Haas DS-30
Key Specifications
Tool Capacity
max cutting diameter
max cutting length
max swing
main spindle speed
main spindle power
Overview
The Haas DS-30 is the base dual-spindle turning center in the Haas DS lineup, built on the proven ST-30 platform. It combines a 22.4 kW (30 hp) main spindle with a fully capable sub-spindle, enabling complete front-and-back turning in a single cycle. Without a Y-axis or live tooling, the DS-30 is purpose-built for shops that need dual-spindle productivity — eliminating part flip and second-op setups — but do not require milling capability on the lathe.
The A2-6 main spindle runs to 4,500 RPM with 407 Nm (300 ft-lb) of torque at 500 RPM. Bar capacity is 76 mm (3.0 in) through an 89 mm (3.5 in) bore, and the main chuck is 254 mm (10 in). The sub-spindle delivers 11.2 kW (15 hp) on an A2-5 nose with a 203 mm (8 in) chuck, spinning to 4,000 RPM. The sub-spindle indexes forward to pick up the part directly from the main spindle at the end of the front operation, eliminating manual handling and achieving consistent chuck-to-chuck positioning.
The 12-station bolt-on turret handles turning, threading, boring, and grooving tools on both spindles in sequence. There is no live tooling on the base DS-30; shops that need cross-drilling or off-center milling features should look at the DS-30Y. For parts that are fully turned on both ends, the 12-station BOT turret provides all the OD, ID, threading, and grooving capability needed.
Max cutting diameter is 349 mm (13.75 in) with 826 mm (32.5 in) of Z-axis cutting length. The sub-spindle travels 810 mm (31.9 in) to reach across from the back. At 7,484 kg (16,500 lb), the DS-30 has excellent mass for a dual-spindle machine of this size, providing solid damping during interrupted cuts and threading operations. Base price starts around $115,000-$130,000, significantly more affordable than the DS-30Y while delivering the core dual-spindle productivity benefit. Specs sourced from Haas Automation published data.
Full Specifications
| Parameter | Value |
|---|---|
| Max Cutting Diameter | 349 mm (13.75 in) |
| Max Cutting Length | 826 mm (32.5 in) |
| Max Swing | 806 mm (31.75 in) |
| Main Spindle Speed | 4,500 RPM |
| Main Spindle Power | 22.4 kW (30 hp) |
| Main Spindle Torque | 407 Nm (300 ft-lb) @ 500 RPM |
| Main Spindle Nose | A2-6 |
| Main Chuck Size | 254 mm (10 in) |
| Sub Spindle Speed | 4,000 RPM |
| Sub Spindle Power | 11.2 kW (15 hp) |
| Sub Spindle Nose | A2-5 |
| Sub Chuck Size | 203 mm (8 in) |
| Bar Capacity | 76 mm (3.0 in) |
| Spindle Bore | 89 mm (3.5 in) |
| X Axis Travel | 318 mm (12.5 in) |
| Z Axis Travel | 826 mm (32.5 in) |
| Sub Spindle Travel | 810 mm (31.9 in) |
| Rapid Traverse X | 24.0 m/min (945 ipm) |
| Rapid Traverse Z | 24.0 m/min (945 ipm) |
| Tool Capacity | 12-station BOT turret |
| Machine Weight | 7,484 kg (16,500 lb) |
| Coolant Capacity | 208 L (55 gal) |
| CNC Control | Haas Next Generation Control (NGC) |
Specifications sourced from haascnc.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Dual-spindle design eliminates part flipping and second-op setups, cutting total cycle time by up to 40% on fully turned parts
- 4,500 RPM main spindle speed is the highest in the Haas DS lineup, enabling competitive surface speeds on finishing passes
- Sub-spindle picks parts directly from main spindle with consistent positioning, removing manual handling and quality risk
- 76 mm (3.0 in) bar capacity covers the most common production bar stock sizes for bar-fed dual-spindle manufacturing
- Base price around $115K-$130K is significantly below the DS-30Y, delivering the core dual-spindle benefit without Y-axis premium
Limitations
- No Y-axis or live tooling means any off-center features such as cross-holes, flats, or keyways require a separate VMC setup
- 12-station BOT turret is shared between both spindles, limiting simultaneous processing compared to dual-turret designs
- 8-inch sub-spindle chuck limits back-working diameter relative to the 10-inch main chuck
- 16,500 lb machine weight requires professional rigging and adequate floor preparation
Best For
Frequently Asked Questions
01
The DS-30Y adds a Y-axis with plus or minus 50.8 mm (2.0 in) of travel and a BMT-65 live tooling turret running at 6,000 RPM. It costs roughly $35,000-$50,000 more. The base DS-30 is purely turning with no cross-drilling, flat milling, or tapping. If any parts need off-center features, the DS-30Y eliminates a second VMC setup and pays for itself quickly. If your parts are fully turned with no milling features, the DS-30 saves money and reduces programming complexity.
02
The sub-spindle indexes forward along the Z-axis to a position where both chucks face each other and grip the part simultaneously. The main spindle releases, and the sub-spindle pulls the part back to the working position for back-end turning. The entire handoff takes a few seconds and is programmed with standard Haas macros. The NGC control manages sub-spindle synchronization and provides canned routines for common handoff operations.
03
Yes, the DS-30 is fully compatible with most 12-foot magazine bar feeders rated for 76 mm (3.0 in) bar capacity. The Haas Servo Bar 300 is the factory-matched option. Third-party feeders from LNS, Iemca, and Edge Technologies are also commonly used. A bar feeder combined with a parts catcher enables extended unattended production, with the sub-spindle depositing finished parts automatically.
04
Two ST-30 lathes cost more in total, need two operators or two separate automation systems, and introduce part-handling time between first and second ops. The DS-30 does both operations on one machine with one operator and no part handling. The downside is that if the DS-30 is down for maintenance, both spindles are offline. Shops with very high volumes may prefer redundant single-spindle machines; shops optimizing for fewer operators and lower work-in-process typically prefer the dual-spindle.
05
Base price starts around $115,000-$125,000. Adding a chip conveyor, parts catcher, bar feeder interface, and high-pressure coolant typically pushes the configured price to $135,000-$150,000. Used DS-30 machines are less common on the used market than single-spindle ST models, so pricing varies more widely based on condition and options.
