DN Solutions VM 1260

$350,000 - $550,000 Updated 2026-03-19

Key Specifications

Max Spindle

6,000 RPM

Table Size

2,800 x 1,260 mm (110 x 50 in)

Rapid Traverse

12 m/min (472 in/min)

Spindle Power

22 kW (29 hp)

x axis travel

2,500 mm (98 in)

y axis travel

1,260 mm (50 in)

Overview

The DN Solutions VM 1260 is the flagship of the VM die and mold series, delivering 2,500 mm (98 in) of X-travel, 1,260 mm (50 in) on Y, and 900 mm (35 in) on Z. That's a massive working envelope for a box-guide VMC, and it's designed specifically for the large mold bases and die sets that smaller machines can't cover.

With a 22 kW (29 hp) spindle running at 6,000 RPM and a table measuring 2,800 x 1,260 mm, the VM 1260 handles workpieces up to 8,000 kg (17,637 lb). That's serious weight capacity — enough for the largest automotive stamping dies and injection mold bases you'll encounter. The box-guide construction (as opposed to linear guides) gives you the rigidity to rough hardened tool steel aggressively without chatter.

Rapid traverse runs at 12 m/min across all axes. That's deliberate — DN Solutions prioritized rigidity and thermal stability over speed in the VM series. These machines aren't sprinting between holes; they're taking heavy cuts in hard materials where surface finish and geometric accuracy matter more than cycle time.

At 31,000 kg (68,343 lb), the VM 1260 has the mass to absorb the vibration from aggressive roughing in P20, H13, and S7 tool steels. The 40-tool magazine keeps enough cutters ready for complete roughing-to-finishing sequences without operator intervention. If you're building large molds or dies, the VM 1260 was designed from the ground up for that work.

Full Specifications

Parameter	Value
X Axis Travel	2,500 mm (98 in)
Y Axis Travel	1,260 mm (50 in)
Z Axis Travel	900 mm (35 in)
Max Spindle Speed	6,000 RPM
Spindle Motor Power	22 kW (29 hp)
Table Size	2,800 x 1,260 mm (110 x 50 in)
Table Load Capacity	8,000 kg (17,637 lb)
Tool Magazine Capacity	40 tools
Rapid Traverse Rate	12 m/min (472 in/min)
Machine Weight	31,000 kg (68,343 lb)
Construction	Box guideway
Max Spindle Speed	Max. Spindle Power
X Axis Travel Distance	2500 mm
Y Axis Travel Distance	1260 mm
Metric	IMPERIAL
Travels	X-Axis Travel DistanceY-Axis Travel DistanceZ-Axis Travel Distance
Feed Rates	X-Axis Rapid TraverseY-Axis Rapid TraverseZ-Axis Rapid Traverse
Main Spindle	Max. Spindle SpeedMax. Spindle Power
Table	Table LengthTable WidthMaximum Workpiece weight
Tool Storage Capacity	No. of tool station
Dimensions	LengthHeightWidthWeight
Favorites	VM 1260
6000 R Min	22 kW
6000 Rpm	29 hp

Specifications sourced from dn-solutions.com — verified 2026-03-28

Strengths & Limitations

Strengths

2,500 x 1,260 mm working envelope handles the largest automotive stamping dies and injection mold bases
8,000 kg table capacity supports heavy mold bases and die sets without accuracy concerns
Box-guide construction delivers superior rigidity for heavy roughing in hardened tool steel
900 mm Z-axis travel provides the depth for deep-cavity mold work and tall die components
31,000 kg machine weight crushes vibration during aggressive stock removal
40-tool magazine supports complete roughing-to-finishing sequences

Limitations

6,000 RPM spindle limits high-speed finishing — shops doing fine surface contouring may want a higher-speed option
12 m/min rapids are slow by modern standards, adding to cycle times on parts with many features spread across the table
31-ton weight and large footprint require substantial floor space and foundation preparation
Higher price point than smaller VM models limits accessibility for shops with occasional large-part needs

Best For

Die and mold shops building large automotive stamping dies, bumper molds, and instrument panel tools Injection mold manufacturers working with mold bases exceeding 1 meter in width Large-format machining operations needing box-way rigidity for hardened steel work Automotive tooling shops processing large progressive dies and transfer die components Aerospace tooling manufacturers building large layup molds and trim fixtures

Frequently Asked Questions

01 What does a DN Solutions VM 1260 cost?

New VM 1260 machines typically sell for $350,000 to $550,000 depending on spindle options, tooling, and accessories. The VM series commands a premium over standard VMCs because of the box-guide construction and heavy-duty design optimized for die and mold work.

02 How does the VM 1260 compare to the VM 960?

The VM 1260 adds 500 mm of X-travel (2,500 vs 2,000 mm) and 300 mm of Y-travel (1,260 vs 960 mm) while keeping the same 900 mm Z-depth. Table capacity jumps from 4,000 to 8,000 kg. Choose the 1260 for the largest mold bases; the 960 covers most mid-to-large die work at a lower price.

03 Can the VM 1260 do high-speed finishing?

The 6,000 RPM spindle handles standard finishing operations well, but it's not a high-speed machining center. For fine surface contouring in mold cavities, consider upgrading to a higher-speed spindle option if available, or plan to use a secondary HSM for finishing after roughing on the VM 1260.

04 What materials is the VM 1260 optimized for?

The box-guide construction and heavy mass target tool steels (P20, H13, S7, D2), cast iron, and other hard materials common in die and mold work. It'll handle aluminum and softer materials fine, but you'd be underutilizing its rigidity.
