-axis extension compared to the shorter-stroke V99

Best For

Automotive mold shops producing large bumper molds, instrument panel tools, and door panel molds that exceed 1,000 mm in one dimension Die manufacturers machining oversized stamping dies for automotive body panels and structural components Shops that need to consolidate roughing and finishing of large workpieces on a single C-frame machine to avoid double-column machine costs Multi-cavity mold makers who benefit from machining multiple cavities in a single plate setup across the extended table Large part manufacturers transitioning from older bridge-type or gantry machines to a modern VMC platform with better control technology

Frequently Asked Questions

01 What does a Makino V99L (40 Taper) cost?

New V99L (40T) machines typically price between $320,000 and $420,000. The extended travel adds approximately $60,000-$70,000 over the standard V99 price. A fully loaded configuration with 60-tool magazine, high-pressure coolant, probing, and chip management can push past $400,000. Used V99L machines are relatively uncommon on the secondary market but trade between $160,000 and $260,000 when available.

02 What is the difference between the V99L and the standard V99?

The V99L extends X-axis travel from 1,000 to 1,300 mm and Y-axis from 800 to 1,000 mm, giving 63% more table area. The table grows from 1,100 x 800 mm to 1,500 x 1,000 mm, and load capacity increases from 2,000 to 3,000 kg. Machine weight goes from ~12,000 to ~16,000 kg. The spindle, rapids, control, and fundamental construction are identical. The V99L is for shops that specifically need the extra travel; the standard V99 is preferred when its envelope is sufficient, as it costs less and has a smaller footprint.

03 Should I buy a V99L or a double-column machine?

The V99L offers comparable travel to entry-level double-column machines with better operator access and a lower price point. However, double-column machines provide symmetrical rigidity and typically handle heavier cuts with less deflection. If your work is primarily die/mold finishing with moderate roughing, the V99L is excellent. If you're doing heavy roughing of very large workpieces — forging dies over 3,000 kg, for example — a double-column design may be more appropriate.

04 Can the V99L be automated?

The V99L can integrate with pallet changers and loading systems, but its primary market — large die/mold work — typically involves long cycle times (8-24+ hours per setup) that reduce the ROI of pallet automation. The 60-tool magazine option is more commonly specified for unattended operation, allowing extended finishing cycles to run overnight without operator intervention.
