DN Solutions CNC Lathes / Turning Centers

DN Solutions PUMA 2600 Y II

Est. $130,000 - $175,000 Specs verified 2026-10-02 · dn-solutions.com Updated 2026-10-02

Image: dn-solutions.com, DN Solutions

Key Specifications

X Travel

260 mm (10 in)

Y Travel

105 mm (4 in)

Z Travel

830 mm (33 in)

Max Spindle

4,000 rpm

Rapid Traverse

30 m/min (1,181 ipm)

Spindle Power

22 kW (29 hp)

How much does the DN Solutions PUMA 2600 Y II cost?

Estimated price range

Est.$130,000 - $175,000

Our best estimate for a cnc lathes / turning center in this class — not a quote from DN Solutions. Configuration moves it a long way.

Overview

The DN Solutions PUMA 2600 Y II is the starting point of DN's 10 in Y-axis lathe range: one spindle, the shorter bed, 760 mm (30 in) of turning length and 830 mm (33 in) of Z travel. The rest of the range is this machine with something added: the PUMA 2600 YB II takes a 12 in chuck, and other models bring a longer bed or a sub-spindle.

The spindle is where it parts company with the 8 in PUMA 2100 Y II. Both are rated 22 kW (29 hp), but this one is set up for torque: 599 N·m (442 ft-lb) with a 4,000 rpm maximum, where the PUMA 2100 Y II lists 358 N·m (264 ft-lb) and 5,000 rpm. Against the PUMA 2100 Y II that is about 67% more torque for 20% less top speed. The larger machine also turns longer parts, 760 mm against the 520 mm (20 in) of the PUMA 2100 Y II, but not wider ones. Its turning diameter is 376 mm (15 in), and the PUMA 2100 Y II lists 406 mm (16 in).

Milling is handled by a 12-station turret with live tools that reach 5,000 rpm, faster than the main spindle itself, on a Y axis with 105 mm (4 in) of travel. X travel is 260 mm (10 in) and rapids are 30 m/min (1,181 ipm).

At 6,100 kg (13,448 lb) and 3,560 mm (140 in) long, it is the lightest and shortest of the PUMA 2600 Y-axis machines. If the work is heavier, the PUMA 2600 YB II fits a 12 in chuck and a 1,123 N·m (828 ft-lb) spindle into a machine of 6,200 kg (13,669 lb), with the speed limit dropping to 2,800 rpm.

Full Specifications

Parameter	Value
Chuck Size	10 in
Max Turning Diameter	376 mm (15 in)
Max Turning Length	760 mm (30 in)
Rapid Traverse Rate	30 m/min (1,181 ipm)
X-Axis Travel	260 mm (10 in)
Y-Axis Travel	105 mm (4 in)
Z-Axis Travel	830 mm (33 in)
Max Spindle Speed	4,000 rpm
Spindle Motor Power	22 kW (29 hp)
Spindle Torque	599 N·m (442 ft-lb)
Turret Stations	12
Live Tool Speed	5,000 rpm
Floor Space Required	3,560 × 1,945 × 2,163 mm (140 × 77 × 85 in)
Machine Weight	6,100 kg (13,448 lb)

Specifications sourced from dn-solutions.com — verified 2026-10-02

Strengths & Limitations

Strengths

599 N·m (442 ft-lb) from 22 kW (29 hp), about 67% more torque than the 358 N·m (264 ft-lb) PUMA 2100 Y II
4,000 rpm spindle, against 2,800 rpm on the 12 in PUMA 2600 YB II
760 mm (30 in) of turning length in a machine 3,560 mm (140 in) long
105 mm (4 in) Y axis and 5,000 rpm live tools on 12 stations
6,100 kg (13,448 lb), the lightest PUMA 2600 Y-axis model

Limitations

376 mm (15 in) turning diameter is smaller than the 406 mm (16 in) of the 8 in PUMA 2100 Y II
No sub-spindle rows in this column of DN's table
Top speed is 4,000 rpm, where the PUMA 2100 Y II reaches 5,000 rpm
Live-tool power, spindle bore and bar capacity are not stated

Best For

General 10 in chuck turn-mill work up to 760 mm (30 in) long Steel parts that need more torque than the 8 in PUMA 2100 Y II offers Parts with flats, slots and off-centre holes within 105 mm (4 in) of Y travel Shops that want Y-axis capability without the long bed or sub-spindle

Frequently Asked Questions

01 Should I buy the PUMA 2600 Y II or the PUMA 2100 Y II?

It depends on torque and part length. The PUMA 2600 Y II has a 10 in chuck, 599 N·m (442 ft-lb), 4,000 rpm and 760 mm (30 in) of turning length. The PUMA 2100 Y II has an 8 in chuck, 358 N·m (264 ft-lb), 5,000 rpm and 520 mm (20 in), and at 5,550 kg (12,236 lb) it is lighter than the 6,100 kg (13,448 lb) PUMA 2600 Y II.

02 What does the PUMA 2600 YB II change?

The chuck and spindle. The PUMA 2600 YB II lists a 12 in chuck, 26 kW (35 hp), 1,123 N·m (828 ft-lb) and 2,800 rpm, with a turning length of 725 mm (29 in). The PUMA 2600 Y II keeps the 10 in chuck and runs to 4,000 rpm with 599 N·m (442 ft-lb) and 760 mm (30 in) of turning length.

03 What are the axis travels of the PUMA 2600 Y II?

X travel is 260 mm (10 in), Y travel is 105 mm (4 in) and Z travel is 830 mm (33 in). Maximum turning diameter is 376 mm (15 in), maximum turning length is 760 mm (30 in), and rapid traverse is 30 m/min (1,181 ipm).

04 How big is the PUMA 2600 Y II?

The listed dimensions are 3,560 × 1,945 × 2,163 mm (140 × 77 × 85 in), given as length, width and height, and the machine weighs 6,100 kg (13,448 lb). The long-bed PUMA 2600 LSY II weighs 7,850 kg (17,306 lb) by comparison.
