DN Solutions PUMA 700 LY II

$480,000 - $650,000 Updated 2026-03-19

Key Specifications

Spindle Power

55 kW (74 hp)

Max Turn Length

3250 mm

chuck size

24 inch

max turning diameter

750 mm

x axis travel

470 mm (19 in)

y axis travel

200 mm (8 in)

Overview

The DN Solutions PUMA 700 LY II is the long-bed Y-axis variant of the 700 series — sharing the same platform as the 700 LM II but with a dedicated Y-axis for true off-center milling operations. With a 24-inch chuck, 900 mm (35 in) max turning diameter, 3,200 mm (126 in) of turning length, and Y-axis capability, it represents one of the most capable horizontal mill-turn lathes in DN Solutions' catalog.

The spindle delivers 55 kW (74 hp) with 8,076 Nm (5,957 ft-lb) of torque through a 375 mm (14.8 in) bore at up to 1,500 RPM. These are the same numbers as every other 700-series variant — the LY II designation adds Y-axis travel to the long-bed milling platform without changing the base turning capability.

The Y-axis provides 200 mm (8 in) of off-center travel — the largest Y-axis stroke in the PUMA lineup, sized appropriately for the scale of parts this machine handles. Combined with 3,000 RPM live tooling on the 12-station turret and C-axis control, the LY II can mill large flats, drill off-center bolt patterns on heavy flanges, cut keyways on 3-meter shafts, and tap holes — all on parts that might weigh multiple tonnes and require crane handling.

Z-axis travel stretches to 3,235 mm (127 in) with 470 mm (19 in) on X. Rapids are 12 m/min on X, 10 m/min on Z, and 6 m/min on Y. At 22,500 kg (49,604 lb), the LY II carries additional mass over the LM II for the Y-axis mechanism. Box-way construction throughout handles the severe forces generated during heavy turning and milling.

The FANUC 0i-TF Plus control manages the multi-axis programming. The PUMA 700 LY II exists for a clear purpose: shops in power generation, oil and gas, marine, and heavy industry that process long, large-diameter parts with complex milled features and cannot afford the time or risk of moving those parts to secondary machines. Specs sourced from DN Solutions published data.

Full Specifications

Parameter	Value
Chuck Size	24 inch
Max Turning Diameter	750 mm
Max Turning Length	3250 mm
X Axis Travel	470 mm (19 in)
Y Axis Travel	200 mm (8 in)
Z Axis Travel	3,235 mm (127 in)
X Axis Rapid Traverse	12 m/min (472 ipm)
Y Axis Rapid Traverse	6 m/min (236 ipm)
Z Axis Rapid Traverse	10 m/min (394 ipm)
Max Spindle Speed	1,500 RPM
Spindle Motor Power	55 kW (74 hp)
Spindle Torque	8,076 Nm (5,957 ft-lb)
Spindle Bore	375 mm (14.8 in)
Turret Stations	12-station turret
Rotary Tool Speed	3,000 RPM
Machine Length	7,354 mm (290 in)
Machine Height	2,590 mm (102 in)
Machine Width	2,714 mm (107 in)
Machine Weight	22,500 kg (49,604 lb)
CNC Control	FANUC 0i-TF Plus
Metric	IMPERIAL
Capacity	Chuck sizeMax. Turning DiameterMax. Turning Length
Travels	X-Axis Rapid TraverseZ-Axis Rapid TraverseX-Axis Travel DistanceY-Axis Travel DistanceZ-Axis Travel Distance
Main Spindle	Max. Spindle SpeedMax. Spindle PowerMax. Spindle Torque
Turret	No. of tool stationRotary Tool r/min
No Of Tool Station	Rotary Tool r/min
Dimensions	LengthHeightWidthWeight
Favorites	PUMA 800XLY II
12 Ea	3000 RPM

Specifications sourced from dn-solutions.com — verified 2026-03-28

Strengths & Limitations

Strengths

200 mm Y-axis travel is the largest in the PUMA lineup — enables substantial off-center milling on the biggest parts
8,076 Nm torque and 55 kW spindle handle the heaviest roughing in any material
375 mm spindle bore passes large-diameter tubular stock through the headstock
3,200 mm max turning length covers long shafts and rollers at 35-inch swing
24-inch chuck provides secure clamping on large-diameter forgings and castings
Eliminates dangerous and costly crane moves to secondary machines for milling operations on heavy parts

Limitations

22,500 kg requires the most substantial foundation preparation and heavy rigging
10 m/min Z-axis rapids mean significant traverse time across the long bed
7.3 meter machine length demands a dedicated bay with overhead crane access
Price point in the $480K-$650K range limits this to shops with consistent heavy mill-turn volume
3,000 RPM live tool speed is lower than smaller PUMA machines

Best For

Power generation OEMs machining long turbine shafts with keyways, bolt patterns, and flats at multiple positions Oil and gas equipment manufacturers producing BOP stacks and subsea components with complex milled features Marine and shipbuilding shops turning propeller shafts with off-center features along the full length Mining industry manufacturers machining large crusher shafts and rollers with drive features Nuclear component shops producing large-diameter, long precision parts with tight positional tolerances on milled features

Frequently Asked Questions

01 What is the difference between the PUMA 700 LY II and the 700 LM II?

Both share the same spindle, chuck, bed length, and live tooling. The LM II has C-axis milling only (on-center). The LY II adds a 200 mm Y-axis for true off-center milling operations. If your parts need off-center holes, flats, or keyways, the LY II eliminates secondary VMC operations.

02 How does the 200 mm Y-axis compare to smaller PUMA Y-axis machines?

The 200 mm Y-axis stroke is the largest in the PUMA lineup, proportional to the machine's 35-inch swing. Smaller PUMAs like the 3100 series have 105 mm Y-axis travel, and the 5100 series has 160 mm. The larger stroke allows bigger off-center features on the proportionally larger parts.

03 What does a PUMA 700 LY II cost?

New machines run $480,000-$650,000 depending on options. The Y-axis adds a premium over the LM II variant. At this machine class, the Y-axis ROI comes from eliminating even a single crane move and VMC setup on parts weighing thousands of kilograms.

04 Can the Y-axis handle heavy milling operations?

The Y-axis with 3,000 RPM live tooling handles production-level milling: flats, keyways, bolt patterns, and cross-drilling. It is not a replacement for a horizontal boring mill on heavy pocketing work, but for typical turned-part secondary features, it is fully productive.
