Makino V99 (50 Taper)
Key Specifications
X Travel
Y Travel
Z Travel
Max Spindle
Spindle Taper
Tool Capacity
Overview
The Makino V99 (50 Taper) is the heavy-duty variant of Makino's flagship large-capacity vertical machining center, built for die and mold manufacturers who prioritize maximum rigidity and torque for aggressive roughing operations in large workpieces. Where the 40-taper version balances speed and rigidity for finishing, the 50T leans hard into metal removal capability.
Axis travel remains the same as the 40T at 1,000 x 800 x 500 mm (39.4 x 31.5 x 19.7 in) on X/Y/Z, and the 1,100 x 800 mm (43.3 x 31.5 in) worktable still handles up to 2,000 kg (4,409 lb). The key difference is the BBT 50 (Big Plus) spindle, which tops out at 10,000 RPM but delivers substantially more torque than the 40-taper variant — 30 kW (40 hp) of continuous power through a larger-diameter spindle assembly. This makes the 50T significantly more productive when hogging material out of large forging dies, stamping dies, and deep mold cavities in hardened steels.
The machine uses the same rigid cast-iron construction and roller-type linear guides as the 40T, providing the structural foundation for heavy cutting without sacrificing positioning accuracy. Rapid traverse runs at 36 m/min (1,417 ipm) on X/Y and 30 m/min (1,181 ipm) on Z. The standard 30-tool ATC (60-tool optional) handles BBT 50 tooling with the dual-contact interface that eliminates the gap between taper and face for maximum rigidity at the tool tip.
Makino's core-cooled spindle technology maintains thermal stability under sustained heavy loads, and the Pro 6 control with SGI.5 contouring ensures that the 50T can transition from roughing to semi-finishing without sacrificing surface quality. Through-spindle coolant comes standard, delivering high-pressure cutting fluid directly to the cutting zone for chip evacuation in deep cavities.
The V99 (50T) competes with the Okuma MCR-BII, DMG Mori DMC 125 FD, and Toyoda FV1565 in the large heavy-duty VMC segment. Pricing typically ranges from $280,000 to $380,000 for a new machine depending on options.
Full Specifications
| Parameter | Value |
|---|---|
| X-Axis Travel | 1,000 mm (39.4 in) |
| Y-Axis Travel | 800 mm (31.5 in) |
| Z-Axis Travel | 500 mm (19.7 in) |
| Max Spindle Speed | 10,000 RPM |
| Spindle Taper | CAT50 (HSK-A100 opt) |
| Spindle Motor Power | 30 kW (40 hp) |
| Tool Capacity | 30 (40, 60) |
| Table Size | 1,100 x 800 mm (43.3 x 31.5 in) |
| Table Load Capacity | 2,000 kg (4,409 lb) |
| Rapid Traverse Xy | 36 m/min (1,417 ipm) |
| Rapid Traverse Z | 30 m/min (1,181 ipm) |
| Guideway Type | Roller-type linear guides |
| Machine Weight | ~12,500 kg (27,558 lb) |
| CNC Control | Makino Professional 6 (Pro 6) |
| Coolant System | Through-spindle coolant (standard) |
| Eventscontent Librarywebinar Archiveownersmakino Expertisesafety Data Sheetsnewsroomfinancing | Financing OptionsMakino makes it easy to upgrade with flexible financing optionsLearn More |
| Metric | English |
| Spindle Rpm | 12,000 (18,000) |
| Rapid Traverse Rate | 787 in/min |
| Cutting Feedrate | 787 in/min |
| Maximum Workpiece | 70.87" x 39.37" x 25.59" |
| Maximum Payload | 8,816 lbs |
| Tool To Tool | 5 secs |
| Maximum Tool Diameter | 5.7" |
| Maximum Tool Weight | 44 lbs |
| Optional Atc Capacity | Yes |
| Makinooptionalatccapacity | Yes |
Specifications sourced from makino.com — verified 2026-03-28
Strengths & Limitations
Strengths
- BBT 50 spindle with 30 kW delivers substantially higher torque than the 40T variant, enabling aggressive roughing in hardened tool steels and large die blocks
- Big Plus dual-contact interface eliminates taper-to-face gap for maximum rigidity and reduced tool deflection under heavy cutting loads
- 1,000 x 800 mm travel handles large forging dies, stamping dies, and injection mold halves without workpiece repositioning
- Core-cooled spindle technology maintains thermal stability even during sustained heavy roughing passes lasting hours
- SGI.5 contouring in the Pro 6 control lets the 50T transition seamlessly from roughing to semi-finishing on complex 3D mold surfaces
- 2,000 kg table capacity supports heavy die blocks and large fixture setups without compromising machine accuracy
- Through-spindle coolant standard provides reliable chip evacuation in deep die cavities
Limitations
- 10,000 RPM maximum spindle speed limits high-speed finishing capability compared to the 14K RPM 40-taper version
- BBT 50 tooling is more expensive than BBT 40, and most die/mold shops will need to maintain both inventories if they also run 40-taper machines
- At approximately 12,500 kg, rigging and floor preparation costs are substantial
- Premium pricing ($280K-$380K) is significantly above general-purpose large VMCs from competitors
- Larger spindle assembly limits RPM ceiling, making the 50T less suitable for aluminum or graphite high-speed machining
Best For
Frequently Asked Questions
01
New V99 (50T) machines typically price between $280,000 and $380,000. The 50T commands a premium over the 40T due to the larger spindle assembly and higher-torque drive system. Adding the 60-tool magazine, high-pressure coolant upgrade, and probing package can push the price toward the upper end. Used 50T machines are less common on the secondary market than the 40T but generally trade between $140,000 and $230,000 for 2015-2020 vintages.
02
Choose the 40T if your work is primarily mold finishing, complex 3D contouring, or you need the higher RPM ceiling (14,000 vs 10,000) for semi-finish and finish passes. Choose the 50T if you regularly rough large die blocks, need maximum torque for heavy cuts in hardened steels, or your tooling is already standardized on BT50/BBT50. Many large die shops prefer the 50T for its ability to handle aggressive roughing while still producing acceptable semi-finish surfaces.
03
The V99 offers comparable travel to many mid-size double-column machines in a C-frame configuration. Double-column machines like the Makino MCF series or Okuma MCR-BII provide greater rigidity for extremely heavy cuts due to their symmetrical structure. The V99 trades some of that ultimate rigidity for better operator access and a smaller footprint. For most die/mold roughing applications, the V99's rigidity is sufficient, and the C-frame design makes workpiece loading easier.
04
Big Plus (BBT) is a dual-contact spindle interface where both the taper and the spindle face make contact simultaneously, unlike standard BT tooling where only the taper contacts. This dual contact increases rigidity by 2-3x at the tool tip, reduces vibration, and improves surface finish. On the V99 (50T), the BBT 50 interface is particularly beneficial during heavy roughing where tool deflection would otherwise compromise accuracy and tool life.
05
The V99 (50T) is fully capable of finish machining, not just roughing. The SGI.5 contouring function in the Pro 6 control, combined with the machine's thermal stability, produces excellent 3D surface finishes. The 10,000 RPM spindle is adequate for finishing in hardened steels where cutting speeds are typically lower anyway. The limitation is in high-speed finishing of aluminum or graphite where higher RPMs would be beneficial.
