Haas Automation CNC Lathes / Turning Centers

Haas ST-25

List US$80,995 Specs verified 2026-10-02 · haascnc.com Updated 2026-10-02

Image: haascnc.com, Haas Automation

Key Specifications

X Travel

8.4 in (213 mm)

Z Travel

22.5 in (572 mm)

Max Spindle

3,400 rpm

Rapid Traverse

945 ipm (24 m/min)

Spindle Power

30 hp (22.4 kW)

Max Turn Length

22.5 in (572 mm)

How much does the Haas ST-25 cost?

Manufacturer list price

US$80,995

As published by Haas Automation, verified 2026-10-02. Options, tooling, freight and installation are extra.

Overview

The Haas ST-25 is a two-axis turning center that shares the ST-20's work envelope and carries a bigger spindle package: a 10 in (254 mm) chuck, 3 in (76 mm) of bar capacity and 30 hp (22.4 kW) delivering 300 ft-lbf (407 N·m) at 500 rpm. Turning capacity is 13 in (330 mm) in diameter by 22.5 in (572 mm) long.

Set the two side by side and the envelope is identical: the ST-20 has the same 21 in (533 mm) swing, the same 8.4 in (213 mm) of X and the same Z stroke. The difference is at the headstock. The ST-20 is rated 20 hp (14.9 kW) and 150 ft-lbf (203 N·m) with 2.5 in (64 mm) of bar capacity, so the ST-25 has twice the torque and passes bar half an inch larger through the same 3.5 in (88.9 mm) bore. It gives up top speed for that: 3,400 rpm against the ST-20's 4,000 rpm.

The standard turret is listed as a 12-station BOT type taking OD and ID tools in any combination, with 4 in (102 mm) behind it for boring bars. Two other turret styles appear in the table and both shrink the work: 11.75 in (298 mm) of turning diameter with a BMT65 turret and 11.8 in (300 mm) with a VDI turret.

Haas lists the sub-spindle as an option. Its rows describe a 5.3 in (135 mm) chuck on an A2-5 nose, 6,000 rpm on its own, 3,400 rpm synchronised with the main spindle, and a 1.5 in (38.1 mm) bore. The parts catcher, automatic parts loader, automatic door and tailstock are options too. WiFi is standard, and Haas says this generation has new castings and an 11% smaller footprint than its predecessor.

The base machine weighs 9,000 lb (4,083 kg), or 10,000 lb (4,536 kg) with the conveyor, and needs 70 A at 220 VAC three-phase or 35 A at 440 VAC. Haas lists a starting price of US$80,995.

Full Specifications

Parameter	Value
Chuck Size	10 in (254 mm)
Max Swing	21 in (533 mm)
Max Turning Diameter	13 in (330 mm)
Max Turning Diameter with Bmt65 Turret	11.75 in (298 mm)
Max Turning Diameter with VDI Turret	11.8 in (300 mm)
Max Turning Length	22.5 in (572 mm)
Bar Capacity	3 in (76 mm)
X-Axis Travel	8.4 in (213 mm)
Z-Axis Travel	22.5 in (572 mm)
Rapid Traverse Rate	945 ipm (24 m/min)
Max Thrust X	4,100 lbf (18,238 N)
Max Thrust Z	5,100 lbf (22,686 N)
Spindle Nose	A2-6
Spindle Motor Power	30 hp (22.4 kW)
Max Spindle Speed	3,400 rpm
Spindle Torque	300 ft-lbf @ 500 rpm (407 N·m @ 500 rpm)
Spindle Bore	3.5 in (88.9 mm)
Sub Spindle Chuck Size	5.3 in (135 mm)
Sub Spindle Nose	A2-5
Sub Spindle Speed	6,000 rpm
Sub Spindle Max Sync Speed with Main Spindle	3,400 rpm
Sub Spindle Chuck Throat	Ø 1.3 in × 1.37 in DEEP (Ø 33 mm × 34.8 mm DEEP)
Sub Spindle Drawbar Bore	Ø 1 in × 4.5 in DEEP (Ø 25.4 mm × 114.3 mm DEEP)
Sub Spindle Spindle Bore	1.5 in (38.1 mm)
Sub Spindle Integrated Brake Torque	17 ft-lbf (23 N·m)
Sub Spindle Spindle Orientation Accuracy	± 0.02 °
Sub Spindle Rapids	400 ipm (10 m/min)
Turret Stations	12-Station BOT
Turret OD Vs ID Tools	Any Combination (will vary with turret)
Turret Boring Bar Rear Clearance	4 in (102 mm)
Coolant Capacity	55 gal (208 L)
Air Required	4 scfm @ 100 psi (113 L/min @ 6.9 bar)
Inline Air Hose	3/8 in
Air Coupler	3/8 in
Air Pressure Min	80 psi (5.5 bar)
Electrical Service (low voltage)	220 VAC 3-phase, 70 A
Electrical Service (high voltage)	440 VAC 3-phase, 35 A
Shipping Domestic Pallet	143 × 90 × 92 in (363 × 229 × 234 cm)
Shipping Export Pallet	143 × 90 × 92 in (364 × 229 × 234 cm)
Machine Weight	9,000 lb (4,083 kg)
Shipping Domestic Pallet with Conveyor	143 × 90 × 92 in (363 × 229 × 234 cm)
Shipping Export Pallet with Conveyor	143 × 90 × 92 in (363 × 229 × 234 cm)
Machine Weight with Conveyor	10,000 lb (4,536 kg)

