Automated Cutting Systems 5x10 Plasma Table

The Automated Cutting Systems 5x10 CNC plasma table is a professional-grade plasma cutting platform designed for fabrication shops, structural steel contractors, and industrial manufacturers that need reliable, accurate plasma cutting of steel plate in a practical mid-size format. The 5-foot by 10-foot table format is one of the most popular configurations in production fabrication — large enough to accommodate full 4x8 and 5x10 plate sizes without material overhang, yet compact enough to fit in a broad range of shop layouts without requiring a dedicated large-machine bay.

Automated Cutting Systems builds its plasma tables around a rigid steel-welded frame construction with precision-machined rack-and-pinion drive systems on both gantry axes. The dual-sided gantry drive eliminates the single-sided drive flex that compromises cut accuracy on lighter-duty plasma tables, keeping the torch head tracking true to the programmed cut path across the full working envelope. Heavy-duty linear bearings on both axes maintain their preload over years of production use, resisting the contamination and shock loading that plasma cutting environments impose on precision motion components.

The table is compatible with a full range of Hypertherm plasma systems, from the Powermax series for shops cutting lighter gauge material to the HPRXD or XPR high-definition systems for fabricators demanding square cut faces and tight dimensional tolerances on structural plate. This torch compatibility range makes the Automated Cutting Systems 5x10 a scalable platform — a shop can start with a Powermax 65 or 105 for general cutting and upgrade to a high-definition torch as production requirements and quality standards increase, without changing the table.

The machine's CNC control system runs industry-standard motion control software with an intuitive operator interface for importing DXF and other common cut file formats, setting up nesting layouts, and managing cutting parameters by material and thickness. Automatic torch height control (THC) continuously adjusts the torch standoff distance based on arc voltage feedback, compensating for plate warpage and surface variations that would otherwise degrade cut quality on out-of-flat plate — a common condition with stored structural plate stock.

Downdraft fume extraction is integrated into the table's slat bed design, with dampered zones that direct exhaust airflow beneath the active cutting area to an external filtration system. This zoned extraction approach is more efficient than full-table exhaust, keeping the filter load manageable and maintaining adequate draw velocity under the torch where fume suppression is needed most. The Automated Cutting Systems 5x10 is positioned for fabricators who need a dependable, well-supported production plasma platform without the complexity and cost of a large-format structural cutting system.
