Spinner TC600
Key Specifications
X Travel
Z Travel
Max Spindle
Rapid Traverse
Spindle Power
Max Turn Length
Overview
The Spinner TC600 is a mid-range 2-axis CNC turning center from the German manufacturer Spinner Werkzeugmaschinenfabrik, designed for production turning of medium-sized shaft and chuck-type workpieces. Spinner has built a strong reputation in Europe for delivering German engineering at price points well below DMG Mori and other premium brands, and the TC600 exemplifies that value proposition.
The TC600 handles workpieces up to 320 mm (12.6 in) turning diameter and 600 mm (23.6 in) turning length, covering a wide range of production parts from automotive shafts to hydraulic components. The main spindle delivers 5,000 RPM with 15 kW (20 hp) continuous power and a hydraulic chuck size of 210 mm (8.3 in). The A2-6 spindle nose accepts standard chuck configurations, and bar capacity through the spindle is 52 mm (2.0 in) for bar-fed production work.
Axis travels are 230 mm (9.1 in) in X and 620 mm (24.4 in) in Z, with rapid traverse rates of 30 m/min in both axes. The machine uses linear guideways for fast positioning and smooth interpolation during finishing cuts. A 12-station VDI turret provides quick tool indexing for multi-operation turning cycles. The turret accepts both OD and ID tooling with VDI 30 or VDI 40 shanks depending on configuration.
The TC600 is typically equipped with a Siemens SINUMERIK 828D or Fanuc 0i-TF Plus control, depending on customer preference and regional availability. Both options provide conversational programming and standard G-code capability. Spinner offers the TC600 with optional live tooling and C-axis for light milling and cross-drilling operations, upgrading the machine from a pure turning center to a basic mill-turn platform. Pricing for the Spinner TC600 starts around $85,000 to $95,000 for a base 2-axis configuration, making it one of the most competitive German-built lathes in its size class. Configured with live tooling, tailstock, and chip conveyor, expect $110,000 to $130,000.
Full Specifications
| Parameter | Value |
|---|---|
| Max Turning Diameter | 320 mm (12.6 in) |
| Max Turning Length | 600 mm (23.6 in) |
| X-Axis Travel | 230 mm (9.1 in) |
| Z-Axis Travel | 620 mm (24.4 in) |
| Max Spindle Speed | 5,000 RPM |
| Spindle Motor Power | 15 kW (20 hp) |
| Spindle Nose | A2-6 |
| Chuck Size | 210 mm (8.3 in) |
| Bar Capacity | 52 mm (2.0 in) |
| Turret Stations | 12 (VDI 30/40) |
| Rapid Traverse Rate | 30 m/min (1,181 ipm) |
| Positioning Accuracy | ±0.005 mm |
| Repeatability | ±0.003 mm |
| CNC Control | Siemens SINUMERIK 828D or Fanuc 0i-TF Plus |
| Machine Weight | 3,800 kg (8,378 lb) |
Strengths & Limitations
Strengths
- German-built quality at 30-40% less than comparable DMG Mori or Index turning centers, making it the value leader among European-made CNC lathes
- 15 kW spindle with 5,000 RPM covers both steel and aluminum turning without needing spindle upgrades for typical production work
- Optional live tooling and C-axis transforms the TC600 into a basic mill-turn platform for cross-drilling and light milling operations in a single setup
- 52 mm bar capacity allows bar-fed production with a bar feeder for unattended operation on smaller diameter parts
- Choice of Siemens or Fanuc control accommodates different shop preferences and programmer skill sets
- 12-station turret handles complex multi-tool turning cycles without tool management compromises
Limitations
- Spinner's North American dealer network is significantly smaller than Haas, Mazak, or DMG Mori, making service and parts access more difficult in some regions
- 30 m/min rapid traverse is adequate but not class-leading; some Japanese competitors offer 36-40 m/min for faster positioning
- Linear guideways sacrifice some heavy-cut rigidity compared to box-way machines like the Okuma LB3000 EX for aggressive roughing in tough materials
- Limited brand recognition outside Europe means lower resale value compared to mainstream Japanese or American turning centers
Best For
Frequently Asked Questions
01
Both are mid-range 2-axis turning centers targeting similar work envelopes. The TC600 is German-built with tighter assembly tolerances and generally better surface finish capability. The Haas ST-20 has a significant advantage in North American parts and service availability, lower entry pricing around $60K-$70K, and a much larger user base. For shops prioritizing build quality and European sourcing, the TC600 wins. For shops needing maximum service support and lowest entry cost, the Haas is the practical choice.
02
The TC600's A2-6 spindle nose with 52 mm bore diameter is compatible with most standard magazine bar feeders from LNS, IEMCA, and FMB. Spinner offers factory-integrated bar feeder packages for seamless installation. A hydrodynamic bar feeder for the TC600 typically adds $15,000-$25,000 to the machine cost depending on brand and bar stock diameter range.
03
The TC600 is primarily a single-spindle machine. For sub-spindle capability, Spinner offers the TC600-65 SMCY variant which adds a sub-spindle for complete part machining in one setup. This configuration adds significantly to the price but eliminates the need for a second operation machine. Contact Spinner directly for sub-spindle configuration pricing.
04
Standard coolant is delivered through an external flood system with programmable nozzles. Optional high-pressure coolant systems up to 70 bar are available for improved chip breaking in stainless steel and superalloy turning. Through-tool coolant is available on live tooling configurations. A full-enclosure chip conveyor is optional but recommended for production environments.
05
Spinner typically provides a 24-month warranty on new machines covering spindle, guideways, and CNC components. Extended warranty packages are available through Spinner dealers. The warranty terms are competitive with the industry standard, though the limited North American dealer presence can complicate warranty service logistics for US-based shops.