Specifications sourced from haascnc.com — verified 2026-10-02

Strengths & Limitations

Strengths

300 ft-lbf (407 N·m) at 500 rpm from a 30 hp (22.4 kW) spindle, twice the torque of the ST-20
3 in (76 mm) of bar capacity through a 3.5 in (88.9 mm) bore
10 in (254 mm) chuck on a machine that weighs 9,000 lb (4,083 kg)
Optional sub-spindle synchronises with the main spindle up to its full 3,400 rpm
12-station turret with any mix of OD and ID tools; BMT65 and VDI turrets are listed as alternatives
WiFi is standard, and a parts catcher and automatic parts loader are available as options

Limitations

Top speed is 3,400 rpm, against 4,000 rpm on the ST-20, which limits surface speed on small diameters
Sub-spindle, automatic door, parts catcher, parts loader and tailstock are all options
No live tooling, C axis or Y axis appears in the table for this model
Fitting a BMT65 or VDI turret cuts the turning diameter to 11.75 in (298 mm) or 11.8 in (300 mm)
Needs a 70 A supply at 220 VAC three-phase, or 35 A at 440 VAC

Best For

Bar work up to 3 in (76 mm) in steel Roughing that needs 300 ft-lbf (407 N·m) at low spindle speed Chucker work on a 10 in (254 mm) chuck within 22.5 in (572 mm) of Z Two-operation turned parts, with the optional sub-spindle

Frequently Asked Questions

01 What separates the ST-25 from the ST-20?

The spindle and chuck. The ST-25 has a 10 in (254 mm) chuck, 3 in (76 mm) of bar capacity, 30 hp (22.4 kW) and 300 ft-lbf (407 N·m) at 500 rpm, with a 3,400 rpm maximum. The ST-20 has an 8.3 in (210 mm) chuck, 2.5 in (64 mm) of bar capacity, 20 hp (14.9 kW) and 150 ft-lbf (203 N·m), and runs to 4,000 rpm. Travels, swing and turning diameter are the same.

02 Which turrets can the ST-25 have, and how do they affect turning diameter?

The table lists a 12-station BOT turret as the base configuration, with a 13 in (330 mm) maximum turning diameter. It also gives the diameter with two other turrets: 11.75 in (298 mm) with a BMT65 turret and 11.8 in (300 mm) with a VDI turret. OD and ID tools can go in any combination, depending on the turret.

03 Is a sub-spindle included on the ST-25?

No, Haas lists the sub-spindle as an option. When fitted it has a 5.3 in (135 mm) chuck, an A2-5 nose, a 1.5 in (38.1 mm) bore and a 6,000 rpm top speed, and it synchronises with the main spindle at up to 3,400 rpm. Its integrated brake holds 17 ft-lbf (23 N·m) and its rapids are 400 ipm (10 m/min).

04 What is standard and what is optional on the ST-25?

WiFi is listed as standard. The two-stage parts catcher, sub-spindle, automatic parts loader, automatic door and the new-design tailstock are all listed as options. Haas also describes new, more compact and more rigid castings, more Z travel and an 11% smaller footprint than the predecessor as features of this generation.

05 What are the electrical and air requirements?

The ST-25 needs 220 VAC three-phase at 70 A or 440 VAC three-phase at 35 A. Air demand is 4 scfm at 100 psi (113 L/min at 6.9 bar) and the supply must not fall below 80 psi (5.5 bar). The air hose and coupler are 3/8 in. Coolant capacity is 55 gal (208 L).
