Mazak QTE-100MS

$70,000 - $110,000 Updated 2026-03-19

Key Specifications

X Travel

130 mm (5.12 in)

Z Travel

310 mm (12.20 in)

max turning diameter

200 mm (7.87 in)

max machining length

22.6"

swing over bed

400 mm (15.75 in)

bar capacity

42 mm (1.65 in)

Overview

The Mazak QTE-100MS adds a sub-spindle to Mazak's economy turning platform, delivering done-in-one part processing at the lowest possible price point for a Mazak machine with dual-spindle capability. The QTE-100MS is designed for shops producing small parts that need machining on both ends without the cost of a full Quick Turn platform.

The main spindle delivers 7.5 kW (10 hp) at 6,000 RPM through an A2-5 spindle nose with 42 mm (1.65 in) bar capacity. The sub-spindle runs 5.5 kW (7.4 hp) at 6,000 RPM for automatic part pickup, cutoff, and backworking operations including face finishing, chamfering, and ID work. The 12-station turret accepts live tools running at 4,500 RPM with 2.2 kW (3 hp) for cross-drilling, tapping, and light milling.

The work envelope covers 200 mm (7.87 in) maximum turning diameter and 250 mm (9.84 in) maximum machining length with axis travels of 130 mm on X and 310 mm on Z. Rapids reach 20 m/min on X and 24 m/min on Z. Without Y-axis, milling is limited to on-centerline features. Machine weight is approximately 3,000 kg (6,614 lb).

MAZATROL SmoothEz runs the control with built-in synchronization cycles for dual-spindle operations. The conversational programming approach keeps the learning curve manageable for operators new to sub-spindle programming.

The QTE-100MS competes with the Haas ST-10SS, Doosan Lynx 2100LB, and entry-level Nakamura-Tome sub-spindle lathes. New pricing typically falls between $70,000 and $110,000, making it one of the most affordable sub-spindle turning centers from a major Japanese builder. Used units from recent years trade between $30,000 and $65,000. Specs sourced from Mazak published data.

Full Specifications

Parameter	Value
Max Turning Diameter	200 mm (7.87 in)
Max Machining Length	22.6"
Swing Over Bed	400 mm (15.75 in)
Bar Capacity	42 mm (1.65 in)
X-Axis Travel	130 mm (5.12 in)
Z-Axis Travel	310 mm (12.20 in)
Main Spindle Speed	6,000 RPM
Main Spindle Power	7.5 kW (10 hp)
Main Spindle Nose	A2-5
Sub Spindle Speed	6,000 RPM
Sub Spindle Power	5.5 kW (7.4 hp)
Sub Spindle Chuck	5 in
Live Tool Speed	4,500 RPM
Live Tool Power	2.2 kW (3 hp)
Tool Stations	12
Turret Type	Live tooling turret
Chuck Size	8″
Rapid Traverse X	20 m/min (787 ipm)
Rapid Traverse Z	24 m/min (945 ipm)
CNC Control	MAZATROL SmoothEz
Machine Weight	3,000 kg (6,614 lb)
Supported Models	Turret type
100m 100my 100ms 100msy200m 200my 200ms 200msy	12 Position Drum Turret
Max Machining Diameter	Φ13.4"

Specifications sourced from mazak.com — verified 2026-03-28

Strengths & Limitations

Strengths

Most affordable sub-spindle turning center in the Mazak lineup, bringing done-in-one capability to budget-conscious shops
Automatic part transfer between spindles eliminates manual rechucking for parts requiring backworking
MAZATROL SmoothEz with built-in sync cycles keeps sub-spindle programming accessible for operators new to dual-spindle work
Compact 3,000 kg footprint and light weight simplify installation without specialized foundation work
6,000 RPM main and sub-spindle speeds provide good surface speed for small-diameter parts in various materials
Mazak nameplate delivers better resale value and service support than competing economy sub-spindle brands

Limitations

7.5 kW main spindle and 5.5 kW sub-spindle limit aggressive roughing in stainless and harder materials
2.2 kW live tool power restricts milling to light operations only; no heavy drilling or face milling
No Y-axis limits milling to centerline features; off-center work requires the QTE-100MSY
250 mm maximum machining length restricts the machine to short parts under 10 inches

Best For

Small production shops making two-sided parts that need both-end machining in a single automatic cycle Medical device and electronics manufacturers producing small components with backworking requirements Shops entering sub-spindle turning for the first time on a budget while wanting Mazak quality Bar-fed production environments running small-diameter parts with automatic cutoff and sub-spindle transfer Training facilities teaching sub-spindle programming on an affordable, forgiving platform

Frequently Asked Questions

01 What does a new Mazak QTE-100MS cost?

New QTE-100MS machines start around $70,000-$85,000 for base configuration. Adding high-pressure coolant, chip conveyor, bar feeder interface, and parts catcher pushes the price to $95,000-$110,000. Used units from recent years trade between $30,000 and $65,000.

02 What is the difference between the QTE-100MS and the QTE-100MSY?

Both have a sub-spindle and live tooling. The MSY adds Y-axis for off-center milling capability. The Y-axis typically adds $10,000-$20,000 to the price. Choose the MS if all milling features on your parts sit on or near the centerline.

03 How does the QTE-100MS compare to the Quick Turn 100MS?

The QTE is the economy version with lighter construction, slower live tools (4,500 vs 6,000 RPM), SmoothEz control, and slower rapids. The Quick Turn offers better rigidity and milling capability. The QTE costs $15,000-$30,000 less for a comparable configuration.

04 Can the QTE-100MS run bar-fed lights-out production?

Yes. The sub-spindle handles automatic cutoff and part transfer. Combined with a bar feeder and parts catcher, the QTE-100MS can run unattended through a full bar. The 42 mm bar capacity works with standard small-diameter bar feeders.
