INDEX R200

$120,000 - $200,000 Updated 2026-03-16

Key Specifications

Rapid Traverse

30 m/min (X and Z)

Max Turn Length

350 mm (13.78 in)

max turning diameter

200 mm (7.87 in)

max bar capacity

52 mm (2.05 in)

main spindle speed

Up to 6,000 RPM

main spindle drive

18.5 kW (24.8 hp)

Overview

The INDEX R200 is an ultra-compact 2-axis slant-bed CNC turning center from INDEX-Traub, designed to deliver precision turning performance in the smallest possible footprint. Built around a rigid slant-bed casting and a high-precision spindle, the R200 targets job shops and production facilities where floor space is at a premium but uncompromising dimensional accuracy remains non-negotiable. The machine handles bar stock up to 52 mm in diameter and chuck work up to 200 mm swing, covering a broad range of small-to-medium turned components.

At its core the R200 employs a 12-position servo-driven turret with rapid index capability, enabling efficient multi-operation turning without tool change delays. The main spindle delivers up to 6,000 RPM with sufficient torque for aggressive turning of steel, stainless, and aluminum. Linear guideways on both X and Z axes enable rapid traverses of 30 m/min, minimizing non-cutting time. The Siemens 840D sl control—standard across the INDEX G and R series—provides a familiar programming environment with full cycle support and compatibility with upstream CAM systems.

The R200's slant-bed geometry directs chips and coolant away from the work zone by gravity, reducing chip recutting and keeping the machining area clean during unattended production. Although the R200 does not include Y-axis or live tooling in its base configuration, optional live tooling allows cross-drilling, milling, and thread milling, expanding the machine's capability into second-operation turning tasks without a separate machining center.

For precision component manufacturers producing small turned parts in medium-to-high volumes—automotive sensors, hydraulic fittings, electronic hardware, and medical components—the INDEX R200 delivers INDEX's renowned build quality and control sophistication in a right-sized, cost-accessible platform. Its compact footprint makes it a natural candidate for cellular manufacturing arrangements and automation with gantry or robot loading.

Full Specifications

Parameter	Value
Max Turning Diameter	200 mm (7.87 in)
Max Bar Capacity	52 mm (2.05 in)
Max Turning Length	350 mm (13.78 in)
Main Spindle Speed	Up to 6,000 RPM
Main Spindle Drive	18.5 kW (24.8 hp)
Turret Positions	12-position VDI servo turret
Rapid Traverse Rate	30 m/min (X and Z)
CNC Control	Siemens 840D sl
Machine Weight	Approx. 4,500 kg (9,921 lb)
Floor Space	Approx. 1,800 mm × 2,200 mm
Guest Name	Dietary Restriction
David	None
Bob	None
Nancy	None
Mary	Vegetarian
Formula	Formula Output
Index	3
Goal	Formula
Find Marys Dietary Restriction	=INDEX(A1:D6, MATCH("Mary", A1:A6, 0), MATCH("Dietary Restriction", A1:D1, 0))
Find Who Is At Table Number 2	=INDEX(A1:D6, MATCH(2, D1:D6, 0), MATCH("Guest Name", A1:D1, 0))

Strengths & Limitations

Strengths

[object Object]
[object Object]
[object Object]
[object Object]

Limitations

[object Object]
[object Object]
[object Object]

Best For

Job shops producing small precision turned components in the 5–50 mm diameter range where floor space is constrained Automotive and hydraulic component suppliers requiring consistent quality on high-volume production of small fittings, sensors, and fasteners Medical device manufacturers producing precision small-diameter turned parts requiring dimensional consistency across long runs Facilities looking to deploy multiple compact turning cells with gantry or robot automation without major floor space investment

Frequently Asked Questions

01 What is the price of an INDEX R200?

New INDEX R200 CNC lathes typically range from approximately $120,000 to $200,000 depending on turret type, live tooling configuration, and control options. Used R200 machines are occasionally available from European dealers at $50,000–$100,000 depending on age and condition.

02 How does the INDEX R200 compare to the R300?

The R300 is the larger sibling in INDEX's R series, offering greater bar capacity (typically up to 65 mm), more swing, and longer machining length. The R200 is the right choice when part sizes are consistently in the sub-52 mm bar range and floor space optimization is important. Both share the same Siemens 840D sl control and INDEX build philosophy.

03 Does the INDEX R200 support automation?

Yes. The R200 is designed for integration with bar feeders, gantry loaders, and robot loading. INDEX offers its own automation interfaces and the machine's control architecture supports standard automation protocols for integration into automated manufacturing cells.

04 What control does the INDEX R200 use?

The INDEX R200 uses the Siemens 840D sl CNC control, the same platform used across INDEX's turning and multi-spindle machine lines. This provides programming consistency for shops operating multiple INDEX machines and broad CAM post-processor support.

05 What industries commonly use the INDEX R200?

The R200 is most common in automotive supply (sensors, ABS components, small fittings), hydraulics and pneumatics (miniature valves and fittings), medical device manufacturing (implant components, surgical instrument parts), and general precision contract manufacturing targeting small-diameter turned parts.
