Hyundai WIA E160

$40,000 - $60,000 Updated 2026-03-16

Key Specifications

Max Spindle

6,000 RPM

Rapid Traverse

30 m/min (1,181 ipm)

Spindle Power

7.5/5.5 kW (10/7.5 hp)

Max Turn Length

350 mm (13.8 in)

max turning diameter

260 mm (10.2 in)

chuck size

6" (165 mm)

Overview

The Hyundai WIA E160 is a compact slant-bed CNC turning center in the entry-level segment of Hyundai WIA's E-series lineup, designed to deliver reliable 2-axis turning performance at an accessible price point for small shops, training facilities, and operations adding turning capacity without a large capital commitment. With a 6-inch chuck, maximum turning diameter of 260 mm (10.2 in), and maximum turning length of 350 mm (13.8 in), the E160 is sized for small parts production.

The 6,000 RPM spindle with 7.5/5.5 kW (10/7.5 hp) motor is well-matched to the machine's work envelope for small steel, stainless, and aluminum components. The 8-station turret provides adequate tooling for typical 2-axis programs on small parts. The Fanuc 0i-TF Plus control is standard, offering all the programming functionality required for production turning with a control platform that new operators can learn quickly.

The E160's compact dimensions — machine footprint under 2,000 x 1,500 mm — make it one of the smallest footprint turning centers in the Hyundai WIA lineup. Weight is approximately 3,500 kg, which means standard shop floors handle the machine without special reinforcement. The slant-bed design at 30 degrees provides efficient chip evacuation and operator accessibility to the work zone.

The E160 competes with the Haas ST-10, Okuma LB1000 EX, and DN Solutions Lynx 2100 in the compact entry-level turning segment. At $40,000-$60,000 new, it is priced to compete directly with these machines while offering Korean build quality and Fanuc control. For shops that need a compact, reliable, Fanuc-controlled turning center for small parts production or as a complement to larger machines, the E160 delivers excellent value.

Full Specifications

Parameter	Value
Max Turning Diameter	260 mm (10.2 in)
Max Turning Length	350 mm (13.8 in)
Chuck Size	6" (165 mm)
Bar Capacity	52 mm (2.05 in)
Swing Over Bed	500 mm (19.7 in)
Max Spindle Speed	6,000 RPM
Spindle Motor Power	7.5/5.5 kW (10/7.5 hp)
Spindle Nose	A2-5
Turret Stations	8
Turret Type	BOT turret
Guideway Type	Linear guides
Rapid Traverse Rate	30 m/min (1,181 ipm)
Machine Weight	3,500 kg (7,716 lb)
CNC Control	Fanuc 0i-TF Plus

Specifications sourced from wiamachine.com — verified 2026-03-28

Strengths & Limitations

Strengths

Compact footprint under 2,000 x 1,500 mm fits in tight shop spaces or alongside larger machines in a turning cell
6,000 RPM spindle is well-matched to small-diameter work in aluminum and stainless for good surface speeds
Fanuc 0i-TF Plus control is accessible for new operators while supporting full production programming capability
Priced at $40K-$60K, the E160 is one of the most affordable new turning centers from a major manufacturer
30 m/min rapid traverse minimizes non-cutting time on short-cycle small-part programs
Lightweight at 3,500 kg — installs on standard shop floors without special foundation work

Limitations

6-inch chuck and 10.2-inch turning diameter limit the E160 to small parts — it cannot handle medium or large workpieces
7.5 kW (10 hp) spindle power restricts heavy cutting in steel; better suited to finishing and medium-depth cuts
52 mm bar capacity is smaller than many production turning applications require
8-station turret limits tooling capacity for complex multi-tool programs
No live tooling option in the base E-series configuration — limited mill-turn capability compared to L-series machines

Best For

Small job shops adding a compact, affordable CNC lathe for small parts production without a large capital investment Training facilities and vocational schools needing a reliable, safe, Fanuc-controlled turning center for student instruction Shops running high volumes of small-diameter turned components in aluminum, steel, or stainless under 10 inches diameter Second-operation cells where compact footprint and low cost are prioritized over envelope size Manufacturers needing a dedicated deburring and finishing lathe alongside larger turning centers

Frequently Asked Questions

01 How does the E160 differ from the L230A?

The E160 is smaller, lighter, and less expensive than the L230A. The E160 has a 6-inch chuck versus the L230A's 8-inch, and a 10.2-inch versus 14-inch turning diameter. The E160 is better suited to small parts production and training applications. The L230A is the better choice for shops that regularly machine parts up to 14 inches in diameter.

02 What does a new Hyundai WIA E160 cost?

New E160 machines typically sell for $40,000-$60,000 depending on options and dealer. This makes it one of the most affordable entry-level turning centers from a major manufacturer. Used E160 machines are available for $20,000-$35,000 depending on age and condition.

03 Is the E160 suitable for production work?

Yes, the E160 is well-suited to production runs of small turned components. The 8-station turret, 6,000 RPM spindle, and 30 m/min rapid traverse support efficient cycle times on small parts. For bar-feed production, it pairs with standard magazine bar feeders from LNS or FMB sized for its 52 mm bar capacity.

04 Does the E160 support sub-spindle or live tooling?

The base E160 does not include live tooling or sub-spindle capability. Hyundai WIA's L-series (L230LM, L300LMSY, etc.) provides live tooling and sub-spindle options for shops needing mill-turn capability. If live tooling is required, the L230A series is a better starting point.
