DN Solutions PUMA TL 2000 LM

$180,000 - $240,000 Updated 2026-03-19

Key Specifications

Spindle Power

22 kW (29 hp)

Max Turn Length

1000 mm

chuck size

8 inch

max turning diameter

350 mm

x axis travel

250 mm (10 in)

z axis travel

1,050 mm (41 in)

Overview

The DN Solutions PUMA TL 2000 LM is a twin-turret turning center with live tooling that's designed to cut cycle times by running two turrets simultaneously on the same workpiece. With 24 total tool stations (12 upper + 12 lower), live milling capability, and an 8-inch chuck spinning at 5,000 RPM, this machine is built for shops that measure competitiveness in seconds per part.

The main spindle puts out 22 kW (29 hp) with 477 Nm (352 ft-lb) of torque. That's enough for production turning in steel and stainless at the 8-inch chuck size. The dual turrets can rough and finish simultaneously, or run OD work on one turret while the other handles ID boring — the programming flexibility is what makes these machines so productive. Max turning diameter is 350 mm (14 in) with 1,000 mm (39 in) of turning length.

Both turrets carry live tools at 5,000 RPM, so you're not limited to turning-only on either one. Cross-drilling, tapping, and C-axis milling are all in play. X-axis travel is 250 mm (10 in) and Z-axis runs 1,050 mm (41 in), with rapids at 20 m/min on X and 24 m/min on Z.

At 8,400 kg (18,519 lb), the TL 2000 LM is a heavy machine for its chuck size — all that mass comes from the twin-turret structure and the rigid base needed to handle simultaneous cutting forces from two directions. The footprint is 3,900 mm (154 in) long by 2,144 mm (84 in) wide.

The FANUC 0i-TF Plus control handles dual-turret programming, though there's a steeper learning curve compared to single-turret machines. You'll need operators who understand simultaneous toolpath management and interference avoidance. The payoff is dramatic: cycle time reductions of 30-50% compared to single-turret machines on the right parts.

Full Specifications

Parameter	Value
Chuck Size	8 inch
Max Turning Diameter	350 mm
Max Turning Length	1000 mm
X Axis Travel	250 mm (10 in)
Z Axis Travel	1,050 mm (41 in)
X Axis Rapid Traverse	20 m/min (787 ipm)
Z Axis Rapid Traverse	24 m/min (945 ipm)
Max Spindle Speed	5,000 RPM
Spindle Motor Power	22 kW (29 hp)
Spindle Torque	477 Nm (352 ft-lb)
Turret Stations	12 upper + 12 lower (24 total)
Rotary Tool Speed	5,000 RPM
Multi Turret	true
Machine Weight	8,400 kg (18,519 lb)
Machine Length	3,900 mm (154 in)
Machine Height	1,930 mm (76 in)
Machine Width	2,144 mm (84 in)
CNC Control	FANUC 0i-TF Plus
Metric	IMPERIAL
Capacity	Chuck sizeMax. Turning DiameterMax. Turning Length
Travels	X-Axis Rapid TraverseZ-Axis Rapid TraverseX-Axis Travel DistanceZ-Axis Travel Distance
Main Spindle	Max. Spindle SpeedMax. Spindle PowerMax. Spindle Torque
Turret	No. of tool stationRotary Tool r/min
No Of Tool Station	Rotary Tool r/min
Dimensions	LengthHeightWidthWeight
Favorites	PUMA TL2500XLM
12 Ea	5000 RPM

Specifications sourced from dn-solutions.com — verified 2026-03-28

Strengths & Limitations

Strengths

Twin turrets with 24 total tool stations enable simultaneous cutting for 30-50% cycle time reduction
Both turrets carry live tools at 5,000 RPM for maximum programming flexibility
5,000 RPM spindle handles both steel production and aluminum at reasonable surface speeds
8,400 kg mass provides stability for simultaneous two-direction cutting forces
1,000 mm turning length accommodates longer shafts on the long-bed platform
FANUC 0i-TF Plus control with dual-turret simultaneous programming capability

Limitations

Dual-turret programming has a steeper learning curve — operators need to manage interference zones and synchronization
8,400 kg weight and 3,900 mm length require significant floor space and foundation prep
Higher acquisition cost than single-turret alternatives for the same chuck size
22 kW spindle power is moderate — not for heavy roughing in tough materials like Inconel
Tooling costs are higher with 24 stations to populate

Best For

High-volume production shops where cycle time reduction directly impacts profitability Automotive and aerospace tier suppliers running medium-complexity parts at volume Shops turning shafts and components that benefit from simultaneous OD/ID operations Contract manufacturers looking to win jobs on price by cutting per-part cycle times Facilities upgrading from single-turret lathes that have hit cycle time ceilings on key parts

Frequently Asked Questions

01 How much cycle time can dual turrets actually save?

It depends heavily on the part geometry, but 30-50% reductions are common on parts with both OD and ID features, or parts that need roughing and finishing. The savings come from overlapping operations that would be sequential on a single-turret machine.

02 What does a PUMA TL 2000 LM cost?

Expect $180,000-$240,000 new depending on options. The dual-turret design and live tooling carry a significant premium over single-turret lathes. Used TL 2000 machines sell in the $80,000-$140,000 range.

03 Is dual-turret programming difficult?

There's definitely a learning curve. You need to manage turret synchronization, interference avoidance, and wait codes. Most operators with single-turret experience can learn it in a few weeks. CAM software with dual-turret simulation (like Mastercam or ESPRIT) is strongly recommended.

04 How does the TL 2000 LM compare to the TL 2500?

The TL 2000 has an 8-inch chuck with 5,000 RPM and live tooling. The TL 2500 has a 10-inch chuck with 4,000 RPM but no live tooling on the base model. Choose the 2000 for smaller parts with milling features, or the 2500 for larger diameters with turning-only dual-turret work.

05 Can both turrets cut at the same time?

Yes, that's the whole point. The upper and lower turrets can engage the workpiece simultaneously, running independent toolpaths. This is how you achieve the cycle time savings — one turret can rough while the other finishes, or one handles OD while the other works ID.
