SNK FNC-150
This model was not found in SNK's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.
Key Specifications
Spindle Taper
Table Size
Spindle Power
spindle diameter
x travel table
y travel headstock
How much does the SNK FNC-150 cost?
Estimated price range
Our best estimate for a cnc boring machine in this class — not a quote from SNK. Configuration moves it a long way.
Overview
The SNK FNC-150 is listed as a CNC boring machine with a 150 mm (5.91 in) spindle, a 900 mm (35.4 in) quill stroke on W and a CNC B-axis rotary table rated up to 25,000 kg. SNK's current lineup does not include this model and the maker has not confirmed the table, so read it as the listed figures.
The travels are stated as upper limits, which suggests the machine was built in several sizes: up to 4,000 mm (157 in) on X at the table, up to 3,000 mm (118 in) on Y at the headstock and up to 2,000 mm (79 in) on Z at the column. Table size ranges from 1,600 × 1,600 mm to 2,000 × 2,000 mm. Anyone looking at a particular machine needs its actual travels, because the table only bounds them.
The spindle is geared, running from 1 to 2,000 RPM with 55 to 75 kW (74 to 100 hp) on an ISO 50 taper. That is a low-speed, high-power drive for large face mills, boring bars and deep quill work. It is not a spindle for small cutters at high surface speed. The W axis adds 900 mm (35.4 in) of reach into a bore without moving the column.
An ATC of up to 80 positions is listed. Machine weight is approx. 60,000 to 90,000 kg, so installation involves a prepared foundation, and the table gives no rapid rates, accuracy or power supply figures.
Full Specifications
| Parameter | Value |
|---|---|
| Spindle Diameter | 150 mm (5.91 in) |
| X Travel Table | Up to 4,000 mm (157 in) |
| Y Travel Headstock | Up to 3,000 mm (118 in) |
| Z Travel Column | Up to 2,000 mm (79 in) |
| W Travel Spindle Quill | 900 mm (35.4 in) |
| Spindle Speed Range | 1 – 2,000 RPM (gearbox) |
| Spindle Motor Power | 55–75 kW (74–100 hp) |
| Spindle Taper | ISO 50 |
| Table Size | 1,600 × 1,600 mm to 2,000 × 2,000 mm |
| Rotary Table | CNC B-axis; up to 25,000 kg capacity |
| Control System | Fanuc 30i-B or Fanuc 31i-B5 |
| ATC | Up to 80 positions |
| Machine Weight | Approx. 60,000–90,000 kg |
Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.
Strengths & Limitations
Strengths
- 150 mm (5.91 in) boring spindle with a 900 mm (35.4 in) quill stroke on W
- Geared spindle with 55 to 75 kW (74 to 100 hp) on an ISO 50 taper
- CNC B-axis rotary table rated up to 25,000 kg
- Travels up to 4,000 mm (157 in) in X, 3,000 mm (118 in) in Y and 2,000 mm (79 in) in Z
- ATC with up to 80 positions
Limitations
- Spindle speed tops out at 2,000 RPM, which rules out efficient work with small-diameter tools
- Travels, table size and power are given as ranges or upper limits, so the figures of a specific machine are not known from the table
- No accuracy or rapid traverse figure is listed
- At approx. 60,000 to 90,000 kg the machine needs a prepared foundation
Best For
Frequently Asked Questions
01
The listed spindle diameter is 150 mm (5.91 in), with an ISO 50 taper and a quill stroke of 900 mm (35.4 in) on the W axis. Spindle power is given as 55 to 75 kW (74 to 100 hp) through a gearbox.
02
The table gives 1 to 2,000 RPM through a gearbox. That range is set up for torque at low speed with large boring and milling tools; small drills and end mills will run well below their best cutting speed.
03
The rotary table is listed with a capacity of up to 25,000 kg and a size between 1,600 × 1,600 mm and 2,000 × 2,000 mm. Travels are up to 4,000 mm (157 in) in X, up to 3,000 mm (118 in) in Y and up to 2,000 mm (79 in) in Z, depending on the build.
04
The ATC is listed with up to 80 positions. The table does not give maximum tool diameter, length or weight, so those limits have to be taken from the documents of the individual machine.
